CDM-710 Broadcast Satellite Modem
Appendix A
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier) Query
Retrieve next 5
N/A 75 bytes
unread Stored
Events
Tx ASI
TAB= 2 bytes
Bandwidth
Tx Alpha Rolloff TAR=
1 byte
Tx Clock
TCI= 2 bytes
Invert
Description of Arguments
Query only.
Unit returns the oldest 5 Stored Events which have not yet been read over the
remote control in the form {CR}Sub-body{CR}Sub-body{CR}Sub-body{CR}Sub-
body{CR}Sub-body, where Sub-body= ABCddmmyyhhmmss is as follows:
A being the fault/clear indicator.
F=Fault
C=Clear
I=Info
B being the fault type where:
1=Unit
2=Rx Traffic
3=Tx Traffic
4=Log
C is Fault Code numbers, as in FLT? or Info Code, which is:
0=Power Off
1=Power On
2=Log Cleared
3=Global Config Change
4=Redundancy Config Change
If there are less than 5 events to be retrieved, the remaining positions are
padded with zeros. If there are no new events, the response is RNE*.
Command or Query.
Tx ASI Bandwidth in the form sx, where:
s=Defines which interface slot (1 or 2)
x=Defines ASI Bandwidth, where:
0=Wide
1=Narrow
Example: TAB=11 (Narrow bandwidth selected)
Command or Query.
Tx Alpha Rolloff in the form x, where:
0 = 20%
1 = 25%
2 = 35%
Example: TAR=0 (Tx Alpha Rolloff of 20% selected)
Command or Query.
Invert Transmit Clock, where:
s=Defines which interface slot ( 1 or 2 )
x=Invert Transmit Clock, where:
0=Normal
1=Inverted
Note: Command valid Only with HSSI)
Example: TCI = 11 (Inverted TX Clock, Slot 1 selected)
A–15
MN/CDM710.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
RNE? RNE? RNE={CR}ABCddmmyyhhmm
RNE* ss{CR}ABCddmmyyhhmmss{
RNE# CR}ABCddmmyyhhmmss{CR}
ABCddmmyyhhmmss
{CR}ABCddmmyyhhmmss
TAB= TAB?s TAB=sx
TAB?
TAB*
TAB#
TAR= TAR? TAR=x
TAR?
TAR*
TAR#
TCI = TCI?s TCI =sx
TCI? (See Description of
TCI * Arguments)
TCI #
Revision 11
