3 INTERNAL MEMORY

3 Internal Memory
This chapter explains the internal memory configuration.
Figure 3.1 shows the S1C33L03 memory map.
Area 2 is used in debug mode only and it cannot be accessed in user mode (normal program execution status).

3.1 ROM and Boot Address

The S1C33L03 does not have a built-in ROM. The boot address is fixed at 0x0C00000, and so external ROM/Flash
should be used in Area 10.
For setting up Area 10, refer to the "BCU (Bus Control Unit)" in "S1C33L03 FUNCTION PART" in this manual.
A-14
Area Address
Areas 18–11
0xFFFFFFF
0x1000000
Area 10
0x0FFFFFF
0x0C00000
Areas 9–7
0x0BFFFFF
0x0400000
Area 6
0x03FFFFF
0x0300000
Areas 5–4
0x02FFFFF
0x0100000
Area 3
0x00FFFFF
0x0080000
Area 2
0x007FFFF
0x0060000
Area 1
0x005FFFF
0x0050000
0x004FFFF
0x0040000
0x003FFFF
0x0030000
Area 0
0x002FFFF
0x0002000
0x0001FFF
0x0000000
Figure 3.1 Memory Map
