CDM-710 Broadcast Satellite Modem
CDI-70 1000 Base-T Gigabit Ethernet (GigE) Interface Module
Specification Feature
Monitor and
WAN Port Statistics (cont.)
Control (M&C)
(continued)
Management Port Statistics
Controlled Functions
Monitored Functions
Supported Protocols
Description
Null packets due to out-of-sync condition
Overrun events
Underrun events
Out-of-sync events
Ingress octets
Ingress unicast
Ingress broadcast packets
Ingress multicast packets
Ingress good octets
Ingress bad octets
Ingress unicast packets
Ingress broadcast packets
Ingress multicast packets
Ingress pause packets
Ingress undersize packets
Ingress fragments
Ingress oversize packets
Ingress jabber
Ingress RX errors
Ingress Frame Check Sequence Errors
Egress octets
Egress unicast packets
Egress broadcast packets
Egress multicast packets
Data Rate
Loss of data: Mask as Fault or Alarm
Ingress buffer violation timeout (100ms. to 1s.)
Management IP Address and Mask
Ingress Multicast Group Address 1
Ingress Multicast Group Address 2
Ingress Multicast Source Address 1
Ingress Multicast Source Address 2
Tx data rate
Tx Enable/Disable
Ingress UDP port base number
Ingress FEC enable/disable
Egress Multicast Group Address
Egress (to LAN) Enable/Disable
Egress UDP destination port base number
Egress UDP source port base number
Egress FEC enable/disable
Egress Tx FEC Configuration (L, D)
Loss of Tx Data (Data Connector Removed): Indicates a loss of signal
and transmits (to WAN) MPEG null
TX clock PLL program error
Buffer status
10/100/1000Base-T Link Status
ICMP RFC-792
IGMP V3 RFC-3376
10–5
