Before printing Load Roll Media
!! IMPORTANT !!
Explain to fix the Media flanges by changing their direction depending on the diameter of the paper tube.
Explain to adjust [Feed Correction] and [Bidirectional Correction] when using another type of media.
Explain about the thickness of usable media. Refer to the User's Manual [Usable Media].
Explain to use the Media clamps when using the media which curls easily.
Explain to remove the roll media from the machine after use.
If the roll media is installed on the machine for a long time, the roll media may bend by the weight
and it may influence the printing result.
Load Sheet Media
Secure in Place Using the Media Clamps. (Only when printing)
!! IMPORTANT !!
There are Short Media Clamps and Long Media Clamps.
The long Media Clamps interfere with the separating knife.
Explain to be sure to set [MEDIA CLAMP] to [LONG] in the menu when using the long media clamps.
Making this setting disable the media-cutoff operation.
Heater Operation
When no media is loaded.
When media is loaded.
Changing the Number of Pinch Rollers to match the Media
You can detach the center pinch rollers.
This lets you vary the number used to match such conditions as the width or composition of the media.
!! IMPORTANT !!
Make sure to place all pinch rollers above grit rollers.
If not, error message will be displayed when you close the Front Cover.
When printing on Banner such as SPVCB, please use all middle pinch rollers (5pcs.) to feed the media
smoothly.
When cutting on Hi Gloss Vinyl such as SV-GG, please remove the middle pinch rollers.
Operations
Make the Temperature Setting for the Heaters
!! IMPORTANT !!
Do not touch the platen when the heater is operating.
You can set the temperature either to "OFF" or to a value from 30 to 50 degrees C
(in steps of 1 degrees C )
If the software you're using is provided with a feature for setting the heater temperature,
you can use your software to adjust the temperature.
Check the State of the Printing Heads
Check the Cutting Condition Settings
The following cutting conditions can be set by [CUT CONFIG] key.
* Blade Force * Blade Offset
* Tool-up Speed *Cutting Speed
