CDM-710 Broadcast Satellite Modem
Front Panel Operation

(CONFIG: Rx) Eb/No

Eb/No Alarm: Threshold
Alarm/Fault
Select Threshold, Alarm/Fault, or Masked using the
(CONFIG: Rx) Eb/No
Eb/No Alarm Threshold:
2.0 dB
The range of Eb/No alarm point values is from 0.1 to 16.0 dB. If the Eb/No falls below the
selected value, a receive traffic fault is generated.
To edit the threshold, use the
arrow keys to change the value of that digit. Press
(CONFIG: Rx) Eb/No
Eb/No Alarm:
Alarm
The available choices define the Eb/No Alarm as an Alarm, as a Fault, or to completely
Mask the alarm. This choice affects operation in 1:1 redundancy.
Select Alarm, Fault, or Masked using the

(CONFIG: Rx) PLL

Carrier PLL Bandwidth:
1x 2x
This selection is sometimes useful when high phase noise is present. Select 1x or 2x using the
arrow keys, then press
( E)
Threshold
Masked ( ▲ ▼ E)
arrow keys to select the digit to be edited, then use the ▲ ▼
Alarm/Fault
Fault Mask
( E)
. 1x is the normal operating mode.
ENTER
arrow keys, then press
when done.
ENTER
( E)
arrow keys, then press
5–23
Revision 11
MN/CDM710.IOM
.
ENTER
.
ENTER
