CDM-710 Broadcast Satellite Modem
Front Panel Operation
(CONFIG: Intfc1 ASI) Rx
Intfc1 ASI Rx Frame:
188
To enable the desired sync mode, select 108 or 204 using the ◄ ► arrow keys, then press
.
ENTER

(CONFIG: Intfc1 ASI) Config

Intfc1 ASI CONFIG:
Port
Select Port or Bandwidth using the
(CONFIG: Intfc1 ASI) Config
Intfc1 ASI Port:
J4
To select the active port on the ASI Interface, select J4 or J5 using the ◄ ► arrow keys, then
press
ENTER
Note: Also see
(CONFIG: Intfc1 ASI) Config
Intfc1 ASI Bandwidth:
Wide
To select the loop bandwidth of the ASI input, select Wide or Narrow using the ◄ ► arrow
keys, then press
Terrestrial jitter sometimes increases when data is sent across the Public Switched Telecom
Network (PSTN).
Wide corresponds to about 2 Hz and Narrow is approximately 0.5 Hz. Normally, the Wide
selection is adequate, but when higher amounts of terrestrial jitter are present in the incoming
ASI data stream the Narrow setting will help reduce jitter.
204 (
Bandwidth (
J5 (
.
(CONFIG:) AUX
Narrow (
.
ENTER
Frame
E)
E)
arrow keys, then press
Port
E)
for redundancy operation.
1:1 Mode
Bandwidth
E)
5–25
