CDM-710 Broadcast Satellite Modem
Front Panel Operation
5.3.4.4

(INFO:) Intfc1 (CDI-40 ASI or CDI-60 HSSI Interfaces Only)

The appearance of the Intfc 1 info screen depends on whether a CDI-40 ASI Interface is installed,
or a CDI-60 HSSI Interface is installed:
Intfc 1: ASI J4
Tx-188
Intfc 1: HSSI Tx Rx
188 Rx-Sat
For the CDI-40 ASI Interface, the information provided may be broken down as follows:
Value
Intfc 1: ASI
J4
Wide
Tx-188
Rx-188
For the CDI-60 HSSI Interface, the information provided may be broken down as follows:
Value
Intfc 1: HSSI
Tx
Rx
188
Rx-Sat
Wide
Rx-188
Description
Indicates that the CDI-40 ASI (Asynchronous Serial Interface) per DVB is installed
in Slot 1.
Indicates the assigned Tx Data Input Connector as J4 or J5.
Indicates the assigned Bandwidth Selection ASI (Tx Data) as Wide or Narrow.
Identifies the selected Transport Stream Frame Type as 188 (188 byte frame) or
204 (204 byte frame).
Identifies the selected Transport Stream Frame Type as 188 (188 byte frame) or
204 (204 byte frame).
Description
Indicates that the CDI-60 HSSI (High-Speed Serial Interface) is installed in Slot 1.
Displays when the Tx side of the interface has been Enabled.
Displays when the Rx side of the interface has been Enabled.
Identifies the selected sync mode/frame type as 188 (188 byte frame) or 204 (204
byte frame).
Identifies the selected source that clocks the output of the Rx Buffer, for the
purpose of delivering data to the Rx port at the user interface: Rx-Sat, Tx-Terr, or
Internal.
