CDM-710 Broadcast Satellite Modem
Front Panel Operation
(CONFIG: Tx) Mode
If S2-G/S2-TS is selected, the (CONFIG:) Tx
available:
Transport Mode: Generic
TransportStream
This command applies only for a CDI-60 HSSI interface in DVB-S2 mode. .
IMPORTANT
The default Transport Mode is TransportStream, regardless of mode or interface type.
Select Generic or TransportStream using the ◄ ► arrow keys, then press

(CONFIG: Tx) Frequency

TX Freq: 0140.0000 MHz
To edit the Tx IF Frequency, use the
arrow keys to change the value of that digit. Press
Note the following:
CDM-710 (70/140 MHz)
CDM-710L (L-Band)
The bandwidth of the modulated Tx carrier must stay within the IF frequency
range. The modem disallows settings that exceed the range, and will turn off
the Tx Carrier.
CAUTION

(CONFIG: Tx) Pwr

TX Power: Level
On/Off Imped
Select Level, On/Off, or Imped using the
The Imped(ance) selection is only available/displayed when the 70/140 MHz
Modulator card is installed.
IMPORTANT

S2-G/S2-TS (DVB-S2 mode only)

( E)
( E)
arrow keys to select the digit to be edited, then use the
The ranges of frequencies are from 52 to 88 MHz and from 104 to 176
MHz with a resolution of 100 Hz.
The range is 950 to 2000 MHz with 100 Hz resolution.
( E)
arrow keys, then press
5–17
Mode S2-G/S2-TS option becomes
when done.
ENTER
ENTER
Revision 11
MN/CDM710.IOM
ENTER.
.
