Figure 7-5. Dvb-S2 8-Psk Packet Error Rate Versus Es/No - Comtech EF Data CDM-710 Installation And Operation Manual

CDM-710 Broadcast Satellite Modem
Forward Error Correction Options
1.0E-02
1.0E-03
3/5
1.0E-04
1.0E-05
1.0E-06
1.0E-07
5 6

Figure 7-5. DVB-S2 8-PSK Packet Error Rate versus Es/No

2/3
3/4
7 8
Es/No (dB)
7–10
DVB-S2: 8-PSK PER vs Es/No
5/6
9 10 11
Revision 11
MN/CDM710.IOM
8/9 9/10
12 13
