CDM-710 Broadcast Satellite Modem
Front Panel Operation
5.3.6.6

(UTIL:) FAST

FAST: Cnfg
MainBoard S/N: 333333333
Comtech EF Data's FAST (Fully Accessible System Topology) system permits the purchase and
installation of options through special authorization codes, entered remotely or through the front
panel. FAST allows immediate implementation of different options through the user interface keypad.
All FAST options are available through the basic platform unit.
Select Cnfg or View using the

(FAST:) Cnfg (Configuration)

FAST Configuration
Edit Code
Select Edit Code or Demo Mode using the
(FAST:) Cnfg
Edit 20 digit FAST Code:
00000000000000000000 ENT
Enter the code carefully on the bottom line by using the
character position, then editing the character in that position by using the
the 20-digit FAST Code is correctly compiled, press
The CDM-710 responds with "Configured Successfully" if the new FAST option is accepted.
If, however, the code as entered is not accepted, the following message displays:
Fast Code Rejected!
Re-enter the code using the previously described code entry procedure. Should the message
display again, contact Comtech EF Data Customer Support for further assistance.
(FAST:) Cnfg
FAST Demo Mode: Off On
3888000 seconds remain
The Demo Mode enables all FAST options for a limited time. For newer units with the latest
firmware version, the Demo Mode lasts 45 days.
Select Off or On using the
remaining on the demo counter. The demo time may be paused either by turning demo mode off,
or by unplugging the unit. However, whenever the unit is turned back on, the demo counter will
resume.
View
arrow keys, then press
Demo Mode
Code
(ENTER OR CLEAR)
Demo Mode
arrow keys, then press
ENTER
arrow keys, then press
.
ENTER
ENTER
5–54
Revision 11
MN/CDM710.IOM
.
.
ENTER
arrow keys to move to each
arrow keys. Once
. The display indicates the time
