Icom IC-7800 Instruction Manual page 90

5
FUNCTIONS FOR RECEIVE
D D Scope set mode (continued)
Set the scope edge frequencies for fix mode scope
when 26 to 30 MHz band is selected.
Set the scope edge frequencies for fix mode scope
when 30 to 45 MHz band is selected.
Set the scope edge frequencies for fix mode scope
when 45 to 60 MHz band is selected.
• Set the frequencies within 26.000 to 30.000 MHz
range in 1 kHz steps.
Up to 500 kHz band width can be specified, so
either edge frequency will be set to the differ-
ence between higher and lower frequencies
become 5 to 500 kHz automatically while setting
another edge frequency.
• Set the frequencies within 30.000 to 45.000 MHz
range in 1 kHz steps.
Up to 500 kHz band width can be specified, so
either edge frequency will be set to the differ-
ence between higher and lower frequencies
become 5 to 500 kHz automatically while setting
another edge frequency.
• Set the frequencies within 45.000 to 60.000 MHz
range in 1 kHz steps.
Up to 500 kHz band width can be specified, so
either edge frequency will be set to the differ-
ence between higher and lower frequencies
become 5 to 500 kHz automatically while setting
another edge frequency.
5-8
