Comtech EF Data CDM-710 Installation And Operation Manual page 187

CDM-710 Broadcast Satellite Modem
Appendix A
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier) Query
Gigabit Stream
GTO= 3 bytes
Timeout
Initialize Events
IEP= None
Pointer
Boot Image
IMG= 1 byte
Tx Output
IMP= 1 byte
Impendance
IP Address
IPA= 18 bytes
Gateway
IPG= 15 bytes
Address
Interface Type
N/A 2 bytes
Description of Arguments
Command or Query.
Gigabit Stream Timeout (Only used when in Dual Stream Mode) in the form stt,
where:
s=Slot (1, 2)
t=Timeout in 100 mS intervals (0 – 10)
Command only.
Resets internal pointer to allow RNE? queries to start at the beginning of the
stored events log.
Command only.
Boot image selection, where n is the image number:
1=Image #1
2=Image #2
Example: IMG=1 (Image #1 selected for booting.)
Command or Query.
Tx output impedance in the form x, where:
0=50 Ohm
1=75 Ohm
Example: IMP=0 (Impedance set to 50 Ohms)
Note: Setting Tx Impedence is only possible on 70/140 MHz units.
Command or Query.
Used to set the IP address and network prefix for the 10/100 BaseTx Ethernet
management port, in the form xxx.xxx.xxx.xxx.yy, where:
xxx.xxx.xxx.xxx is the IP address
yy is the network prefix (00..31)
Example: IPA=010.006.030.001.24
Command or Query.
Used to set the Gateway IP addess for the 10/100 Base Tx Ethernet
management port, in the form xxx.xxx.xxx.xxx, where:
xxx.xxx.xxx.xxx is the IP address
Example: IPG = 010.006.030.001
Query only.
Interface Type in the form sx, where:
s=Defines which interface slot (1 or 2)
x=Defines the interface type, where:
0=ASI
1=Gigabit Ethernet
2=HSSI
Example: ITF?1
A–13
MN/CDM710.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
GTO= GTO?s GTO=stt
GTO#
GTO?
GTO*
IEP= N/A N/A
IEP?
IEP*
IEP#
IMG= IMG? IMG=n
IMG?
IMG*
IMG#
IMP= IMP? IMP=x
IMP?
IMP*
IMP#
IPA= IPA? IPA= xxx.xxx.xxx.xxx.yy
IPA?
IPA*
IPA#
IPG= IPG? IPG = xxx.xxx.xxx.xxx
IPG?
IPG*
IPG#
ITF? ITF?s ITF=sx
ITF*
ITF#
Revision 11
