Comtech EF Data CDM-710 Installation And Operation Manual page 205

CDM-710 Broadcast Satellite Modem
Appendix A
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier) Query
Rx Demod
RSW= 3 bytes
Acquisition
Sweep Width
Rx Transport
N/A 1 byte
Mode
Serial Number
N/A 9 bytes
Software
N/A 5 bytes
Revision
Real-time Clock
TIM= 6 bytes
Time
Temperature
N/A 3 bytes
Description of Arguments
Command or Query.
Rx ± acquisition sweep range of demodulator, in kHz, ranging from ± 1 to ± 100
kHz in the form xxx.
Example: RSW=009 (± 9 kHz selected)
Query only.
Reads the transport mode for DVB-S2 mode only in the form x, where:
0 = Generic Mode
1 = Transport Stream (Default)
Note: Command applies only with DVB-S2 and HSSI. For any other mode, set
RTM to 1.
Example: RTM=1 (Transport Stream selected)
Query only.
Used to query the unit 9-digit serial number. Unit returns its S/N in the form
xxxxxxxxx.
Example: SNO=176500143
Query only.
Unit returns the value of the internal software revision installed in the unit, in the
form Boot:X.X.X Bulk1:Y.Y.Y Bulk2: Z.Z.Z.
Example: SWR=Boot:1.0.3 Bulk1:1.0.1 Bulk2:1.0.0
Command or Query.
A time as indicated from midnight, in the form hhmmss, where:
hh = hours (00 to 23)
mm = minutes (00 to 59)
ss = seconds (00 to 59)
Example: TIM=231259 (23 hours: 12 minutes: 59 seconds)
Query only.
Unit returns the value of the internal temperature, in degrees C, in the form sxxx,
where:
s=sign (+ or -)
xxx=number of degrees.
Example: TMP=+026
A–31
MN/CDM710.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
RSW= RSW? RSW=xxx
RSW? (See Description of
RSW* Arguments)
RSW#
RTM? RTM? RTM=x
RTM*
RTM#
SNO? SNO? SNO=xxxxxxxxx
SNO*
SNO#
SWR? SWR? SWR=Boot:X.X.X Bulk1:Y.Y.Y
SWR* Bulk2:Z.Z.Z
SWR#
TIM= TIM? TIM=hhmmss
TIM?
TIM*
TIM#
TMP? TMP? TMP=sxxx
TMP*
TMP#
Revision 11
