D D To send/read memory contents
When sending or reading memory contents, additional
code must be added to appoint the memory channel
as follows.
➥ Additional code: 0000–0101 (0100=P1, 0101=P2)
D D Band stacking register
To send or read the desired band stacking register's
contents, combined codes of the frequency band and
register codes as follows are used.
For example, when sending/reading the oldest con-
tents in the 21 MHz band, the code "0703" is used.
• Frequency band code
Code Frequency band Frequency range (unit: MHz)
01 1.8
02 3.5
03 7
04 10
05 14
06 18
07 21
08 24
09 28
10 50
12 GENE
• Register code
Code Registered number
01
02
03
D D Codes for memory keyer contents
To send or read the desired memory keyer contents,
the channel and character codes as follows are used.
• Channel code
Code Channel number
01
02
03
04
1.800000– 1.999999
3.400000– 4.099999
6.900000– 7.499999
9.900000–10.499999
13.900000–14.499999
17.900000–18.499999
20.900000–21.499999
24.400000–25.099999
28.000000–29.999999
50.000000–54.000000
Other than above
1 (latest)
2
3 (oldest)
M1
M2
M3
M4
• Character's code
Character ASCII code
0–9 30–39
A–Z 41–5A
space 20
/ 2F
? 3F
, 2C
. 2E
^ 5E
✱
2A
D D Codes for memory name, opening
message and clock 2 name contents
To send or read the desired memory name settings,
the character codes, instructed codes for memory
keyer contents as above, and follows are additionally
used.
• Character's code— Alphabetical characters
Character ASCII code
a–z 61–7A
• Character's code— Symbols
Character ASCII code
!
$
&
?
'
+
:
=
>
)
]
}
_
@
14-9
CONTROL COMMAND
Description
Numerals
Alphabetical characters
Word space
Symbol
Symbol
Symbol
Symbol
e.g., to send , enter ^4254
BT
Inserts contest number (can be
used for 1 channel only)
Character ASCII code
—
Character ASCII code
21 #
24 %
26 ¥
3F "
27 `
2B –
3A ;
3D <
3E (
29 [
5D {
7D |
–
5F
40
14
—
23
25
5C
22
60
2D
3B
3C
28
5B
7B
7C
7E
