CDM-710 Broadcast Satellite Modem
Appendix A
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier) Query
Rx Symbol
RSR= 9 bytes
Rate
Enable/
AEQ= 1 byte
Disable
Adaptive
Equalizer
ASI Rx Frame
ARF= 2 bytes
Size
Auto Switch
ASW= 1 byte
Mode
ASI Tx Frame
ATF= 2 bytes
Size
Rx BER
N/A 7 bytes
Clear All Stored
CAE= None
Events
Description of Arguments
Command or Query.
Rx Symbol Rate in the form x, where:
s=Symbol Rate in Msps
Example: RSR=20.000000 (20 Msps.)
Note: Refer to Sect. 1.5 Summary of Specifications for available symbol
rates for each mode.
Command or Query.
Adaptive Equalizer status in the form x, where:
0=Disable
1=Enable
Example: AEQ=1 (Adaptive Equalizer enabled)
Command or Query.
(CDI-40 ASI module only) Indicates whether the ASI Rx Frame Size is 188 or
204 bytes, in the form sf, where:
s = interface slot ( 1 or 2 )
f = frame size
0 = 188 bytes
1 = 204 bytes
Example: ARF=11 (Interface Slot 1 set to 204 byte frame size)
Command or Query.
Unit returns the redundancy auto/manual mode of the unit in the form x, where:
0 = Manual
1 = Automatic
Example: ASW=0 (Manual Mode selected)
Command or Query.
(CDI-40 ASI module only) Indicates whether the ASI Tx Frame Size is 188 or
204 bytes in the form sf, where:
s = interface slot ( 1 or 2 )
f = frame size
0 = 188 bytes
1 = 204 bytes
Example: ATF=11 (Interface Slot 1 set to 204 byte frame size)
Query only.
Units returns the value of the estimated BER in the form ab x 10
are the value. Last two bytes are the exponent. Returns 0.0E+00 if the demodulator
is unlocked.
Example: BER=4.8E-03 (BER = 4.8 x 10
Command only.
Forces the software to clear the software events log.
Example: CAE=
Note: This command takes no arguments
-c
. First three bytes
-3
is specified)
A–38
MN/CDM710.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
RSR= RSR? RSR=ss.ssssss
RSR?
RSR*
RSR#
AEQ= AEQ? AEQ=x
AEQ?
AEQ*
AEQ#
ARF= ARF?s ARF=sf
ARF?
ARF*
ARF#
ASW= ASW? ASW=x
ASW? (See Description of
ASW* Arguments)
ASW#
ATF= ATF?s ATF=sf
ATF?
ATF*
ATF#
BER? BER? BER=a.bEscc
BER*
BER#
CAE= N/A N/A
CAE?
CAE*
CAE#
Revision 11
