Page 13: About This Document
Nortel Networks representative to verify that the hardware and software described are supported in your area. Subject This Nortel Networks Publication (NTP) is a reference tool for first-time installation of a Small System. In addition to complete installation instructions, it includes information about Survivability and the Central Answering Position (CAP) feature.
Page 14: Applicable Systems
This NTP contains information about systems, components, and features that are compatible with Succession 3.0 Software. For more information on legacy products and releases, click the Technical Documentation link under Support on the Nortel Networks home page: http://www.nortelnetworks.com/ Applicable systems This document applies to the following systems: •...
Page 15: Intended Audience
About this document Page 15 of 562 Small System that supports an upgrade path to a Succession 1000M Small System. Table 1 Meridian 1 systems to Succession 1000M systems Maps to this This Meridian 1 system... Succession 1000M system Meridian 1 Option 11C Chassis Succession 1000M Chassis Meridian 1 Option 11C Cabinet Succession 1000M Cabinet...
Page 16 Page 16 of 562 About this document The following systems are referred to generically as “Small System”: • Meridian 1 Option 11C Chassis • Meridian 1 Option 11C Cabinet • Succession 1000M Chassis • Succession 1000M Cabinet The following systems are referred to generically as “Chassis system”: •...
Page 17: Related Information
About this document Page 17 of 562 Table 2 North American to UK terms (Part 2 of 2) North American term UK term or meaning telephone station extension telephone TIE trunks private circuits toll trunks exchange lines 1.5 Mbit, 24 channel digital carrier (North American equivalent to Megastream) WATS, FEX (FX1 and FX2), CSA Alternative public vendor network services...
Page 18 Page 18 of 562 About this document NTPs The following NTPs are referenced in this document: • Small System: Description (553-3011-010) • Small System: Planning and Engineering (553-3011-120) • Small System: Upgrade Procedures (553-3011-258) • Small System: Maintenance (553-3011-500) • ISDN Primary Rate Interface: Installation and Configuration (553-3001-201) •...
Page 19 BIX In-Building Cross-Connect System Material Installation and Servicing (631-4511-200) Online To access Nortel Networks documentation online, click the Technical Documentation link under Support on the Nortel Networks home page: http://www.nortelnetworks.com/ CD-ROM To obtain Nortel Networks documentation on CD-ROM, contact your Nortel Networks customer representative.
Page 20 Page 20 of 562 About this document 553-3011-210 Standard 1.00 October 2003...
Page 21: Cabinet System Equipment
Page 21 of 562 Cabinet system equipment Contents This section contains information on the following topics: Introduction ..........Cabinets.
Page 22: Introduction
Page 22 of 562 Cabinet system equipment Introduction This chapter identifies major components of Cabinet systems. Identification codes are given where appropriate. For a description of the Succession Signaling Server for a Succession 1000M Cabinet, refer to Signaling Server: Installation and Configuration (553-3001-212).
Page 23 Cabinet system equipment Page 23 of 562 such as a Power Failure Transfer Unit (PFTU). The SDI connector in the main and IP expansion cabinets interfaces three SDI ports using a three-port SDI cable. The Ethernet connector in the main cabinet provides a 10 Mbps Ethernet port.
Page 24: Power Supplies
Page 24 of 562 Cabinet system equipment Cooling The NTAK11 cabinet is designed to permit natural convection cooling. WARNING Do not block cabinet ventilation. Poor ventilation could cause the system to overheat and damage system components, which may result in service interruption. Power supplies Two types of power supply are available for the system: •...
Page 25 Cabinet system equipment Page 25 of 562 Figure 3 AC/DC power supply Small System Installation and Configuration...
Page 26: Reserve Power
Page 26 of 562 Cabinet system equipment Reserve power CAUTION — Service Interruption If the NTDK70 or NTDK78 ac/dc power supply is powered down while it is operating on dc reserve power from a battery backup unit, the Cabinet system cannot be powered up again until ac power is restored.
Page 27 Cabinet system equipment Page 27 of 562 Figure 4 NTAK75 battery box Small System Installation and Configuration...
Page 28: Common Equipment Circuit Cards And Components
Page 28 of 562 Cabinet system equipment Figure 5 NTAK76 battery box Common equipment circuit cards and components The circuit cards described in this section can be used in the main cabinet and the IP expansion cabinets, where indicated. Small System Controller card The NTDK20 Small System Controller (SSC) card includes: •...
Page 29: Software Daughterboard
Cabinet system equipment Page 29 of 562 PC Card interface The NTDK20 SSC card has a 2-slot PC Card interface socket located on its faceplate. You can insert a Software Delivery card (PC Card) into the socket. Use the PC Card for software upgrades on an existing Cabinet system. You can also use this socket for creating an external backup copy of the customer database.
Page 30 Page 30 of 562 Cabinet system equipment Figure 6 The NTDK83 IP Daughterboard 553-3011-210 Standard 1.00 October 2003...
Page 31 Cabinet system equipment Page 31 of 562 Figure 7 The NTTK02 IP Daughterboard Figure 8 The NTDK99 Daughterboard Small System Installation and Configuration...
Page 32: Fiber Expansion Equipment
Page 32 of 562 Cabinet system equipment Figure 9 The NTTK01 Daughterboard Fiber Expansion equipment For non-IP expansion, Fiber Expansion Daughterboards in the main cabinet and Fiber Receiver cards in expansion cabinets allow for fiber connectivity between the main cabinet and up to four fiber expansion cabinets or chassis. Fiber Receiver card There are three versions of the Fiber Receiver card.
Page 33 Cabinet system equipment Page 33 of 562 Fiber Expansion Daughterboard Single-port Fiber Expansion Daughterboard The Single-port Fiber Expansion Daughterboards and their Fiber Receiver card counterparts are: • The NTDK22 Fiber Expansion Daughterboard. Its Fiber Receiver card counterpart is the NTDK23. •...
Page 34 Page 34 of 562 Cabinet system equipment Figure 11 The NTDK24 Daughterboard Dual-port Fiber Expansion Daughterboard The Dual-port Fiber Expansion Daughterboards and their Fiber Receiver counterparts are: • The NTDK84 Dual-port Fiber Expansion Daughterboard. Its Fiber Receiver card counterpart is the NTDK23. •...
Page 35 Cabinet system equipment Page 35 of 562 Figure 12 The NTDK84 Daughterboard Figure 13 The NTDK85 Daughterboard Small System Installation and Configuration...
Page 36: Security Device
Page 36 of 562 Cabinet system equipment Security device A security device is required on the NTDK20 SSC card of the main and all IP expansion cabinets. There are two types of security devices: • The NT_STD required in the main cabinet •...
Page 37 Cabinet system equipment Page 37 of 562 Figure 14 Daughterboards and security device on the NTDK20 SSC card Security device Software Daughterboard Fiber Expansion Daughterboard in top connector (Fiber 1) Fiber Expansion Daughterboard in bottom connector (Fiber 2) Small System Installation and Configuration...
Page 38: Sdi/Dch Card
Page 38 of 562 Cabinet system equipment SDI/DCH card The NTAK02 is an optional SDI/DCH card that provides four SDI ports for various applications. TDS/DTR card The NTAK03 TDS/DTR card provides tone transmission and detection plus two SDI ports. Tone detector cards The NT5K20 and NT5K48 Tone detector cards provide DTMF or DT detection.
Page 39: Peripheral Equipment Cards
Cabinet system equipment Page 39 of 562 Table 3 Common equipment packs supported in Cabinet system IP cabinets (Part 2 of 2) Pack Daughterboard Supported application MISP (NTBK22) CC (NTAK20) MISP BRI processor clock controller (stratum 3/4) SDI_DCH (NTAK02) only DCH is supported; ESDI, AML, TTY are not supported Card Option Mail is not sup-...
Page 40: Telephones And Attendant Consoles
Page 40 of 562 Cabinet system equipment • NT7D16 Data Access Card (DAC) • NTAG26 Extended Multi-frequency Receiver (XMFR) card Telephones and attendant consoles Supported telephones are as follows: • Analog (500/2500-type) telephones with or without message waiting lamps. • Meridian Digital Telephones (M2006, M2008, M2009, M2018, M2112, M2216, M2616 and M3000).
Page 41 Cabinet system equipment Page 41 of 562 Table 4 Cable and wire specifications (Part 2 of 3) Cables and Wires Purpose / Description Glass Fibre Optic Cable used on 100BaseF Must be supplied locally by a facilities provider. Expansion daughterboards (Multimode only) Length up to 2 km.
Page 42: Miscellaneous Items
Page 42 of 562 Cabinet system equipment Table 4 Cable and wire specifications (Part 3 of 3) Cables and Wires Purpose / Description NTAK19 cable SDI cable used with the NTAK02 and NTAK03 circuit cards. A0601397 F-F DCE to DTE converter, or May be required when connecting SDI ports to A0601396 F-M DCE to DTE converter TTYs, modems, etc.
Page 43 Cabinet system equipment Page 43 of 562 • modems or Data Communication Equipment (DCE) for remote access to the system • on-site Data Terminating Equipment (DTE) or teletypewriter (TTY) terminal for accessing the system • connecting blocks for the cross-connect terminal •...
Page 44 Page 44 of 562 Cabinet system equipment Figure 15 EMC grounding clip 553-3011-210 Standard 1.00 October 2003...
Page 45: Chassis System Equipment
Page 45 of 562 Chassis system equipment Contents This section contains information on the following topics: Introduction ..........Main components of the Chassis system.
Page 46: Main Components Of The Chassis System
Page 46 of 562 Chassis system equipment Main components of the Chassis system NTDK91 chassis and NTDK92 chassis expander A Chassis system comprises an NTDK91 chassis plus an optional NTDK92 chassis expander. The chassis can be connected to the chassis expander to increase line capacity.
Page 47 Chassis system equipment Page 47 of 562 Cable connectors 25-pair cables connect cards to the cross-connect terminal. Connectors for these cables are on the back of the chassis and the chassis expander. See Figure 16 on page Figure 16 25-pair cable connectors on the back of the chassis 25-pair connectors The Auxiliary (AUX), Serial Data Interface (SDI), and Ethernet connectors...
Page 48 Page 48 of 562 Chassis system equipment The back of the chassis also contains connectors for connecting the chassis and the chassis expander. These connectors are for the DS-30X and CE-MUX connections. See Figure 17 on page The power connector is at the back of the chassis on the upper left-hand side. See Figure 17 on page 48.
Page 49 Chassis system equipment Page 49 of 562 Figure 18 on page 49 shows the connectors on the back of the chassis expander. Figure 18 Connectors on the back of the chassis expander Power cord connector DS-30X CE-MUX connector connector 25-pair connectors Cooling The NTDK91 chassis and the NTDK92 chassis expander have forced air...
Page 50 Page 50 of 562 Chassis system equipment Power supply The universal power supply in the Chassis system uses ac input. The power supply is factory installed and not customer replaceable. The Chassis system does not support dc input. Power switch There is a power switch on the front of the NTDK91 chassis and the NTDK92 chassis expander.
Page 51 Chassis system equipment Page 51 of 562 Table 5 Power supply DIP switch settings Ringing Frequency (Hz) Ringing Amplitude (Vrms) Message Waiting Lamp (VDC) -120 -150 Disable Switch Switch Switch Setting Setting Setting NOT USED Table 6 Asia Pacific/CALA power supply DIP switch settings In the Asia Pacific/CALA region, usage of the high voltage Message Waiting Lamp is optional.
Page 52 Page 52 of 562 Chassis system equipment Table 8 North American power supply DIP switch settings In North America, usage of the high voltage Message Waiting Lamp is optional and requires -150 V when enabled. The following table shows the settings for 20 Hz, 86 V, and the Message Waiting Lamp is disabled.
Page 53 Chassis system equipment Page 53 of 562 Figure 19 shows the power switch, power status indicator, and DIP switch settings. Figure 19 Front of chassis Power status Power indicator switch DIP switch settings Reserve power supply You can use an Uninterruptible Power Supply (UPS) to provide a backup power supply for the NTDK91 and the NTDK92 chassis.
Page 54 Page 54 of 562 Chassis system equipment cards. For more information about other circuit cards supported on the Chassis system, refer to “Installing optional circuit cards” on page 217. NTDK20 SSC card and components The NTDK20 SSC card includes: • a Central Processing Unit (CPU) that handles call processing •...
Page 55 Chassis system equipment Page 55 of 562 Ethernet port. This connector is for a standard 15-pin AUI interface for a MAU. Digitone Receiver, tone generation, tone detection functions The NTDK20 SSC card provides the following Digitone and other tone functions related to tone: •...
Page 56 Page 56 of 562 Chassis system equipment IP expansion For IP connectivity, four IP daughterboards are available: • The NTDK83 dual-port 100BaseT • The NTTK02 dual-port 100BaseF • The NTDK99 single-port 100BaseT • The NTTK01 single-port 100BaseF Fiber expansion For non-IP expansion, Fiber Expansion Daughterboards in the chassis and Fiber Receiver cards in the expansion chassis allow for fiber connectivity between the chassis and up to four fiber expansion chassis or cabinets.
Page 57 Chassis system equipment Page 57 of 562 Telephones and attendant consoles The following is a list of the telephones and attendant consoles supported by the Chassis system: • Analog (500/2500-type) telephones, with or without message waiting lamps • Meridian Digital Telephones (M2006, M2008, M2009, M2018, M2112, M2216, M2616, and M3000) •...
Page 58 Page 58 of 562 Chassis system equipment Cables and wires Table 9 lists Chassis system cable kits and their contents. Table 9 Chassis system cable kits Cable or wire Purpose/description NTDK88 Main cable kit NTBK48 three-port SDI cable Connects equipment, such as TTYs and modems, to the Chassis system.
Page 59 Chassis system equipment Page 59 of 562 Table 10 lists the ac power cord kits for various countries. These cords connect a system chassis to a commercial ac power source. Table 10 AC power cord kits Country / Region Cord Voltage North America NTTK14...
Page 60 Page 60 of 562 Chassis system equipment Table 11 Chassis system miscellaneous cables and wires (Part 2 of 3) Cable and Wire Purpose / Description NTAK19 cable SDI cable used with the NTAK02 and NTAK03 circuit cards (see Note 1). NTAK1108/1118 9- to 25-pin RS232 Connects SDI ports and terminals (see Note 1).
Page 61 Chassis system equipment Page 61 of 562 Table 11 Chassis system miscellaneous cables and wires (Part 3 of 3) Cable and Wire Purpose / Description #8 AWG (10 mm ) insulated ground wire Connects a chassis to a building ground source. (Germany) Cross-connect wire Makes cross connections at the cross-connect...
Page 62 Page 62 of 562 Chassis system equipment • additional Modem Eliminator (NULL Modem without hardware handshaking). The A0601397 converter may be required to interface the DTE to the system. • industry-standard Ethernet Medium Access Unit (MAU) 553-3011-210 Standard 1.00 October 2003...
Page 63: Regulatory Information
Page 63 of 562 Regulatory information Contents This section contains information on the following topics: Introduction ..........Notice for United States installations .
Page 64: Introduction
Page 64 of 562 Regulatory information Introduction This chapter includes regulatory information for American, Canadian and International installations pertinent to the Small System installation. WARNING The fiber-optic interface product used in the Small System is considered safe. However, as a precaution do not look directly at the optical port or the end of fiber-optic cable.
Page 65 Regulatory information Page 65 of 562 Importance of Ringer Equivalence Number The FCC regulation label includes the Ringer Equivalence Number (REN). This number represents the electrical load applied to your telephone line after you plug the PBX into the wall jack. The telephone line for your premises does not operate correctly if the total ringer load exceeds the capability of the telephone company’s Central Office (CO) equipment.
Page 66: Notice For Canadian Installations
Page 66 of 562 Regulatory information Notice for Canadian installations The Industry Canada — formerly called the Canadian Department of Communications — label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements. Industry Canada does not guarantee that the equipment will operate to the user’s satisfaction.
Page 67: Notice For International Installations
Regulatory information Page 67 of 562 DANGER OF ELECTRIC SHOCK Do not attempt to make electrical ground connections yourself. Contact your local electrical inspection authority or electrician to make electrical ground connections. Notice for International installations If there is insufficient planning or technical information present for your country of operation, contact your regional telecommunications distributor or authority for assistance.
Page 68: Electromagnetic Compatibility
Page 68 of 562 Regulatory information Electromagnetic compatibility Table 12 shows the Electromagnetic Compatibility (EMC) specifications for the Small System. Table 12 Small System EMC specifications for Class A devices (Part 1 of 2) Jurisdiction Standard Description United States FCC CFR 47 FCC Rules for Radio Frequency Devices Part 15 (see Note 1)
Page 69 Regulatory information Page 69 of 562 Table 12 Small System EMC specifications for Class A devices (Part 2 of 2) Jurisdiction Standard Description Taiwan CNS 13438 Limits and methods of measurement of radio disturbance characteristics of information technology equipment Note 1: FCC CFR 47 Part 15.21 statement: “Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
Page 70: Canadian And Us Network Connections
Small System. Note: Table 13 includes columns for system port identification, Facility Interface Code (FIC), Service Order Code (SOC), USOC jack identification and associated Nortel equipment part numbers. Table 13 Network connection specifications (Part 1 of 2) Facility...
Page 71 Regulatory information Page 71 of 562 Table 13 Network connection specifications (Part 2 of 2) Facility Service Manufacturer Interface Order Network network interface Ports MTS/WATS Code Code jacks port designation 2-Wire, LSA, R-B 02RV2-T 9.0F 0.0B RJ21X NT8D14 (2-Wire, Local Switched CA21X* Access, Reverse-Battery) 1.544 Mbps OSI, SF...
Page 72 Page 72 of 562 Regulatory information FCC compliance: Registered equipment for Direct Inward Dial calls Equipment registered for Direct Inward Dial (DID) calls must provide proper answer supervision. Failure to meet this requirement is a violation of part 68 of the FCC’s rules. Refer to Features and Services (553-3001-306) for more information.
Page 73: Important Safety Instructions
Page 73 of 562 Important safety instructions Contents This section contains information on the following topics: Symbols you must recognize....... . . Safety instructions when installing telephone equipment .
Page 74: Safety Instructions When Installing Telephone Equipment
Page 74 of 562 Important safety instructions Safety instructions when installing telephone equipment The following are safety instructions for installing telephone equipment: Never install telephone wiring during a lightning storm. Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.
Page 75 Important safety instructions Page 75 of 562 Some equipment has a three-wire grounding plug. This type of plug has a third grounding pin. As a safety feature, the plug only fits into an isolated ground outlet. If you cannot insert the plug completely into the outlet, contact your electrician to replace the outlet.
Page 76: Fiber-Optic Cable Handling Procedures
Page 76 of 562 Important safety instructions 14 Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning. 15 Do not use the telephone to report a gas leak in the vicinity of the leak. Fiber-optic cable handling procedures WARNING The fiber-optic interface product used in the...
Page 77 Important safety instructions Page 77 of 562 • NTDK79 3 km Fiber Expansion Daughterboard (Single Mode glass fiber-optic cable) • NTDK80 3 km Fiber Receiver card (Single Mode glass fiber-optic cable) Note: Fiber-optic cable is the only type of interconnection cable supported on a fully expanded Chassis system.
Page 78 Page 78 of 562 Important safety instructions 553-3011-210 Standard 1.00 October 2003...
Page 79: Bracing Against Earthquakes
Page 79 of 562 Bracing against earthquakes Contents This section contains information on the following topics: Introduction ..........Method for earthquake bracing .
Page 80 Page 80 of 562 Bracing against earthquakes Procedure 1 Earthquake bracing method Determine the size of the backboard. You need a backboard that is large enough to hold all of the components that you will install on the wall. To determine the backboard size, refer to Small System: the wall plan that you developed using the guidelines in Planning and Engineering...
Page 81 Bracing against earthquakes Page 81 of 562 between wall studs. Wall stud spacing must be within the range listed in Table 15. • The required wall stud sizes for wood and metal stud walls. Table 15 Stud spacing Stud spacing 16 in.
Page 82 Page 82 of 562 Bracing against earthquakes Table 17 lists the maximum wall heights for different sizes of wall studs with 16-inch spacing. Table 17 Maximum wall heights for stud sizes — 16-inch spacing Wall studs Maximum height of wall Wood Studs 2 X 4 (DF #2) 11 ft (3300 mm)
Page 83 Bracing against earthquakes Page 83 of 562 Table 18 lists the maximum wall heights for different sizes of wall studs with a 24-inch spacing. Table 18 Maximum wall heights for stud sizes — 24-inch spacing Wall studs Maximum height of wall Wood Studs 2 X 4 (DF #2) 10 ft (3000 mm)
Page 84 Page 84 of 562 Bracing against earthquakes Determine where to place the fasteners. Refer to Figures 20 through 22 if you need help with where to place the fasteners on the backboard. In each figure, the minimum (2 ft by 6 ft) and maximum (4 ft by 8 ft) sizes of the backboard are used as examples.
Page 85 Bracing against earthquakes Page 85 of 562 Figure 20 Plywood fastener locations for wood and metal stud walls — 16 inch spacing Small System Installation and Configuration...
Page 86 Page 86 of 562 Bracing against earthquakes Figure 21 Plywood fastener locations for wood and metal stud walls — 24 inch spacing 553-3011-210 Standard 1.00 October 2003...
Page 87 Bracing against earthquakes Page 87 of 562 Figure 22 Plywood fastener locations for concrete and masonry walls Small System Installation and Configuration...
Page 88 Page 88 of 562 Bracing against earthquakes Continue with Small System installation. Now that you have securely fastened the backboard to the wall, you can continue with the Small System installation. End of Procedure 553-3011-210 Standard 1.00 October 2003...
Page 89: Preparing For Installation
Page 89 of 562 Preparing for installation Contents This section contains information on the following topics: Introduction ..........Tools checklist.
Page 90: Readiness Checklist
Page 90 of 562 Preparing for installation appropriate cable terminating tools a drill for making lead holes for screws Readiness checklist Have you: read all safety instructions in “Important safety instructions” on page made sure that you received all the equipment that you ordered? made sure your area meets all environmental requirements? checked for all power requirements? checked for correct grounding facilities?
Page 91: Installing The Cabinet System
Page 91 of 562 Installing the Cabinet system Contents This section contains information on the following topics: Introduction ..........Installing a new Cabinet system .
Page 92: Installing A New Cabinet System
Page 92 of 562 Installing the Cabinet system Make sure you have read and completed all instructions contained in the prior chapters of this guide and in the chapters on system and site planning in Small System: Planning and Engineering (553-3011-120). CAUTION WITH ESDS DEVICES Wear the antistatic wrist strap provided in the bottom of the cabinet before handling the power supplies or other...
Page 93 Installing the Cabinet system Page 93 of 562 Install the NTDK20 Small System Controller (SSC) card and daughterboards. Refer to “Installing Small System Controller and Fiber Receiver cards” on page 187. Install the remaining circuit cards. Refer to “Installing optional circuit cards”...
Page 94 Page 94 of 562 Installing the Cabinet system For fiber connectivity, go to step 4. For IP connectivity, do one of the following: • For point-to-point 100BaseF connectivity, go to step 5. • For point-to-point 100BaseT connectivity, go to step 6. •...
Page 95 Installing the Cabinet system Page 95 of 562 IP daughterboards. The two A0817052 fiber cables are usually connected to the customer’s LAN. • Use the NTDK8305 2-meter STP CAT 5 extension cable to connect the main and IP expansion cabinets using 100BaseT IP daughterboards.
Page 96 Page 96 of 562 Installing the Cabinet system Figure 24 Cable ends for 100BaseT IP connectivity NTDK8305 cable ends Main power hook-up. Connect the external power supply, if not already done. If this system uses a commercial ac power supply, the power outlet should be tested to make sure that the correct voltage is present before plugging the power cord in the outlet.
Page 97 Installing the Cabinet system Page 97 of 562 Set the circuit breaker on the battery backup unit to ON (if the system has reserve power). Note: A system equipped with the NTDK70 or NTDK78 ac/dc power supply and a battery backup unit will continue to operate on dc reserve power if the ac supply fails.
Page 98: Expanding An Existing System
Page 98 of 562 Installing the Cabinet system 14 Install (if not previously installed) and activate the telephones. Refer to “Connecting the telephones” on page 333. 15 Connect the trunks to the system as described in “Connecting the trunks” page 359.
Page 99: Reconfiguring A System
Installing the Cabinet system Page 99 of 562 Connect the trunks to the system as described in “Connecting the trunks” page 359. Perform a system backup in LD 43. 10 Install any remaining equipment, such as external alarms. Refer to “Connecting an external alarm”...
Page 100: Cabinet And Chassis System Mix-And-Match Configuration
Page 100 of 562 Installing the Cabinet system Scenario 2: Adding a fourth expansion cabinet The existing main cabinet is equipped with two 10 m dual-port expansion daughterboards connecting to three expansion cabinets. A remote expansion cabinet is to be added requiring a 3 km expansion daughterboard. Although one of the existing daughterboards has a port available, it can only be connected to a cabinet within 10 m (33 ft).
Page 101 Installing the Cabinet system Page 101 of 562 Figure 26 EMC grounding clip for the cabinet EMC grounding clip Stiffener rail Small System Installation and Configuration...
Page 102 Page 102 of 562 Installing the Cabinet system Figure 27 EMC grounding clip for the chassis 100BaseT cables secured with a cable tie Grounding clip Figure 28 on page 103 shows an example “mix-and-match” configuration in which the main cabinet of a Cabinet system uses both fiber and IP cabling to connect two expansion cabinets and one Chassis system (chassis with chassis expander).
Page 103 Installing the Cabinet system Page 103 of 562 Figure 28 Cabinet and Chassis system mix-and-match expansion configuration Small System Controller Equipped with dual port Fiber Expansion Daughterboard and IP Expansion Daughterboard Option 11C Chassis Option 11C Chassis Expander Small System Controller Equipped with IP Expansion Daughterboard 553-AAA0466...
Page 104: Expansion Cabinet As A Power Shelf For Auxiliary Processors
Page 104 of 562 Installing the Cabinet system Expansion cabinet as a power shelf for auxiliary processors Follow Procedure 5 to add an expansion cabinet used as a power shelf for auxiliary processor units (such as Max IPE). Procedure 5 Adding an expansion cabinet as a stand-alone power shelf Locate the carton containing the expansion cabinet.
Page 105 Installing the Cabinet system Page 105 of 562 Put on the wrist strap provided in the bottom of the cabinet and install the power supply with the circuit breaker at the OFF position. If this is an ac powered system, plug in the power supply cord in the commercial power supply receptacle and into the power supply.
Page 106 Page 106 of 562 Installing the Cabinet system Figure 29 Ground/Earth connection Ground/Earth connection Ground/Earth wire in third groove 553-3011-210 Standard 1.00 October 2003...
Page 107: Installing The Chassis System
Page 107 of 562 Installing the Chassis system Contents This section contains information on the following topics: Summary of installation procedures ......Summary of installation procedures The following list provides a high-level summary of installation procedures for the Succession 1000M Chassis or Meridian 1 Option 11C Chassis.
Page 108 Page 108 of 562 Installing the Chassis system If your Small System requires earthquake bracing, refer to “Bracing against earthquakes” on page For your system to be braced against earthquakes, you must install the chassis on a wall in a vertical position. Locate the box containing the Small System equipment.
Page 109 Installing the Chassis system Page 109 of 562 10 If you require a UPS, install the UPS according to the manufacturer’s instructions. 11 If you have not already done so, remove the faceplate of the chassis. Loosen the quick-release screws on the faceplate of the chassis. See Figure 30 on page 109.
Page 110 Page 110 of 562 Installing the Chassis system 12 Install the Small System Controller (SSC) card and the 48-port Digital Line Card. Install the security device on the NTDK20EA SSC card. Install the SSC card in CPU slot 0 of the chassis. See “Main cabinet and chassis NTDK20 SSC card installation”...
Page 111 Installing the Chassis system Page 111 of 562 18 If Ethernet is required, insert an industry-standard Medium Access Unit (MAU) directly into the Ethernet connector at the back of the chassis. The Chassis system does not include the MAU. Insert the Ethernet cable into this MAU.
Page 112 Page 112 of 562 Installing the Chassis system 28 Replace the faceplate. Fit the brackets at the bottom of the faceplate into the raised edge at the bottom of the chassis. Move slightly to the left. See Figure 31. Figure 31 Aligning the faceplate with the chassis Fit brackets onto Fit brackets onto...
Page 113 Installing the Chassis system Page 113 of 562 Move the faceplate down so that it fits over the raised edge at the bottom of the chassis. See Figure 32. Figure 32 Fitting the front faceplate on the chassis Small System Installation and Configuration...
Page 114 Page 114 of 562 Installing the Chassis system Slide the faceplate to the right, and tighten the quick-release screws into the two holes at the top of the chassis. See Figure 33. Figure 33 Pushing the faceplate down into place to align with chassis Tighten the quick-release screws...
Page 115: Mounting The Cabinets
Page 115 of 562 Mounting the cabinets Contents This section contains information on the following topics: Introduction ..........Earthquake bracing .
Page 116: Earthquake Bracing
Page 116 of 562 Mounting the cabinets Earthquake bracing If the Small System cabinets require earthquake bracing, refer to the earthquake bracing requirements in the chapters on system and site requirements in Small System: Planning and Engineering (553-3011-120) before continuing. Wall mounting Items required To mount cabinets on a wall you need:...
Page 117 Mounting the cabinets Page 117 of 562 Procedure 6 Mounting the cabinet on a wall Note: If adding a cabinet next to an existing installed cabinet, start at step Draw a level line on the plywood backboard indicating where the mounting brackets for each system cabinet will be located.
Page 118 Page 118 of 562 Mounting the cabinets Figure 34 Brackets for horizontal expansion Alignment bracket Rest the bottom of the bracket on the line drawn for the expansion cabinet, and fasten the mounting bracket to the wall with five 1 in. #12 screws provided (or other suitable fasteners).
Page 119 Mounting the cabinets Page 119 of 562 Simultaneously slide both latches in towards the center of the cabinet. Grasp the sides of the cover and pull the top outwards, then lift it upward to remove it from the cabinet. Note: The bottom of the front cover is supported but not secured to the cabinet.
Page 120 Page 120 of 562 Mounting the cabinets Locate the two screw holes at the bottom towards the rear of the cabinet. See Figure 36 on page 120. 10 Adjust the cabinet so that it is straight and level. Fasten the bottom of the cabinet to the wall with the two 1 in.
Page 121: Floor Mounting
Mounting the cabinets Page 121 of 562 Floor mounting Items required To mount the cabinet on the floor you need: • the optional pedestal for floor mounting • four #14 screws provided to secure the cabinet to the pedestal • the equipment layout plan as developed in the chapters on system and site requirements in Small System: Planning and Engineering (553-3011-120)
Page 122 Page 122 of 562 Mounting the cabinets Figure 37 Unlocking the latches Note: The bottom of the front cover is supported but not secured to the cabinet. Be careful not to drop it. Remove the metal drip tray. Check the wrist strap in the bottom right of the cabinet. It may have come loose during transit.
Page 123 Mounting the cabinets Page 123 of 562 Figure 38 Installing the pedestal Opening for door hinge (one on each side of cabinet) Place the cabinet on the pedestal and make sure that it is properly seated. Align with the guide at the rear of the cabinet and pedestal. (Refer to Figure 39 on page 124.)
Page 124 Page 124 of 562 Mounting the cabinets Figure 39 Mounting the cabinet on the pedestal Position the cabinet according to the equipment layout plan. If an additional expansion cabinet is being installed at this site, repeat this procedure for that cabinet. End of Procedure 553-3011-210 Standard 1.00...
Page 125: Mounting The Chassis
Page 125 of 562 Mounting the chassis Contents This section contains information on the following topics: Introduction ..........Mounting in a 19-inch rack/equipment cabinet.
Page 126 Page 126 of 562 Mounting the chassis equipment layout plan and a card slot assignment plan in Small System: Planning and Engineering (553-3011-120) for additional information. Note: For a Succession 1000M Chassis system, the Succession Signaling Server must be mounted in an external 19-inch equipment rack.
Page 127: Mounting In A 19-Inch Rack/Equipment Cabinet
Mounting the chassis Page 127 of 562 Mounting in a 19-inch rack/equipment cabinet Items required To install the chassis in a 19-inch rack/equipment cabinet, you require the following items: • equipment layout plan • one left chassis guide bracket • one right chassis guide bracket •...
Page 128 Page 128 of 562 Mounting the chassis Figure 40 Typical layout for installing the chassis in a rack/equipment cabinet Space for additional data communications equipment Main P o w e r F a n Chassis Maximum O RK S NE TW of 21 in.
Page 129 Mounting the chassis Page 129 of 562 Procedure 8 Installing the chassis in a 19-inch rack/equipment cabinet Fasten the left chassis guide bracket to the left rack/equipment cabinet support. Insert two #12-24 self-tapping screws into the two middle slots in the chassis guide bracket and into the respective holes in the left rack/equipment cabinet support.
Page 130 Page 130 of 562 Mounting the chassis Attach the left ear bracket (marked with an “L”) to the holes on the left side of the chassis (near the front). Use two #8-32 machine screws. Position the ear bracket so that the four holes on the bracket flange are nearer to the back of the chassis.
Page 131 Mounting the chassis Page 131 of 562 Place the chassis on the chassis guide brackets. Carefully slide the chassis into the rack/equipment cabinet until the ear brackets come to rest against the rack/equipment cabinet support. Use the four remaining #12-24 self-tapping screws to fasten the chassis to the rack/equipment cabinet supports (two screws on each side).
Page 132: Wall Mounting In A Vertical Position
Page 132 of 562 Mounting the chassis If you want to add a chassis expander, follow the above steps. You only need to leave a small space between the chassis and the chassis expander. The air circulates from the side of the chassis. To install the chassis expander, start in the next 5u pattern of mounting holes.
Page 133 Mounting the chassis Page 133 of 562 The NTTK08 bracket kit contains all of the above items, with the exception of the equipment layout plan and the plywood. DANGER A chassis is 30 lb (13.5 kg) with circuit cards installed. Make sure that you fasten the equipment securely to the wall.
Page 134 Page 134 of 562 Mounting the chassis Figure 44 Typical layout for installing the chassis on a wall in a vertical position Leave at least Allow 24 in. (610 mm) at the top 12 in. (305 mm) for miscellaneous equipment between edge of backboard and corner of...
Page 135 Mounting the chassis Page 135 of 562 Procedure 9 Installing the chassis on a wall in a vertical position Draw the vertical center line of the chassis on the plywood backboard. Allow for clearance on the left and right of the chassis for cables and card access.
Page 136 Page 136 of 562 Mounting the chassis Fasten the chassis bracket to the back of the chassis using the four #8-32 machine screws supplied with the bracket kit. See Figure 46, which shows the chassis lying on its side. Note: Make sure that the slot feature on the chassis bracket is at the top of the chassis.
Page 137 Mounting the chassis Page 137 of 562 Fasten the chassis in position. Fasten the tabs, which extend past the bottom of the chassis, to the plywood backboard. Use the two remaining #12 wood screws from the bracket kit to fasten the tabs to the backboard. See Figure 47.
Page 138 Page 138 of 562 Mounting the chassis If you want to install a chassis expander, repeat the above steps. Refer to the equipment layout plan for the measurements and where to place the chassis expander. End of Procedure 553-3011-210 Standard 1.00 October 2003...
Page 139: Wall Mounting In A Horizontal Position
Mounting the chassis Page 139 of 562 Wall mounting in a horizontal position Items required To install the chassis on a wall in a horizontal position, you require the following items: • equipment layout plan • one left shelf bracket •...
Page 140 Page 140 of 562 Mounting the chassis Figure 48 Typical layout for installing the chassis on a wall in a horizontal position Allow 24 in. (610 mm) at the top for miscellaneous equipment Leave at least 2 in. (51 mm) between edge of backboard and corner of room...
Page 141 Mounting the chassis Page 141 of 562 Procedure 10 Installing the chassis on a wall in a horizontal position Draw two vertical lines 18.5 inches apart on the plywood backboard. Allow for clearance on the left and right of the chassis for cables and air flow.
Page 142 Page 142 of 562 Mounting the chassis Figure 49 Thumb screws on the wall shelf brackets Thumb screws for fastening the chassis to the shelf brackets Lower mounting hole 553-3011-210 Standard 1.00 October 2003...
Page 143 Mounting the chassis Page 143 of 562 Place the chassis on the shelf brackets. Carefully slide the chassis on the wall shelf brackets until it touches the chassis stops on the brackets. See Figure 50. Figure 50 Chassis stops on the wall shelf brackets Chassis stops Fasten the chassis in position using the four thumb screws, located on the...
Page 144 Page 144 of 562 Mounting the chassis Figure 51 Chassis installed on a wall in a horizontal position If you want to install a chassis expander on a wall in a horizontal position, repeat the above steps for the chassis expander. Refer to the equipment layout plan for the measurements and where to position the chassis expander.
Page 145: Connecting The Chassis Expander
Page 145 of 562 Connecting the chassis expander to the chassis Contents This section contains information on the following topics: Introduction ..........Adding a chassis expander .
Page 146 Page 146 of 562 Connecting the chassis expander to the chassis Procedure 11 Adding a chassis expander Install the chassis expander following the procedures in “Mounting the chassis” on page 125. Connect one of the NTDK95 cables from the CE-MUX connector on the back of the chassis to the CE-MUX connector on the back of the chassis expander.
Page 147 Connecting the chassis expander to the chassis Page 147 of 562 Figure 52 The chassis and chassis expander connected with the two NTDK95 CE-MUX/DS-30X bus cables DS-30X CE-MUX connection connection Install the system ground as described in “Installing the system ground” page 149.
Page 148 Page 148 of 562 Connecting the chassis expander to the chassis 553-3011-210 Standard 1.00 October 2003...
Page 149: Installing The System Ground
Page 149 of 562 Installing the system ground Contents This section contains information on the following topics: Introduction ..........Cabinets or chassis powered by the same service panel.
Page 150 Page 150 of 562 Installing the system ground Make sure you read the grounding requirements in the chapters on system and site requirements in Small System: Planning and Engineering (553-3011-120) before proceeding further. DANGER OF ELECTRIC SHOCK Proper grounding is extremely important. Failure to complete the following steps could result in a system that is: •...
Page 151: Grounding Instructions For Cabinets And Chassis
Installing the system ground Page 151 of 562 chassis cannot be powered from the same service panel, it must be grounded separately from the others back to the service panel that supplies it. For an expanded Chassis system, all chassis and chassis expander pairs must be powered from the same service panel.
Page 152 Page 152 of 562 Installing the system ground For a Cabinet system, if the cabinet is connected to a reserve power supply unit (battery backup), make sure that the circuit breaker on that unit is set to OFF. DANGER OF ELECTRIC SHOCK Never connect backup power to a cabinet that is not grounded correctly.
Page 153 Installing the system ground Page 153 of 562 Figure 53 Ground/Earth lug in the NTAK11 system cabinets Earth lug Ground connection Ground/Earth wire in third groove Small System Installation and Configuration...
Page 154 Page 154 of 562 Installing the system ground For the Chassis system: Install a #6 AWG (#40 Metric Wire Gauge) ground wire from the ground lug on the back of the chassis to the NTBK80 grounding block. Consider each chassis and chassis expander pair as one ground. Jumper the chassis expander ground to the chassis ground.
Page 155 Installing the system ground Page 155 of 562 Figure 55 NTBK80 grounding block To ground lug in cabinets or chassis To ground source Connect the grounding block to the ground bus in the ac power service panel, using #6 AWG wire. See Table 19 on page 151 for region-specific grounding requirements.
Page 156 Page 156 of 562 Installing the system ground Procedure 13 Earthing the cabinets or chassis (UK) Connect a protective and functional earth wire from the earthing strip on the Krone Test Jack Frame to the earth at the building entry point. Use a green/yellow wire no thinner than 10 mm 2 .
Page 157 Installing the system ground Page 157 of 562 Figure 56 Grounding multiple pieces of equipment in a rack Chassis Chassis P o w e r F a n Expander Grounding lug on P o w e r F a n back of chassis Other data Other data...
Page 158 Page 158 of 562 Installing the system ground 553-3011-210 Standard 1.00 October 2003...
Page 159: Installing The Power Supplies For The Cabinet System
Page 159 of 562 Installing the power supplies for the Cabinet system Contents This section contains information on the following topics: Introduction ..........Power supplies.
Page 160: Power Supplies
Page 160 of 562 Installing the power supplies for the Cabinet system Figure 57 Power supply location — main and expansion cabinets Power supplies Power supplies are shipped separately from the cabinets. AC-powered system If installing an ac-powered system, an NTDK70 or NTDK78 ac/dc power supply is required with its appropriate line cord for each cabinet.
Page 161 Installing the power supplies for the Cabinet system Page 161 of 562 Additionally, one NTAK0420 power cable is required for each cabinet (for a dc power source). Switch settings The power supplies are equipped with a series of switches which must be set before the units are installed in the cabinet.
Page 162 Page 162 of 562 Installing the power supplies for the Cabinet system Figure 58 NTDK70, NTDK72, and NTDK78 power supply switch settings Message Waiting -150V -120V Ringing 86VRMS 80VRMS 75VRMS Switches located 70VRMS at the top inside unit Frequency Setting 20 Hz 25 Hz 50 Hz...
Page 163 Installing the power supplies for the Cabinet system Page 163 of 562 AC power supply installation AC power requirements The ac-powered version requires a non-switched dedicated power outlet installed within 6 ft (1830 mm) of each cabinet, with: • one non-switched dedicated outlet per cabinet with: —...
Page 164 Page 164 of 562 Installing the power supplies for the Cabinet system Procedure 14 Installing the ac power supply Set the ac breaker on the front of the power supply to the OFF position. Make sure that the switches on the power supply are properly set. See Figure 58 on page 162.
Page 165 Installing the power supplies for the Cabinet system Page 165 of 562 Figure 59 AC power cable connection Commercial ac power connection Clip at rear of cabinet Optional battery backup dc power connection Secure the power line cord in place using the clip at rear of cabinet. See Figure 59 on page 165.
Page 166 Page 166 of 562 Installing the power supplies for the Cabinet system Test the ground of each system cabinet using the following: Set the circuit breakers feeding the ac outlet used to power the cabinet to OFF. Connect the power line cord to the NTDK70 or NTDK78 main cabinet power supply.
Page 167 Installing the power supplies for the Cabinet system Page 167 of 562 Procedure 15 Installing the dc power supply Make sure the switches on the power supply are properly set. Refer to Figure 58 on page 162 of this chapter. Insert the power supply into the first slot on the left of the card shelf (refer to Figure 57 on page...
Page 168 Page 168 of 562 Installing the power supplies for the Cabinet system Figure 60 NTDK72 dc power cable connection DC power connection Route the rest of the power cable down through the opening at the bottom of the cabinet as shown in Figure 61 on page 169.
Page 169 Installing the power supplies for the Cabinet system Page 169 of 562 Figure 61 Power cord routing DC power cord in second groove Ground wire in third groove Mount the NTAK28 Breaker Assembly to the wall within 3 ft (915 mm) of the cabinet it is serving.
Page 170 Page 170 of 562 Installing the power supplies for the Cabinet system Figure 62 NTAK28 Breaker Assembly location Set the breakers on the NTAK28 Breaker Assembly and on the NTDK72 power supply to OFF. Connect the other end of the dc power cable (NTAK0420 cable) to the connector on the dc breaker assembly.
Page 171 Installing the power supplies for the Cabinet system Page 171 of 562 Figure 63 Power connection at the NTAK28 breaker assembly End of Procedure Small System Installation and Configuration...
Page 172 Page 172 of 562 Installing the power supplies for the Cabinet system 553-3011-210 Standard 1.00 October 2003...
Page 173: Installing And Connecting Reserve Power Supplies For The Cabinet System
Page 173 of 562 Installing and connecting reserve power supplies for the Cabinet system Contents This section contains information on the following topics: Introduction ..........Types of reserve power .
Page 174: Ntak75 Battery Unit Installation
Page 174 of 562 Installing and connecting reserve power supplies for the Cabinet system — provides a minimum of 2 hours of reserve dc power — mounts to the floor — supports one system cabinet • The NTAK76 battery box, which has the following features: —...
Page 175 Installing and connecting reserve power supplies for the Cabinet system Page 175 of 562 Procedure 16 Installing the NTAK75 battery unit Unpack the NTAK75 battery unit and place it according to the equipment layout plan. • The battery unit must be a installed within 3 ft (915 mm) of the cabinet it is serving.
Page 176 Page 176 of 562 Installing and connecting reserve power supplies for the Cabinet system Figure 64 NTAK75 battery backup — top view Circuit breaker Locate the four black/red jumper cables supplied with the NTAK75. Connect the battery packs by installing the jumper cables between the +/- terminals of one battery pack to the connectors marked J1 –...
Page 177 Installing and connecting reserve power supplies for the Cabinet system Page 177 of 562 11 Plug the NTAK0420 cable from the battery box into the power supply in the cabinet (Figure 65 on page 178). Secure the cable with the cable retainer inside the cabinet. 12 Set the breaker on the NTDK70 or NTDK78 to ON.
Page 178: Ntak76 Battery Unit Installation
Page 178 of 562 Installing and connecting reserve power supplies for the Cabinet system Figure 65 Cable connections Connection on power supply unit Cable from reserve power NTAK76 battery unit installation Follow Procedure 17 on page 179 to install an NTAK76 battery unit. Repeat the procedure for each system cabinet being installed.
Page 179 Installing and connecting reserve power supplies for the Cabinet system Page 179 of 562 Procedure 17 Installing the NTAK76 battery unit Unpack the NTAK76 battery unit and place it according to the equipment layout plan. • The battery unit must be installed within 3 ft (915 mm) of the cabinet it is serving.
Page 180 Page 180 of 562 Installing and connecting reserve power supplies for the Cabinet system Figure 66 Mounting the NTAK76 battery unit to the wall Install this screw first Screw holes Set the switch on the front of the NTAK76 battery box to OFF. (Refer to Figure 67 on page 181).
Page 181 Installing and connecting reserve power supplies for the Cabinet system Page 181 of 562 Locate the three white jumper wires and the red and black jumper cables supplied with the NTAK76 battery unit. Connect the battery packs in series by connecting the white jumper wires between the + (red) terminal of one battery pack to the - (black) terminal of the next battery pack.
Page 182 Page 182 of 562 Installing and connecting reserve power supplies for the Cabinet system 11 Set the breaker in the battery unit to ON to test for correct wiring. The NTAK76 green LED (BATT) should switch on. DC voltage can be measured between the test points whenever the green BATT LED is lit on the NTAK76.
Page 183: Connecting Other Battery Backup Systems
Installing and connecting reserve power supplies for the Cabinet system Page 183 of 562 Figure 68 Power cord routing Connection on power Connection on power supply unit supply unit Cable from reserve power Connecting other battery backup systems This procedure describes how to install and connect customer-supplied battery backup systems.
Page 184 Page 184 of 562 Installing and connecting reserve power supplies for the Cabinet system Procedure 18 Installing other battery systems Unpack the battery box and place it according to the equipment layout plan. Remove its cover. Set the switch on the battery box to OFF. Unpack the batteries and check the expiry dates.
Page 185 Installing and connecting reserve power supplies for the Cabinet system Page 185 of 562 Figure 69 NTAK28 breaker assembly location 10 Set the breakers on the NTAK28 Junction Box and on the NTDK70 or NTDK78 power supply to OFF. 11 Connect the NTAK0420 cable from the NTAK28 Junction Box to the power supply in the cabinet.
Page 186 Page 186 of 562 Installing and connecting reserve power supplies for the Cabinet system Figure 70 NTAK28 circuit breaker assembly 553-3011-210 Standard 1.00 October 2003...
Page 187: Installing Small System Controller And Fiber Receiver
Page 187 of 562 Installing Small System Controller and Fiber Receiver cards Contents This section contains information on the following topics: Introduction ..........Circuit card assignments for the Chassis system .
Page 188 Page 188 of 562 Installing Small System Controller and Fiber Receiver cards The following procedures describe how to install the NTDK20 SSC card and the NTDK23 Fiber Receiver card: • Procedure 19: “Installing the software daughterboard and security device” on page 191 •...
Page 189: Circuit Card Assignments For The Chassis System
Installing Small System Controller and Fiber Receiver cards Page 189 of 562 Circuit card assignments for the Chassis system Figure 71 on page 189 and Figure 72 on page 190 show the circuit card assignments for the chassis and chassis expander. Follow these diagrams to make sure that you have all circuit cards inserted in the correct slots.
Page 190 Page 190 of 562 Installing Small System Controller and Fiber Receiver cards Figure 72 Circuit card assignments in the chassis expander Chassis Expander Slot 10 - Meridian Mail or any IPE card Slot 09 - Any IPE card Slot 08 - Any IPE card Slot 07 - Any IPE card 553-9032 Note 1: See the card slot assignment table in the equipment layout...
Page 191: Main Cabinet And Chassis Ntdk20 Ssc Card Installation
Installing Small System Controller and Fiber Receiver cards Page 191 of 562 Main cabinet and chassis NTDK20 SSC card installation This section describes the steps to install a Small System Controller (SSC) card in the main cabinet or chassis of a Small System. It also describes the installation of the daughterboards, cables, and other components that are required installation on the SSC card.
Page 192 Page 192 of 562 Installing Small System Controller and Fiber Receiver cards Figure 73 Location of software daughterboard and security device on the NTDK20 SSC card Software daughterboard Security device 553-3011-210 Standard 1.00 October 2003...
Page 193 Installing Small System Controller and Fiber Receiver cards Page 193 of 562 Installation of expansion daughterboards and cables The following four daughterboards can be installed on the SSC card in the main cabinet or chassis: • NTDK22/24/79 (Single mode) — single port •...
Page 194 Page 194 of 562 Installing Small System Controller and Fiber Receiver cards Replace the standoffs on the SSC card with the taller standoffs supplied with the IP daughterboard. Record the MAC address found on the back of the daughterboard. This will be needed later to perform the software installation.
Page 195 Installing Small System Controller and Fiber Receiver cards Page 195 of 562 11 Insert the SSC card into slot 0 of the main cabinet or chassis. Lock card into faceplate latches. 12 Route NTDK8305 extension cable through EMC clip. For the Cabinet system, push cable to the left as shown in Figure 76 on page 197.
Page 196 Page 196 of 562 Installing Small System Controller and Fiber Receiver cards Figure 75 SSC card with 100BaseT daughterboard installed Plastic post connection MAC address Daughterboard port connectors NTDK8305 cable 553-3011-210 Standard 1.00 October 2003...
Page 197 Installing Small System Controller and Fiber Receiver cards Page 197 of 562 Figure 76 EMC grounding clip for the cabinet Stiffener rail EMC grounding clip Note: The EMC grounding clip is installed on the front of the stiffener rail on the IP cabinet. There is a small #4-40 screw to fasten the clip to the stiffener rail.
Page 198 Page 198 of 562 Installing Small System Controller and Fiber Receiver cards Figure 77 EMC grounding clip for the chassis 100BaseT cables secured with a cable tie Grounding clip CAUTION WITH ESDS DEVICES The grounding clip is required to ensure EMC compliance.
Page 199 Installing Small System Controller and Fiber Receiver cards Page 199 of 562 Figure 78 Cable Routing Guide under main cabinet Cable Routing Guide Procedure 21 Installing the 100BaseF IP daughterboard on the SSC card on the main cabinet or chassis Put on the antistatic wrist strap.
Page 200 Page 200 of 562 Installing Small System Controller and Fiber Receiver cards Note 1: With new connectors, push very firmly until a definite “click” is heard. Pull gently on the connection to make sure it is secure. Note 2: The top connector on the SSC card is for expansion cabinets or chassis ”1”...
Page 201 Installing Small System Controller and Fiber Receiver cards Page 201 of 562 Figure 79 NTTK02 dual-port 100BaseF daughterboard Fiber connectors connector Small System Installation and Configuration...
Page 202 Page 202 of 562 Installing Small System Controller and Fiber Receiver cards Figure 80 Cable ends and fiber coupler A0817052 MT-RJ end A0817052 MT-RJ to ST A0346816 ST Fiber cable (B) Rx end Coupler A0817052 MT-RJ to ST cable (A) Tx end Installation of Fiber Expansion Daughterboards and cables For non-IP expansion, a Fiber Expansion Daughterboard must be installed on the SSC card of the main cabinet or chassis, and a Fiber Receiver card must...
Page 203 Installing Small System Controller and Fiber Receiver cards Page 203 of 562 Install the Fiber Expansion Daughterboard for expansion cabinet or chassis “1” on the upper connector. Install the Fiber Expansion Daughterboard for expansion cabinet or chassis “2” on the lower connector. Note 1: If using the plastic fiber cable, see Procedure 24 on page 207.
Page 204 Page 204 of 562 Installing Small System Controller and Fiber Receiver cards Figure 81 NTDK22 single-port fiber Expansion Daughterboard Procedure 23 Installing the dual-port fiber Expansion Daughterboards on the SSC card of the main cabinet or chassis Put on the antistatic wrist strap. Place the SSC card on a clean flat surface.
Page 205 Installing Small System Controller and Fiber Receiver cards Page 205 of 562 Route the cables through the SSC cable router on the SSC card. Refer to Figure 85 on page 209. Insert the SSC card into slot 0 of the main cabinet or chassis. Route the fiber cable through the Cable Routing Guide under the main cabinet.
Page 206 Page 206 of 562 Installing Small System Controller and Fiber Receiver cards Figure 83 Cabinet or chassis assignments for dual-port daughterboards Expansion daughterboard in connector “Fiber 1” Connection for Cabinet/Chassis 1 Connection for Cabinet/Chassis 3 Connection for faceplate LED Expansion daughterboard in connector “Fiber 2”...
Page 207 Installing Small System Controller and Fiber Receiver cards Page 207 of 562 Do not staple or twist fiber-optic cable. Do not bend it beyond a 35 mm bend radius (90° soft bend). CAUTION — Service Interruption Incorrectly connected fiber-optic cables may cause the following problems: •...
Page 208 Page 208 of 562 Installing Small System Controller and Fiber Receiver cards Route the cables through the SSC Cable Routing Guide as shown in Figure 85 on page 209. Note: Be sure to wrap the cable a minimum of one complete loop around the Cable Routing Guide to allow for extra cable for removing the SSC card later.
Page 209 Installing Small System Controller and Fiber Receiver cards Page 209 of 562 Figure 85 Fiber-optic cable connection Fiber cable connections SSC cable router Small System Installation and Configuration...
Page 210 Page 210 of 562 Installing Small System Controller and Fiber Receiver cards Procedure 25 Installing glass fiber-optic cable Put on the antistatic wrist strap. Place the SSC card on a clean flat surface. Remove the protective plugs from one connector on the Fiber Daughterboard.
Page 211: Ntdk20 Ssc Card Installation On Ip Expansion Cabinets And Chassis
Installing Small System Controller and Fiber Receiver cards Page 211 of 562 Figure 86 Glass fiber-optic cable connection on dual-port daughterboard SSC cable router Glass fiber-optic cable connections NTDK20 SSC card installation on IP expansion cabinets and chassis IP expansion cabinets or chassis require an NTDK20 SSC card equipped with an IP daughterboard.
Page 212 Page 212 of 562 Installing Small System Controller and Fiber Receiver cards Note: While the security device on the SSC card of the IP expansion cabinet or chassis is installed as described in Procedure 19 on page 191, the device itself is different. The security device for IP expansion cabinets or chassis is labelled “NT_REM”...
Page 213: Fiber Receiver Card Installation On Expansion Cabinets And Chassis
Installing Small System Controller and Fiber Receiver cards Page 213 of 562 Fiber Receiver card installation on expansion cabinets and chassis Fiber expansion cabinets or chassis require an NTDK23 Fiber Receiver card. This section describes the steps necessary to connect the cables and install the Fiber Receiver card.
Page 214 Page 214 of 562 Installing Small System Controller and Fiber Receiver cards Figure 87 Plastic fiber-optic connection on Fiber Receiver card If the connector is equipped with a marking, it should be hidden by the clasp when properly connected. Insert the connector firmly.
Page 215 Installing Small System Controller and Fiber Receiver cards Page 215 of 562 Figure 88 Glass fiber-optic connection on Fiber Receiver card Insert plug and twist one half turn clockwise to lock Small System Installation and Configuration...
Page 216 Page 216 of 562 Installing Small System Controller and Fiber Receiver cards Figure 89 Fiber Receiver card in slot 0 of the fiber expansion cabinet Fiber cable connection Cable storage area Cable Routing Guide 553-3011-210 Standard 1.00 October 2003...
Page 217: Installing Optional Circuit Cards
Page 217 of 562 Installing optional circuit cards Contents This section contains information on the following topics: Introduction ..........Circuit cards .
Page 218 Page 218 of 562 Installing optional circuit cards Refer to the card slot assignments in the equipment layout chapter of Small System: Planning and Engineering (553-3011-120) for additional information on where to place circuit cards. Refer to Circuit Card: Description and Installation (553-3001-211) for full descriptions of country-specific IPE cards and their installation procedures.
Page 219: Circuit Cards
Installing optional circuit cards Page 219 of 562 Circuit cards A circuit card displaying a symbol of a switch on its faceplate is equipped with option switches or strapping plugs or both. Other circuit cards, such as the NTDK20 SSC card, are capable of mounting daughterboards and other add-on devices.
Page 220 Page 220 of 562 Installing optional circuit cards Procedure 27 Installing the NTAK02 circuit card Set the switches and jumper plugs for the NTAK02 SDI/DCH card according to Tables 21 to 23. Table 21 Switch settings (Ports 0 and 1) Port Port DPNSS...
Page 221: Ntak03 Tds/Dtr Card
Installing optional circuit cards Page 221 of 562 Table 23 Jumper settings Strap Strap Jumper Jumper Port location location RS422 RS232 Port 0 C - B B - A Port 1 C - B B - A C - B B - A C - B B - A...
Page 222: Nt8D14 Universal Trunk Card
Page 222 of 562 Installing optional circuit cards Procedure 28 Installing the NTAK03 card Insert the card in its assigned slot. You can insert the NTAK03 TDS/DTR card into: • any of the card slots 1 through 9 of the cabinet •...
Page 223 Installing optional circuit cards Page 223 of 562 Procedure 29 Installing the Universal Trunk card Set the jumpers for the NT8D14 Universal Trunk circuit card according to Table 24. Table 24 NT8D14 Universal Trunk — modes and option settings Jumper Modes Location strap...
Page 224: Nt8D15 E&M Trunk Card
Page 224 of 562 Installing optional circuit cards NT8D15 E&M Trunk card The E&M trunk card provides four trunks which can function as 2W E&M, 4W E&M, and Paging. You can install this card in: • slots 1 through 10 in the main cabinet or slots 11 through 30 in the expansion cabinets •...
Page 225: Ntag26 Xmfr Card
Installing optional circuit cards Page 225 of 562 NTAG26 XMFR card The NTDK20 SSC card provides the functionality of the Extended Multi-Frequency Receiver (XMFR) card. However, this card can exist with the SSC card if you want to access additional XMFR capability. The XMFR card receives MF digit information.
Page 226: Nt5K21 Xmfc Card
Page 226 of 562 Installing optional circuit cards NT5K21 XMFC card The NTDK20 SSC card provides the functionality of the Extended Multi-Frequency Compelled Sender/Receiver (XMFC) card. However, the XMFC card can coexist with the SSC card if you wish to access extra XMFC capability.
Page 227 Installing optional circuit cards Page 227 of 562 Procedure 33 Installing the OPS analog line card Set the jumpers on the NT1R20 OPS card. Each line interface unit on the card is equipped with two jumper blocks that are used to select the proper loop current, depending upon loop length.
Page 228 Page 228 of 562 Installing optional circuit cards Table 26 provides OPS analog line card configuration information. Table 26 OPS analog line card configuration Application On-premise station (ONS) Off-premise station (OPS) Class of service (Note 1) Loop resistance 0–460 ohms 0–2300 ohms Jumper strap setting Both JX.0 and JX.1 off...
Page 229 Installing optional circuit cards Page 229 of 562 Figure 92 OPS analog line card: jumper block locations Jumper block locations Small System Installation and Configuration...
Page 230: Ntdk16 48-Port Digital Line Card
Page 230 of 562 Installing optional circuit cards Figure 93 OPS analog line card cross-connections End of Procedure NTDK16 48-port Digital Line Card The NTDK16 48-port Digital Line Card provides an interface to a maximum of 48 digital integrated voice and data sets in a Chassis system. The NTDK16 Digital Line Card is functionally equivalent to three NT8D02 Digital Line Cards.
Page 231 Installing optional circuit cards Page 231 of 562 Figure 94 48-port Digital Line Card Latches Note 1: You can only place the NTDK16 Digital Line Card in slot 4 of the chassis. Note 2: The Chassis system does not require the NTDK16 Digital Line Card to operate.
Page 232: Nt8D02 Digital Line Card
Page 232 of 562 Installing optional circuit cards Procedure 34 Installing the NTDK16 48-port Digital Line Card Insert the NTDK16 card in Slot 4 of the chassis. Lock the latches on the card. Note 1: The NTDK16 provides three independent loops (loops 4, 5, and 6).
Page 233: Digital Trunk Cards
Installing optional circuit cards Page 233 of 562 Digital Trunk cards Small Systems supports the following digital trunk cards: • NTAK09 1.5 Mbit DTI/PRI • NTAK10 2.0 Mbit DTI • NTAK79 2.0 Mbit PRI • NTBK22 MISP • NTBK50 2.0 Mbit PRI •...
Page 234 Page 234 of 562 Installing optional circuit cards 553-3011-210 Standard 1.00 October 2003...
Page 235: Installing And Connecting Cross-Connect Terminals
Page 235 of 562 Installing and connecting cross-connect terminals Contents This section contains the following topics: Introduction ..........Terminal block requirements .
Page 236: Terminal Block Requirements
Page 236 of 562 Installing and connecting cross-connect terminals This chapter contains the following procedures: • Procedure 36 “Installing the BIX cross-connect terminal” on page 238 • Procedure 37 “Installing the Reichle Masari cross-connect terminal (Germany)” on page 241 • Procedure 38 “Installing the Krone Test Jack Frame (UK)”...
Page 237: Terminal Block Requirements For The Chassis System
Installing and connecting cross-connect terminals Page 237 of 562 – Connectors J1 through J10 correspond to slot numbers 21 through 30 in the second expansion cabinet. – Connectors J1 through J10 correspond to slot numbers 31 through 40 in the third expansion cabinet. –...
Page 238: Installing The Bix Cross-Connect Terminal
Page 238 of 562 Installing and connecting cross-connect terminals — If the NTAK19 SDI cable is not used with the NTAK03 or NTAK02 cards, then you require a 25-pair cable for each of these cards. • four conductors for the AUX cable from the chassis •...
Page 239 Installing and connecting cross-connect terminals Page 239 of 562 Figure 95 Typical BIX cross-connect terminal layout for the Cabinet system Small System Installation and Configuration...
Page 240 Page 240 of 562 Installing and connecting cross-connect terminals Figure 96 Typical BIX cross-connect terminal layout for the Chassis system Main Chassis Cable Card 1 AUX cable Cable Card 2 PFTU Cable Card 3 Cable Card 4/6 Cable Card 5/6 Telephones Trunks Chassis Expander...
Page 241: Installing The Reichle Masari Cross-Connect Terminal (Germany)
Installing and connecting cross-connect terminals Page 241 of 562 Installing the Reichle Masari cross-connect terminal (Germany) Procedure 37 describes how to install the Reichle Masari cross-connect terminal for Germany. Procedure 37 Installing the Reichle Masari cross-connect terminal (Germany) Consult the equipment layout plan to determine where to place the cross-connect terminal.
Page 242 Page 242 of 562 Installing and connecting cross-connect terminals Connect a 16 mm (10 mm green-yellow ground wire for Germany) ground wire from the ground bar on the cross-connect terminal to the ground lug in each cabinet. Figure 97 Reichle Masari cross-connect terminal layout for the Cabinet system (Germany) Odd system cable Even system cable...
Page 243 Installing and connecting cross-connect terminals Page 243 of 562 Figure 98 Typical Reichle Masari cross-connect terminal layout for the Chassis system (Germany) Card 1 Card 10 Card 2 Card 10 Card 3 Card 4 Card 6 (0-7) Card 5 Card 5 Card 6 Free block for wiring Card 6...
Page 244: Installing The Krone Test Jack Frame For The Uk
Page 244 of 562 Installing and connecting cross-connect terminals Installing the Krone Test Jack Frame for the UK The Krone Test Jack Frame provides terminating strips that hold 10 pairs of cable. Generally, only 8 of the 10 pairs are used. As a result, one 25-pair cable requires three terminating strips: 8 pairs/strip x 3 strips = 24 pairs Figure 99 on...
Page 245 Installing and connecting cross-connect terminals Page 245 of 562 Figure 99 25-pair cable on three Krone strips Pair Pin numb er Wire Co lo ur Kron e strip W-BL BL-W W-BR BR -W R-BL BL-R R-BR BR -R BK-BL BL-BK BK-O O-BK BK-G...
Page 246 Page 246 of 562 Installing and connecting cross-connect terminals Procedure 38 describes how to install the Krone Test Jack Frame. Procedure 38 Installing the Krone Test Jack Frame (UK) Consult the equipment layout plan to determine where to place the cross-connect terminal.
Page 247 Installing and connecting cross-connect terminals Page 247 of 562 Figure 100 Typical Krone cross connect terminal layout for the Cabinet system Main cabinet Expansion cabinet Pair Pair Pair Pair Spare Spare Spare PFTU Attendant terminations console AUX cable Earthing block Earthing block Small System Installation and Configuration...
Page 248 Page 248 of 562 Installing and connecting cross-connect terminals Figure 101 Typical Krone cross-connect terminal layout for the Chassis system Pair Pair Spare PFTU termination Other equipment AUX cable Grounding block Attendant Console Card 10 Chassis Expander Card 9 Card 8 Card 7 Card 6 (8-15) Card 5...
Page 249: Connecting The Cables
Installing and connecting cross-connect terminals Page 249 of 562 Note: One 25-pair cable contains Card 4 and Card 6 (units 0–7). Another 25-pair cable contains Card 5 and Card 6 (units 8–15). End of Procedure Connecting the cables WARNING Always use caution when installing or modifying telephone lines.
Page 250 Page 250 of 562 Installing and connecting cross-connect terminals For 1.5 Mbit and 2.0 Mbit DTI/PRI-related wiring and cable information, refer to the following documents: • ISDN Primary Rate Interface: Installation and Configuration (553-3001-201) • ISDN Primary Rate Interface: Maintenance (553-3001-517) Procedure 39 Connecting the cables for the Cabinet system Remove the connector retaining bar from the connector panel in the lower...
Page 251 Installing and connecting cross-connect terminals Page 251 of 562 Replace the retaining bar when you have connected all the cables to the cabinet. Terminate all the 25-pair cables installed at the cross-connect terminal. Label all the cables at the cross-connect terminal blocks according to the card slot allocation plan.
Page 252 Page 252 of 562 Installing and connecting cross-connect terminals Figure 103 Cable connectors on the back of the chassis Connector Connector for Connector for for slot 3 slot 5 and half slot 4 and half of slot 6 of slot 6 Connector for slot 2 Connector...
Page 253 Installing and connecting cross-connect terminals Page 253 of 562 Figure 104 AUX cable connector AUX connector Small System Installation and Configuration...
Page 254 Page 254 of 562 Installing and connecting cross-connect terminals Terminate the AUX cable at the cross connect terminal, according to Table 28. Table 28 AUX cable terminations for the Chassis system Color Wire number Designation Connection W-BL BRTN to QUA6-J1 1R BL-W BRTN to QUA6-J1 2R...
Page 255 Installing and connecting cross-connect terminals Page 255 of 562 Figure 105 Cross connections record End of Procedure Small System Installation and Configuration...
Page 256 Page 256 of 562 Installing and connecting cross-connect terminals 553-3011-210 Standard 1.00 October 2003...
Page 257 Page 257 of 562 Installing Power Failure Transfer Units Contents This section contains the following topics: Introduction ..........PFTU installation .
Page 258 Page 258 of 562 Installing Power Failure Transfer Units PFTU installation Refer to the equipment layout plan to determine where to locate the PFTU. See the chapters on system and site requirements in Small System: Planning and Engineering (553-3011-120). Procedure 41 Installing the PFTU Mount the PFTU on the wall near the system cross-connect terminal and secure it with four screws.
Page 259 Installing Power Failure Transfer Units Page 259 of 562 Connect the PFTU power and control connections to the AUX cable from the cabinet or chassis. See Table 29. For the location of the Auxiliary port on the cabinet, see Figure 107 on page 260.
Page 260 Page 260 of 562 Installing Power Failure Transfer Units Figure 107 Auxiliary port location on cabinet Auxiliary port: NTAK1104 AUX cable connects the PFTU and M2250 attendant console to the cabinet 553-3011-210 Standard 1.00 October 2003...
Page 261 Installing Power Failure Transfer Units Page 261 of 562 Figure 108 Auxiliary connector on chassis AUX connector Connect the attendant console to the PFTU: • attendant console 14 Tip (14T) to ground • 3 Tip (3T) of PFTU to 11 Ring (11R) of attendant console (power fail transfer switch) •...
Page 262 Page 262 of 562 Installing Power Failure Transfer Units If power to the M2250 attendant console is not provided by two Digital Line Card TNs, connect: • G-W of AUX to 8 Tip (8T) of attendant console (-15 volts) • W-G of AUX to 7 Tip (7T) of attendant console (+15 volts) Figure 109 Power fail transfer...
Page 263 Installing Power Failure Transfer Units Page 263 of 562 PFTU control lead signals To connect PFTUs from other manufacturers, use the information provided in Table 30. Table 30 PFTU control lead signals NTAK1104 Lead State when PFTU is Lead State when PFTU AUX cable lead in non-transferred state is in transferred state...
Page 264 Page 264 of 562 Installing Power Failure Transfer Units 553-3011-210 Standard 1.00 October 2003...
Page 265: Introduction
Page 265 of 562 Installing and connecting SDI and Ethernet ports Contents This section contains information on the following topics: Introduction ..........Modem setup requirements .
Page 266: Modem Setup Requirements
Page 266 of 562 Installing and connecting SDI and Ethernet ports • Procedure 42 “Connecting SDI ports on the SSC card” on page 271 • Procedure 43 “Connecting SDI ports to the Fiber Receiver card” on page 274 • Procedure 44 “Setting up the terminal” on page 282 •...
Page 267: Sdi Ports
Installing and connecting SDI and Ethernet ports Page 267 of 562 Table 31 lists some of the problems that may be encountered. Table 31 Modem problems Problem Solution CDR is not printing on an ESDI port Change the modem set-up to 7 bits, no parity, 1 configured as 8 bits, no parity, and 1 stop stop bit, or add MTC or SCH to the ESDI user bit.
Page 268: Cable Connections And Adapters
Page 268 of 562 Installing and connecting SDI and Ethernet ports Cable connections and adapters An NTBK48 3-port 9- to 25-pin converter cable is supplied with the Small System. The cable can be used to connect SDI port 0, 1, or 2 directly to most types of modems.
Page 269 Installing and connecting SDI and Ethernet ports Page 269 of 562 Figure 111 NTBK48 Ports 1 and 2 signal leads 9 PIN Connector 25 PIN Connector Port 1 & 2 - Cable Wiring FGND 1 FGND 2 RX 3 TX Not Used 4 RTS Not Used...
Page 270: Installing And Connecting Sdi Ports
Page 270 of 562 Installing and connecting SDI and Ethernet ports Figure 112 Modem eliminator connections and designations FGND 1 1 FGND TX 2 2 TX RX 3 3 RX RTS 4 4 RTS CTS 5 5 CTS DSR 6 6 DSR CD 8 8 CD...
Page 271 Installing and connecting SDI and Ethernet ports Page 271 of 562 Note: When the time comes to configure ports 1 and 2, configure them in LD 17. • Use Port 0 for software installation and upgrades. SDI port 0 is the only SDI port that you can use for software installation and upgrades.
Page 272 Page 272 of 562 Installing and connecting SDI and Ethernet ports If the system is to be accessed remotely, connect the system modem to the cable marked “port 0” on the NTBK48 cable. Note 1: If port 0 is used, check the baud rate setting on the front of the SSC card located in slot 0 of the main cabinet or chassis.
Page 273: Ntdk23, Ntdk25, And Ntdk80 Fiber Receiver Cards
Installing and connecting SDI and Ethernet ports Page 273 of 562 Figure 114 SDI cable connection on the chassis SDI connector End of Procedure NTDK23, NTDK25, and NTDK80 Fiber Receiver cards The Fiber Receiver cards provide one SDI port per expansion cabinet or chassis.
Page 274 Page 274 of 562 Installing and connecting SDI and Ethernet ports Note: Although all device numbers can be assigned to any cabinet or chassis, TTY 0, 1, and 2 are usually assigned to the main cabinet or chassis. TTY 3, 4, 5, and 6 are typically assigned to the first, second, third, and fourth expansion cabinets or chassis respectively.
Page 275 Installing and connecting SDI and Ethernet ports Page 275 of 562 Figure 115 SDI cable connection on the fiber expansion cabinet NTAK1108 cable connection Small System Installation and Configuration...
Page 276: Ntak02 Sdi/Dch Card
Page 276 of 562 Installing and connecting SDI and Ethernet ports Figure 116 SDI cable connection on the fiber expansion chassis SDI connector NTAK02 SDI/DCH card In the Cabinet system, the NTAK02 SDI/DCH card can be used in the main and IP expansion cabinets.
Page 277 Installing and connecting SDI and Ethernet ports Page 277 of 562 You can use the NTAK02 ports to access overlay software. Define these ports in the configuration database as the SDI logical type. An NTAK19FB 4-port SDI cable is designed for use with the NTAK02 circuit card.
Page 278 Page 278 of 562 Installing and connecting SDI and Ethernet ports Table 34 NTAK02 connections at the cross-connect terminal — Port 1 RS422 RS232 Designations Designations (I = input (I = input Cable Signal O = output) O = output) Signal Pair Color...
Page 279 Installing and connecting SDI and Ethernet ports Page 279 of 562 Table 35 NTAK02 connections at the cross-connect terminal — Port 2 RS422 RS232 Designations Designations (I=input (I=input Cable Signal O=output) O=output) Signal Pair Color BK-G G-BK BK-BR CH/CI BR-BK BK-S S-BK Y-BL...
Page 280 Page 280 of 562 Installing and connecting SDI and Ethernet ports Table 36 NTAK02 connections at the cross-connect terminal — Port 3 RS422 RS232 Designations Designations (I=input (I=input Cable Signal O=output) O=output) Signal Pair Color SCTEA SCTA – – – –...
Page 281: Ntak03 Tds/Dtr Card
Installing and connecting SDI and Ethernet ports Page 281 of 562 NTAK03 TDS/DTR card The NTDK20 SSC card includes the functionality of the NTAK03 TDS/DTR card. However, you can also configure the NTAK03 card, if required. An NTAK19 cable is designed for use with the NTAK03 circuit card. However, you can use an NE-A25B 25-pair cable to extend the connections to the cross-connect terminal.
Page 282: Terminal Setup
Page 282 of 562 Installing and connecting SDI and Ethernet ports Table 38 NTAK03 connections at the cross-connect terminal — Port 1 Designations Pair Color Signal (I=input, O=output) R-BL BL-R – – – – BK-BL BL-BK BK-G – – G-BK –...
Page 283 Installing and connecting SDI and Ethernet ports Page 283 of 562 Use the keys listed in Table 39 to view and change setup values. Table 39 Setup (keys and functions) Function Arrow key Move from field to field <Enter> Scroll through possible values or cause requested action to take place (depends on type of field) <Next Screen>...
Page 284 Page 284 of 562 Installing and connecting SDI and Ethernet ports Table 40 HP700/32 setup values G loba l s e t- up s c r ee n H os t P or t K e y boa r d U .S.
Page 285 Installing and connecting SDI and Ethernet ports Page 285 of 562 Table 41 VT420 setup values Global Set-Up On Line Comm1=RS232 Sessions on Comm1 70Hz CRT Saver Printer Shared Display Set-Up 80 Columns No Status Display Interpret Controls Cursor Steady Auto Wrap 3x24 pages Jump Scroll...
Page 286 Page 286 of 562 Installing and connecting SDI and Ethernet ports Table 42 VT220 setup values Global Set-Up On Line Comm1=RS232 Sessions on Comm1 70Hz CRT Saver Printer Shared Display Set-Up 80 Columns Light Text, Dark Screen Interpret Controls Cursor Auto Wrap Block Style Cursor Jump Scroll...
Page 287: Installing And Connecting An Ethernet Cable
Installing and connecting SDI and Ethernet ports Page 287 of 562 Installing and connecting an Ethernet cable This section describes the procedures required to connect an Ethernet cable • a Cabinet system (Procedure 45 on page 290) • a Chassis system (Procedure 46 on page 292) Cabinet system: IP expansion 10BaseT port...
Page 288: J7 Jumper Plug
Page 288 of 562 Installing and connecting SDI and Ethernet ports It is not recommended to use the remote 10BaseT port in normal mode, as maintenance or alarm management are not available. In survival mode it assumes the system level configuration of the main cabinet port. Figure 117 Ethernet port location on the cabinet Ethernet cable interface...
Page 289 Installing and connecting SDI and Ethernet ports Page 289 of 562 Compatible Daughterboard used in multi-cabinet systems that are not interconnected with fiber-optic cable. When a multi-cabinet system is upgraded from copper to fiber-optic cable inter-cabinet connections, the NTDK26 Backwards Compatible Daughterboard must be replaced with Fiber Expansion Daughterboards.
Page 290 Page 290 of 562 Installing and connecting SDI and Ethernet ports Figure 118 J7 Jumper Plug location on NTDK20EA SSC card Location of J7 jumper plug connector Procedure 45 Connecting the Ethernet cable to the Cabinet system Insert the 50-pin end of the cable into the cable connector on the left side of the retaining bar.
Page 291 Installing and connecting SDI and Ethernet ports Page 291 of 562 The Ethernet cable is a 50-pin amphenol to 15-pin AUI adaptor cable (Part number for Ethernet cable NTDK27 A06030723). This provides a standard Medium Access Unit (MAU) attachment point. Note: A jumper block located on connector J7 (near the Fiber 2 connector) (see Figure 118 on page 290...
Page 292: Chassis System Ethernet Connection
Page 292 of 562 Installing and connecting SDI and Ethernet ports Chassis system Ethernet connection The Chassis system provides a 10 Mbit Ethernet connection to a Local Area Network (LAN). The Ethernet cable connector is at the back of the chassis on the bottom left-hand side.
Page 293 Installing and connecting SDI and Ethernet ports Page 293 of 562 Insert the Ethernet cable into the MAU. See Figure 121. Note: When the time comes to configure the Ethernet link, use LD 117. Figure 121 Ethernet cable inserted into an industry-standard MAU Industry-standard End of Procedure Small System...
Page 294 Page 294 of 562 Installing and connecting SDI and Ethernet ports 553-3011-210 Standard 1.00 October 2003...
Page 295 Page 295 of 562 Starting the Chassis system Contents This section contains information on the following topics: Introduction ..........Startup procedures.
Page 296 Page 296 of 562 Starting the Chassis system Procedure 47 Startup procedure for a new system installation, using the Small System Controller card Test the power outlet. Make sure that the correct voltage of power is present before you plug the power cord into the outlet. The source must match the label on the back of the chassis.
Page 297 Starting the Chassis system Page 297 of 562 Observe the TTY or terminal screen. The TTY must be connected to TTY port 0. When you have completed the software installation (see “Installing software in a new system” on page 304), observe the screen again. Perform an EDD using LD 43.
Page 298 Page 298 of 562 Starting the Chassis system 553-3011-210 Standard 1.00 October 2003...
Page 299: Introduction
Page 299 of 562 Installing software Contents This section contains information on the following topics: Introduction ..........Software Installation Program .
Page 300: Software Installation Program
Page 300 of 562 Installing software Software Installation Program The Software Installation Program provides a menu-driven method of selecting from the different options of installing, modifying, or upgrading the following: • software • customer data • feature set • Incremental Software Management (ISM) parameters The flash ROM stores information about the selections.
Page 301: Keycodes
ISM parameters. Note: Contact your Nortel Networks representative if the Keycode Data Sheet is missing. The Software Installation Program validates the keycodes. If the keycodes are valid, the installation function continues.
Page 302: Feature Set And Ism Parameters
Page 302 of 562 Installing software If the keycodes are unsuccessful, check the following: • software issue • feature set name • any additional packages • • ISM parameters • security ID • auxiliary ID (the old site ID, if this is an upgrade) •...
Page 303: Security Device
Installing software Page 303 of 562 Security device A security device comes with each new Small System. Attach this device to the component side of the NTDK20 Small System Controller (SSC) card at the time of initial installation. The security device remains there for the life of the system.
Page 304: Installing Software In A New System
Page 304 of 562 Installing software Backed up Database The Backed up Database option allows the copy on the backup flash drive to be installed. It is provided to recover a customer database if the customer database on the primary flash drive becomes corrupted. Installing software in a new system Before beginning the software installation process, complete Step 1 through Step 9 in “Installing a new Cabinet system”...
Page 305 Installing software Page 305 of 562 12 Reboot the main cabinet or chassis. 13 Wait for link to come up. Note: IP expansion cabinet or chassis software must be the same software version as the main cabinet or chassis. CAUTION WITH ESDS DEVICES Wear the antistatic wrist strap provided in the bottom of the cabinet before handling circuit cards.
Page 306 Page 306 of 562 Installing software Observe the terminal screen. Then The following is displayed: Proceed to step 5. SOFTWARE INSTALLATION PROGRAM The following is displayed: Proceed to step 4. current system time and date: 00:00:00 -- 00/00/00 The following is displayed: Proceed to step 3.
Page 307 Installing software Page 307 of 562 Figure 123 PC Card slot location PC Card in Slot A Set the system time and date. Note: The Time and Date prompt appears only when the Install Setup Program detects a system Year Date that is not in the range of 1995– 2095.
Page 308 Page 308 of 562 Installing software Select Main Menu option 1 for a new installation. If you are installing from a PC Card, select item 4. Call Server/Main Cabinet Software Installation Main Menu: 1. New Install or Upgrade from Option 11/11E - From Software Daughterboard 2.
Page 309 Installing software Page 309 of 562 Indicate if you want to add packages. Feature Set Selection: Enhanced Business Do you wish to add packages? Select no, yes or abort: n <CR> (no) y <CR> (yes) a <CR> (abort) Note: Abort returns you to the main menu. If the response was NO go to step 11 on page 310.
Page 310 Page 310 of 562 Installing software 11 Select a database. If you are installing from a PC Card, go to Step 12 on page 310. If you are installing from an SSC card, continue here. Select menu option 1 or 2 for a new system installation: 1.
Page 311 Installing software Page 311 of 562 13 Select an Archived Database. The terminal screen displays the available archived databases. The following are examples only. Archived Database available: 1. Company ABC 2. XYZ.Offices 3. Green.Packaging [q]uit, [m]ain menu, [p]revious menu, <CR> - redisplay 14 Confirm database selection.
Page 312 Page 312 of 562 Installing software ANALOGUE TELEPHONES (2500) (maximum number of analogue sets) ATTENDANT CONSOLES (2500) (maximum number of attendant sets) BRI DSL (100) (maximum number of Digital Subscriber Loops) CLASS TELEPHONES (2500) (maximum number of class sets) DATA PORTS (2500) (maximum number of data ports) DIGITAL TELEPHONES (2500) (maximum number of Digital sets) INTERNET TELEPHONES (0) (maximum number of Internet sets) PHANTOM PORTS (2500) (maximum number of phantom ports)
Page 313 Installing software Page 313 of 562 LTID (100) RAN CON (12) RAN RTE (2500) MUS CON (100) BRAND (0) ACD AGENTS (300) ANALOGUE TELEPHONES (2500) ATTENDANT CONSOLES (2500) BRI DSL (100) CLASS TELEPHONES (2500) DATA PORTS (2500) DIGITAL TELEPHONES (2500) INTERNET TELEPHONES (0) PHANTOM PORTS (2500) WIRELESS TELEPHONES (2500)
Page 314 Page 314 of 562 Installing software MUS CON (100) BRAND (0) ACD AGENTS (300) ANALOGUE TELEPHONES (2500) ATTENDANT CONSOLES (2500) BRI DSL (100) CLASS TELEPHONES (2500) DATA PORTS (2500) DIGITAL TELEPHONES (2500) INTERNET TELEPHONES (0) PHANTOM PORTS (2500) WIRELESS TELEPHONES (2500) WIRELESS VISITORS (0) ITG ISDN TRUNKS (2500) TRADITIONAL TRUNKS (2500)
Page 315 Installing software Page 315 of 562 18 Define the AUX ID. Note: The default AUX ID is the system ID provided with the Small System. Example: Security ID: 10000326 Current AUX ID: 10000326 Do you wish to change the AUX ID? y <CR>...
Page 316 Page 316 of 562 Installing software S/W Release: 2520F 2520X ISM Parameters TNS: 100 200 ACDN: 300 300 AST: 100 100 LTID: 100 100 RAN CON 12 12 RAN RTE 2500 2500 MUS CON 100 100 BRAND 0 0 ACD AGENTS 300 300 ANALOGUE TELEPHONES 2500 2500 ATTENDANT CONSOLES 2500 2500 BRI DSL 100 100...
Page 317 Installing software Page 317 of 562 Is this correct? y <CR> (yes) n <CR> (no) a <CR> (abort, return to main menu) If the response was NO, go to Step 7 on page 308. If the response was YES, go to Step 21 on page 317.
Page 318: Software Installation On The Ip Expansion Cabinet Or Chassis Using The Preprogrammed Software Daughterboard
Page 318 of 562 Installing software If the response was NO, go to step 5 on page 308. If the response was YES, this is the end of the Software Installation Program. Continue with the next step (step 23). 23 Observe the screen a second time once the installation program has been completed.
Page 319 Installing software Page 319 of 562 Procedure 50 Installing software for IP expansion, using the preprogrammed software daughterboard Power up the system, and the menu in step 2 appears. IMPORTANT! BootP is a broadcast message used for IP Address discovery. •...
Page 320 Page 320 of 562 Installing software Is this correct? y <CR> (yes) n <CR> (no) a <CR> (abort, return to main menu) Note: “Expansion Router/Gateway” appears only in a Layer 3 configuration. The software installation completes automatically without user intervention. Refer to LD 117 in Software Input/Output: Maintenance (553-3001-511) to configure the IP Address of the IP expansion cabinet or chassis.
Page 321: Introduction
Page 321 of 562 IP Line card configuration Contents This section contains information on the following topics: Introduction ..........Voice Gateway Media Card configuration on the Small System .
Page 322: Voice Gateway Media Card Configuration On The Small System
Page 322 of 562 IP Line card configuration There are three types of IP Line card: • the ITG-P 24-port line card (occupies 2 slots) • the Succession Media Card 8-port line card (occupies 1 slot) • the Succession Media Card 32-port line card (occupies 1 slot) If a Succession Media Card 32-port card, a Succession Media Card 8-port card, or an ITG-P 24-port card is running IP Line 3.1 software, it is known as a Voice Gateway Media Card.
Page 323 IP Line card configuration Page 323 of 562 the following procedures. Certain special considerations apply for a survivable Small System. Refer to “IP Line in survivable Small Systems” on page 517. Configure the Voice Gateway Media Card on the main and IP expansion cabinets or chassis.
Page 324: Configuring Voice Gateway Media Cards On Cabinets Or Chassis
Page 324 of 562 IP Line card configuration Configuring Voice Gateway Media Cards on cabinets or chassis Use Procedures 51 and 52 to configure the Small System’s main cabinet or chassis and any IP expansion cabinets or chassis. Procedure 51 Configuring the ELAN IP address for the Small System active ELNK Ethernet interface on the main cabinet or chassis, if not already defined Go into LD 117.
Page 325 IP Line card configuration Page 325 of 562 Update the ELAN configuration. Enter the following command: UPDATE DBS Reboot the main cabinet or chassis for the changes to take effect or go into LD 137 and disable and enable the ELNK. Enter the following commands: DIS ELNK ENL ELNK...
Page 326: Configuring Ip Line Data
Page 326 of 562 IP Line card configuration PRT ELNK Activate New Host entry. Enter the following command: CHG ELNK ACTIVE <hostname> <cab#> Where: <cab#> = 1–4 for IP expansion cabinets or chassis Update the ELAN configuration. Enter the following command: UPDATE DBS Reboot the main cabinet for the changes to take effect or go into LD 137 and disable and enable the ELNK.
Page 327 IP Line card configuration Page 327 of 562 Configure the main cabinet or chassis ELAN IP address, survivable IP expansion cabinet or chassis ELAN IP address, and TLAN voice port. Enter the Small System IP ELAN address of the main cabinet or chassis. Define the survivable IP expansion cabinet or chassis IP address in OTM.
Page 328: Transmitting Ip Line Node Configuration Data
Page 328 of 562 IP Line card configuration Figure 124 OTM 2.1 primary and secondary IP addresses Transmitting IP Line node configuration data IP Line node and card properties are configured in the OTM IP Line IP Phones application and then transmitted to the IP Line cards. OTM converts the configuration data to text files and transmits files to the line cards.
Page 329: Configuring Ip Line Data With Element Manager
IP Line card configuration Page 329 of 562 Configuring IP Line data with Element Manager Refer to IP Line: Description, Installation and Operation (553-3001-365) and Internet Terminals (553-3001-368) for a detailed description of the procedures listed below. Manually add an IP Telephony node. Do not use this node anywhere else. It is unique for this cabinet or chassis.
Page 330: Transferring Node Configuration From Element Manager To
Page 330 of 562 IP Line card configuration Figure 125 Element Manager LAN configuration Transferring node configuration from Element Manager to the Voice Gateway Media Cards The IP Telephony node and card properties are configured using Element Manager. The configuration data is saved to the Call Server and then transferred to the Voice Gateway Media Cards.
Page 331 IP Line card configuration Page 331 of 562 (553-3001-365) and Telephones and Consoles (553-3001-367) for additional information. If you must upgrade the software, the preferred method of software delivery is directly from the ESD website. When Internet access is restricted or unavailable from the OTM PC, order the latest software on CD-ROM, and insert the CD-ROM into the CD-ROM drive on the OTM PC.
Page 332 Page 332 of 562 IP Line card configuration 553-3011-210 Standard 1.00 October 2003...
Page 333: Introduction
Page 333 of 562 Connecting the telephones Contents This section contains information on the following topics: Introduction ..........Cable assignments for the Cabinet system .
Page 334 Page 334 of 562 Connecting the telephones This chapter contains the following procedures: • Procedure 53: “Cross-connecting telephones” on page 335 • Procedure 54: “Connecting telephones without a PFTU” on page 337 • Procedure 55: “Connecting 500/2500-type telephones with a PFTU” on page 338 •...
Page 335: Cable Assignments For The Cabinet System
Connecting the telephones Page 335 of 562 Cable assignments for the Cabinet system The cables from each cabinet are labeled J1 through J10 at the cross-connect terminal. Each cable represents a specific set of Terminal Numbers (TNs) as shown in Table 43 on page 344.
Page 336 Page 336 of 562 Connecting the telephones Figure 126 NE-500/2500-type telephone cross-connections 553-3011-210 Standard 1.00 October 2003...
Page 337: Connecting Telephones Without A Pftu
Connecting the telephones Page 337 of 562 Figure 127 Meridian Digital Telephone cross-connections Connecting telephones without a PFTU Procedure 54 Connecting telephones without a PFTU Locate the telephone terminations on the cross-connect terminal. Connect one end of the cross-connect wire to the leads of the telephone. Locate the line card terminations on the cross-connect terminal.
Page 338: Connecting Analog 500/2500-Type Telephones With A Pftu
Page 338 of 562 Connecting the telephones Now, you can activate the telephone, as described in “Activating telephones” on page 350. End of Procedure Connecting analog 500/2500-type telephones with a PFTU Procedure 55 Connecting 500/2500-type telephones with a PFTU Locate the telephone terminations on the cross-connect terminal. Connect one end of the cross-connect wire to the leads of the telephone.
Page 339: Connecting Off-Premise Telephones
Connecting the telephones Page 339 of 562 Connecting off-premise telephones Connect off-premise analog (500/2500-type) telephones through an NTAK92AA Off-Premise Protection Module. Each module can connect up to four analog (500/2500-type) telephones and can interface with one of the following: • NT1R20 Off-Premise Station Analog Line Card •...
Page 340 Page 340 of 562 Connecting the telephones Procedure 56 Connecting an off-premise telephone Mount the NTAK92AA Off-Premise Protection Module on the wall using four #10 1/2 in. (minimum) screws. Connect a #6 AWG (#40 Metric Wire Gauge) from the ground lug at the bottom of the NTAK92AA Off-Premise Protection Module to an earth ground.
Page 341 Connecting the telephones Page 341 of 562 Figure 128 NTAK92AA Off-Premise Protection Module connections Cross-connect terminal block BL - 1W BL - 2W O - 1W O - 2W To off-premise G - 1W telephones G - 2W BR - 1W BR - 2W NTAK92AA Off-Premise...
Page 342: Connecting An Attendant Console
Page 342 of 562 Connecting the telephones Connecting an attendant console Procedure 57 Connecting attendant console Locate the attendant console terminations at the cross-connect terminal. Locate the line card terminations at the cross-connect terminal. With cross-connect wire, connect the line card and other connections to the console as shown in Figure 129 on page 343.
Page 343 Connecting the telephones Page 343 of 562 Figure 129 Attendant console connections Small System Installation and Configuration...
Page 344 Page 344 of 562 Connecting the telephones Table 43 Terminal number assignments — Main and Expansion Cabinets 1 and 2 (Part 1 of 2) Card First TN..Last TN Cable Cabinet 01 00..01 15 Main 02 00..02 15 Main 03 00..03 15 Main 04 00..04 15 Main...
Page 345 Connecting the telephones Page 345 of 562 Table 43 Terminal number assignments — Main and Expansion Cabinets 1 and 2 (Part 2 of 2) Card First TN..Last TN Cable Cabinet 21 00..21 15 Expansion Cabinet 2 22 00..22 15 Expansion Cabinet 2 23 00..23 15 Expansion Cabinet 2 24 00..24 15...
Page 346 Page 346 of 562 Connecting the telephones Table 44 Terminal number assignments – Expansion Cabinets 3 and 4 (Part 2 of 2) Card First TN..Last TN Cable Cabinet 39 00..39 15 Expansion Cabinet 3 40 00..40 15 Expansion Cabinet 3 41 00..41 15 Expansion Cabinet 4 42 00..42 15...
Page 347 Connecting the telephones Page 347 of 562 Table 45 Terminal Number assignments — Chassis and chassis expander Physical slot Logical slot First TN...Last TN Cable Chassis 01 00...01 15 Card 1 Main 02 00...02 15 Card 2 Main 03 00...03 15 Card 3 Main 04 00...04 15...
Page 348 Page 348 of 562 Connecting the telephones Table 46 Power Failure Transfer Unit connections (Part 1 of 2) QUA6 J1 Cable Function Pair Color Connects to Connect to the telephone R-BL Connect to the telephone line card BL-R PFT 1 Connect to the Central Office trunk Connect to the trunk line card R-BR...
Page 349 Connecting the telephones Page 349 of 562 Table 46 Power Failure Transfer Unit connections (Part 2 of 2) QUA6 J1 Cable Function Pair Color Connects to Connect to the telephone Connect to the telephone line card PFT 4 Y-BR Connect to the Central Office trunk BR-Y Connect to the trunk line card V-BL...
Page 350: Cross-Connecting Terminal Digital Subscriber Loops
Page 350 of 562 Connecting the telephones Table 47 Cable Pair Color Combinations W-Bl W-BR R-BL Color Bl-W BR-W BL-R Unit R-BR BK-BL BK-O BK-G BK-BR BK-S Color BR-R BL-BK O-BK G-BK BR-BK S-BK Unit Cross-connecting terminal Digital Subscriber Loops Refer to ISDN Basic Rate Interface: Installation and Configuration (553-3001-218) for a complete description of terminal Digital Subscriber Loops (DSL) cross-connecting and installation.
Page 351 Connecting the telephones Page 351 of 562 Telephone tones There are a number of different telephone tones. Table 48 on page 351 includes tones that you hear during telephone activation. Table 49 on page 351 includes tones that you hear during telephone activation in Germany.
Page 352: Activating A Default Model With A Character Display
Page 352 of 562 Connecting the telephones Note 1: Before you activate a telephone, make sure that you have decided on its final location. Also, know the model number assigned to the telephone and if it is to be customized. Note 2: When you are activating Meridian Digital Telephones, remember that they are different from the older Meridian Modular Telephones.
Page 353 Connecting the telephones Page 353 of 562 If the extension number is already in use by another telephone, you hear the special dial tone. If the telephone has a display it shows “MULTI-LINE, EXTENSION?”. To accept the default extension number press the pound key. To select a new extension number, manually enter an extension number and press the pound key.
Page 354: Activating A Default Model Without A Character Display
Page 354 of 562 Connecting the telephones Activating a default model without a character display Procedure 59 Activating a default model telephone without a character display Plug the telephone set into the jack and wait 20 seconds before picking up the handset. If you do not receive dial tone, replace the handset and wait another 10 seconds before going off-hook again.
Page 355: Activating A Customized Model With A Character Display
Connecting the telephones Page 355 of 562 Activating a customized model with a character display Procedure 60 Activating a customized telephone Plug the telephone set into the jack and wait 20 seconds before picking up the handset. If you do not receive dial tone, replace the handset and wait another 10 seconds before going off-hook again.
Page 356: Activating A Customized Model Without A Character Display
Page 356 of 562 Connecting the telephones If the extension number is not available for use, you hear overflow tone. The character display shows “ERROR, EXTENSION?” and you must repeat this step. Note: If other keys require secondary extension numbers, you are prompted until you enter all of the required extension numbers for the model.
Page 357: Activating Terminals On A Dsl
Connecting the telephones Page 357 of 562 You hear a short high-pitched beep lasting four seconds, followed by silence (relocation tone). If the extension number is already in use by another telephone, you hear special dial tone again. If the extension number is not available for use, you hear a fast, high-pitched broken tone (overflow tone), and you must repeat this step.
Page 358 Page 358 of 562 Connecting the telephones 553-3011-210 Standard 1.00 October 2003...
Page 359 Page 359 of 562 Connecting the trunks Contents This section contains information on the following topics: Introduction ..........Connecting trunks without PFTU .
Page 360: Introduction
Page 360 of 562 Connecting the trunks Introduction This chapter describes how to connect trunks directly to the trunk card, with or without the use of a Power Failure Transfer Unit (PFTU). This chapter contains the following procedures: • Procedure 62: “Connecting trunks without PFTU” on page 361 •...
Page 361: Connecting Trunks Without Pftu
Connecting the trunks Page 361 of 562 Connecting trunks without PFTU Procedure 62 Connecting trunks without PFTU From the assignment record, determine the location of the trunk connection and its associated Terminal Number (TN) at the cross-connect terminal. With cross-connect wire, connect the trunk to the TN. Make sure that the wiring is not reversed and is on the correct terminals.
Page 362 Page 362 of 562 Connecting the trunks Table 50 Power Failure Transfer Unit connections (Part 1 of 2) QUA6 J1 cable Function Pair Color Connects to Comments Connect to the telephone R-BL Connect to the Connect to TN assigned to BL-R telephone line card the telephone...
Page 363 Connecting the trunks Page 363 of 562 Table 50 Power Failure Transfer Unit connections (Part 2 of 2) QUA6 J1 cable Function Pair Color Connects to Comments Connect to the telephone Connect to the Connect to TN assigned to telephone line card the telephone Y-BR Connect to the Central...
Page 364: Trunk Connections
Page 364 of 562 Connecting the trunks Trunk connections NT8D14 Universal Trunk card The Universal Trunk card provides eight analog trunks which can function in the modes shown in Table 51. Table 51 NT8D14 Universal Trunk — modes and option settings Modes Location Jumper strap...
Page 365 Connecting the trunks Page 365 of 562 Refer to Table 52 for the connections to the NT8D14 Universal Trunk at the cross-connect terminal. Table 52 NT8D14 Universal Trunk connections (Part 1 of 2) Cable from cabinet or chassis Designations Paging All other Pair Color...
Page 366 Page 366 of 562 Connecting the trunks Table 52 NT8D14 Universal Trunk connections (Part 2 of 2) Cable from cabinet or chassis Designations Paging All other Pair Color Unit # mode mode modes BK-BL BL-BK BK-O O-BK BK-G G-BK BK-BR BR-BK BK-S S-BK...
Page 367: Nt8D15 E&M Trunk Card
Connecting the trunks Page 367 of 562 NT8D15 E&M Trunk card Table 53 NT8D15 E&M Trunk card (Part 1 of 2) Cables J1 through J10 from cabinet/Card 1 through Card 10 from chassis Designations Paging Type 1 Type 1 Type 2 Pair Color Unit #...
Page 368 Page 368 of 562 Connecting the trunks Table 53 NT8D15 E&M Trunk card (Part 2 of 2) Cables J1 through J10 from cabinet/Card 1 through Card 10 from chassis Designations Paging Type 1 Type 1 Type 2 Pair Color Unit # mode mode mode...
Page 369: Nt6D70 Silc And Nt6D71 Uilc Cards
Connecting the trunks Page 369 of 562 NT6D70 SILC and NT6D71 UILC cards Refer to ISDN Basic Rate Interface: Installation and Configuration (553-3001-218) for a complete description of trunk DSL installation and connections. Small System Installation and Configuration...
Page 370: Trunk Connections (Europe)
Page 370 of 562 Connecting the trunks Trunk connections (Europe) E&M TIE trunk card (2-wire) Note: Refer to Circuit Card: Description and Installation (553-3001-211) for a complete description of European circuit cards. Table 54 E&M TIE trunk card (2-wire) Cables J1 through J10 from cabinet/Card 1 through Card 10 from chassis...
Page 371 Connecting the trunks Page 371 of 562 Table 55 E&M 2-wire Type 2 Lead designations Pins Pair color Unit number Unit R-BL BL-R Unit Unit BK-BL BL-BK BK-O O-BK BK-BR BR-BK Unit BK-S S-BK Y-BL BL-Y Small System Installation and Configuration...
Page 372: E&M Tie Trunk Card (4-Wire)
Page 372 of 562 Connecting the trunks E&M TIE trunk card (4-wire) Table 56 E&M TIE trunk card (4-wire) (Part 1 of 2) Cables J1 through J10 from cabinet/Card 1 through Card 10 from chassis Typical lead designations Pair Color Unit # Pins Type 1 &...
Page 373 Connecting the trunks Page 373 of 562 Table 56 E&M TIE trunk card (4-wire) (Part 2 of 2) Cables J1 through J10 from cabinet/Card 1 through Card 10 from chassis Typical lead designations Pair Color Unit # Pins Type 1 & 5 Type 1 &...
Page 374 Page 374 of 562 Connecting the trunks Table 57 E&M TIE trunk card (4-wire) (Part 1 of 2) Cables J1 through J10 from cabinet/Card 1 through Card 10 from chassis Typical lead designations Pair Color Unit # Pins Type 2 Type 2 W-BL BL-W...
Page 375 Connecting the trunks Page 375 of 562 Table 57 E&M TIE trunk card (4-wire) (Part 2 of 2) Cables J1 through J10 from cabinet/Card 1 through Card 10 from chassis Typical lead designations Pair Color Unit # Pins Type 2 Type 2 R-BR BR-R...
Page 376: E&M Tie Trunk Card (2280 Hz)
Page 376 of 562 Connecting the trunks E&M TIE trunk card (2280 Hz) Table 58 E&M 2280 Hz TIE trunk connections Lead designations Pins Pair color Unit # W-BL BL-W R-BL BL-R R-BR BR-R BK-G G-BK BK-BR BR-BK 553-3011-210 Standard 1.00 October 2003...
Page 377: E&M Tie Trunk Card (Ran)
Connecting the trunks Page 377 of 562 E&M TIE trunk card (RAN) Table 59 E&M 2-wire Recorded Announcement trunk connections Lead designations Pins Pair color Unit # W-BL BL-W SIG B W-BR SIG A BR-W SIG B SIG A R-BR BR-R SIG B BK-O...
Page 378: E&M Tie Trunk Card (Mus)
Page 378 of 562 Connecting the trunks E&M TIE trunk card (MUS) Table 60 E&M 2-wire Music trunk connections Lead designations Pins Pair color Unit# W-BL BL-W R-BR BR-R BK-G G-BK CO & DID trunk card Table 61 Central Office & Direct Inward Dial trunk connection (Part 1 of 2) Cable from cabinets or chassis Lead designations...
Page 379 Connecting the trunks Page 379 of 562 Table 61 Central Office & Direct Inward Dial trunk connection (Part 2 of 2) Cable from cabinets or chassis Lead designations Pair Color Unit # Pins Column 1 Column 2 Column 3 R-BL PPM2 BL-R —...
Page 380: Central Office Trunk Card
Page 380 of 562 Connecting the trunks Central Office trunk card Table 62 Central Office trunk connections (Part 1 of 2) Cable from cabinets or chassis Pair Color Unit # Pins Lead designations W-BL BL-W W-BR BR-W R-BL BL-R R-BR BR-R BK-BL BL-BK...
Page 381: Trunk Connections (Uk)
Connecting the trunks Page 381 of 562 Table 62 Central Office trunk connections (Part 2 of 2) Cable from cabinets or chassis Pair Color Unit # Pins Lead designations BK-G G-BK BK-BR BR-BK BK-S S-BK Y-BL BL-Y Trunk connections (UK) NT5K17 Direct Inward Dial card terminations Cross-connect the NT5K17 DID card as shown in Table 63.
Page 382 Page 382 of 562 Connecting the trunks Table 63 NT5K17 DID cross-connect terminations (Part 2 of 2) Pair Pins Pair color Unit # R-BL BL-R R-BR BR-R BK-BL BL-BK BK-O O-BK BK-G G-BK BK-BR BR-BK BK-S S-BK Y-BL BL-Y 553-3011-210 Standard 1.00 October 2003...
Page 383: Nt5K18 Exchange Line Trunk Card Terminations
Connecting the trunks Page 383 of 562 NT5K18 Exchange line trunk card terminations Cross-connect the NT5K18 Exchange line trunk card as shown in Table 64. Note: The connections on the NT5K18 Exchange line trunk card are polarity sensitive. Make sure the ground side of the trunk is connected to the A leg of the NT5K18 circuit.
Page 384 Page 384 of 562 Connecting the trunks Table 64 NT5K18 Exchange line trunk card cross-connect terminations (Part 2 of 2) Pair Pins Pair color Unit # BK-BL BL-BK BK-O O-BK BK-G G-BK BK-BR BR-BK BK-S S-BK Y-BL BL-Y 553-3011-210 Standard 1.00 October 2003...
Page 385: Nt5K19 Analog Tie Line Trunk Card Terminations
Connecting the trunks Page 385 of 562 NT5K19 Analog TIE line trunk card terminations Cross connect the NT5K19 analog TIE line trunk card as shown in Table 65 page 385. Note: The speech pairs on the NT5K19 card are polarity insensitive. The E&M signalling pairs, however, are polarity sensitive.
Page 386 Page 386 of 562 Connecting the trunks Table 66 NT5K19 2W Type 1 mode terminations Pair Pins Pair color Unit # R-BL BL-R & BK-BL BL-BK BK-BR BR-BK BK-S S-BK 553-3011-210 Standard 1.00 October 2003...
Page 387 Connecting the trunks Page 387 of 562 Table 67 NT5K19 4W Type 1 mode terminations Pair Pins Pair color Unit # W-BL BL-W R-BL BL-R R-BR BR-R BK-BL BL-BK BK-G G-BK BK-BR BR-BK BK-S S-BK Small System Installation and Configuration...
Page 388 Page 388 of 562 Connecting the trunks Table 68 NT5K19 AC15 mode pair terminations Pair Pins Pair color Unit # W-BL BL-W R-BL BL-R R-BR BR-R BK-G G-BK BK-BR BR-BK 553-3011-210 Standard 1.00 October 2003...
Page 389: Activating A Default Model Trunk
Connecting the trunks Page 389 of 562 Table 69 NT5K19 Recorded Announcement mode pair terminations Pair Pins Pair color Unit # W-BL BL-W SIG B W-BR SIG A BR-W SIG B SIG A R-BR BR-R SIG B BK-O SIG A O-BK BK-G G-BK...
Page 390 Page 390 of 562 Connecting the trunks Enter the default administration telephone password. You hear special dial tone, and the prompt “TASK?” appears in the top line of the character display. The second line of the display reads “1 ADD TRUNK”. Select “1 ADD TRUNK”...
Page 391: Activating A Selected Model Trunk
Connecting the trunks Page 391 of 562 By entering “#” when the procedure repeats, you accept the next TN and are prompted for the model type. By entering “#” again, you accept the previously accepted model. Note: The model chosen during the first trunk activation sequence will be the default model for all subsequent trunks until you hang up the telephone or manually enter a new trunk model number.
Page 392 Page 392 of 562 Connecting the trunks Enter the TN in Small System format (cu). The response “MODEL?” prompts you to select a model number for the trunk. Enter a trunk model number for the specified TN and route, and press the pound key.
Page 393 Page 393 of 562 Connecting an external alarm Contents This section contains information on the following topics: Introduction ..........Alarm port assigned in software .
Page 394 Page 394 of 562 Connecting an external alarm The alarm will operate when a BSD090 message indicates a power fault in the system. Information about BSD090 messages is contained in Software Input/Output: Maintenance (553-3001-511). Procedure 66 Installing an alarm using an alarm port Install an analog (500/2500-type) line as described in “Connecting the telephones”...
Page 395 Connecting an external alarm Page 395 of 562 Alarm through a QUA6 PFTU A QUA6 PFTU can be used to connect an external alarm through normally open or normally closed contacts of one of its units. The contacts operate under the same conditions as the PFTU, and can support the capacities listed in Table 70.
Page 396 Page 396 of 562 Connecting an external alarm Figure 130 Contacts in PFTU 553-3011-210 Standard 1.00 October 2003...
Page 397 Connecting an external alarm Page 397 of 562 Table 71 Power Failure Transfer Unit connections (Part 1 of 2) Unit Pair Color Normal mode Failure mode Makes with 6T Opens 6T and 6R and 6R Makes with 7T and 7R R-BL Makes with 5T Open...
Page 398 Page 398 of 562 Connecting an external alarm Table 71 Power Failure Transfer Unit connections (Part 2 of 2) Unit Pair Color Normal mode Failure mode Makes with 18T Opens 18T and 18R and 18R Makes with 19T and 19R Makes with 17T Open and 17R...
Page 399 Page 399 of 562 Preprogrammed data Contents This section contains information on the following topics: Introduction ..........Passwords and codes .
Page 400: Introduction
You must, for example, assign features to telephone keys for the telephones to work correctly. Nortel Networks or its distributors can program the Small System’s Software Daughterboard with customer data before they send the card to the customer site.
Page 401: Passwords And Codes
Preprogrammed data Page 401 of 562 Passwords and codes Table 72 shows each function in the left column and a corresponding password or code on the right. Table 72 Passwords and codes Function Code or extension(s) TTY password 0000 (for access to TTY Small System overlays) Meridian Mail administration password adminpwd Administration telephone password...
Page 402: First Digits
Page 402 of 562 Preprogrammed data • For the Cabinet system: Meridian Mail Virtual Agents are preconfigured for Card 10 in Unit 0, 1, 2, 8, 9, and 10 of the main cabinet. For the Chassis system: Meridian Mail Virtual Agents are preconfigured for card slot 10 in Units 0, 1, 2, 4, 5, 8, 9, 10, 11, 12, and 13 of the chassis expander.
Page 403 Preprogrammed data Page 403 of 562 Note: The first number of the default numbering plan is preprogrammed as 2200. The remaining numbers in the default numbering plan are assigned in software. These numbers do not become active, however, until you select the numbers during the telephone activation procedure. The digit “7”...
Page 404: Important Extension Numbers
Page 404 of 562 Preprogrammed data Important extension numbers Table 74 Default numbering plan — important extension numbers Extension Attendant extension First number in numbering plan 2200 Night number 7700* Queue for Central Answering Position 7700* General ACD queue 7750* Meridian Mail miscellaneous ACD queues: 7000–7009 •...
Page 405: Extensions Assigned To Card Slots
Preprogrammed data Page 405 of 562 Extensions assigned to card slots For the Cabinet system: Tables 75 through Table 79 provide the extension numbers assigned to card slots in the main and expansion cabinets. For the Chassis system: Table 80 on page 410 provides the extension numbers assigned to card slots in the chassis and chassis expander.
Page 406 Page 406 of 562 Preprogrammed data Table 76 Extensions assigned to card slots in Expansion Cabinet 1 Slot number Extension numbers 2360 through 2375 2376 through 2391 2392 through 2407 2408 through 2423 2424 through 2439 2440 through 2455 2456 through 2471 2472 through 2487 2488 through 2503 2504 through 2519...
Page 407 Preprogrammed data Page 407 of 562 Table 77 Extensions assigned to card slots in Expansion Cabinet 2 Slot number Extension numbers 2520 through 2535 2536 through 2551 2552 through 2567 2568 through 2583 2584 through 2599 2600 through 2615 2616 through 2631 2632 through 2647 2648 through 2663 2664 through 2679...
Page 408 Page 408 of 562 Preprogrammed data Table 78 Extensions assigned to card slots in Expansion Cabinet 3 Slot number Extension numbers 2680 through 2695 2696 through 2711 2712 through 2727 2728 through 2743 2744 through 2759 2760 through 2775 2776 through 2791 2792 through 2807 2808 through 2823 2824 through 2839...
Page 409 Preprogrammed data Page 409 of 562 Table 79 Extensions assigned to card slots in Expansion Cabinet 4 Slot number Extension numbers 2840 through 2855 2856 through 2871 2872 through 2887 2888 through 2903 2904 through 2919 2920 through 2935 2936 through 2951 2952 through 2967 2968 through 2983 2984 through 2999...
Page 410 Page 410 of 562 Preprogrammed data Table 80 Extensions assigned to card slots in the chassis and chassis expander Slot number Card number Extension numbers Chassis 2200 through 2215 2216 through 2231 2232 through 2247 2248 through 2263 2264 through 2279 2280 through 2295 Chassis expander 2296 through 2311...
Page 411 Preprogrammed data Page 411 of 562 Tables 81 through 87 provide the default DN assignments for Cabinet and Chassis systems. Table 81 Main cabinet default DN assignments (Part 1 of 2) Cable Unit Default Directory Number (DN) 2200 2201 2202 2203 2204 2205...
Page 412 Page 412 of 562 Preprogrammed data Table 81 Main cabinet default DN assignments (Part 2 of 2) Cable Unit Default Directory Number (DN) 2336 2337 2338 2339 2340 2341 2342 2343 8 - 15 2344 2345 2346 2347 2348 2349 2350 2351 0 - 7...
Page 413 Preprogrammed data Page 413 of 562 Table 82 Expansion Cabinet 1 default DN assignments (Part 2 of 2) Cable Unit Default Directory Number (DN) 2456 2457 2458 2459 2460 2461 2462 2463 0 - 7 2464 2465 2466 2467 2468 2469 2470 2471...
Page 414 Page 414 of 562 Preprogrammed data Table 83 Expansion Cabinet 2 default DN assignments (Part 2 of 2) Cable Unit Default Directory Number (DN) 2576 2577 2578 2579 2580 2581 2582 2583 8 - 15 2584 2585 2586 2587 2588 2589 2590 2591...
Page 415 Preprogrammed data Page 415 of 562 Table 84 Expansion Cabinet 3 default DN assignments (Part 2 of 2) Cable Unit Default Directory Number (DN) 2696 2697 2698 2699 2700 2701 2702 2703 0 - 7 2704 2705 2706 2707 2708 2709 2710 2711...
Page 416 Page 416 of 562 Preprogrammed data Table 85 Expansion Cabinet 4 default DN assignments (Part 1 of 2) Cable Unit Default Directory Number (DN) 2840 2841 2842 2843 2844 2845 2846 2847 0 - 7 2848 2849 2850 2851 2852 2853 2854 2855...
Page 417 Preprogrammed data Page 417 of 562 Table 85 Expansion Cabinet 4 default DN assignments (Part 2 of 2) Cable Unit Default Directory Number (DN) 2976 2977 2978 2979 2980 2981 2982 2983 8 - 15 2984 2985 2986 2987 2988 2989 2990 2991...
Page 418 Page 418 of 562 Preprogrammed data Table 86 Default DN assignments for the chassis and chassis expander (Part 2 of 2) Cable Unit Default Directory Number (DN) Card 7 0 - 7 2296 2297 2298 2299 2300 2301 2302 2303 Card 7 8 - 15 2304...
Page 419 Preprogrammed data Page 419 of 562 Table 87 lists the default DN assignments for the chassis and chassis expander for Germany. Table 87 Default DN assignments for the chassis and chassis expander (Germany) Cable Unit Default Directory Number (DN) Card 1 0 - 7 Card 1 8 - 15...
Page 420: Flexible Feature Codes
Page 420 of 562 Preprogrammed data Flexible Feature Codes Many administrative procedures use Flexible Feature Code (FFC) data. Table 88 lists the FFCs for the Small Systems. Table 88 Flexible Feature Codes FFC prompt Definition ASRC Automatic Set Relocation AREM Automatic Set Removal Code ADMN Administration Set Access Code...
Page 421: Sdi Ports
Preprogrammed data Page 421 of 562 SDI ports The minimum system port configuration for the Small System is 3 SDI ports, all of which can be found on the Small System’s NTDK20 SSC card. You can obtain additional ports by installing an NTAK02 SDI/DCH circuit card.
Page 422: Enhanced Serial Data Interface (Esdi) Port
Page 422 of 562 Preprogrammed data Enhanced Serial Data Interface (ESDI) port Port 9 is preprogrammed as an ESDI port and supports Meridian Mail. It functions as a Command Status Link with the settings given in Table 90. Table 90 ESDI settings Setting Code...
Page 423: Telephone Tones
Preprogrammed data Page 423 of 562 Telephone tones The telephone tones in North America are as follows: • Dial tone: A continuous tone. • Special dial tone: Three beeps followed by continuous dial tone. • Overflow tone: Like a busy tone, except faster and higher. •...
Page 424: Trunk Routes
Page 424 of 562 Preprogrammed data Trunk routes Table 91 shows preprogrammed trunk route information that you need on hand to activate and modify trunks. Table 91 Preprogrammed trunk route information Route Type Access Code Mode Interface 00 * 7100 –...
Page 425: Trunk Models
Preprogrammed data Page 425 of 562 Call Detail Recording (CDR) output. The CDR is preconfigured as follows: Trunk models Note: All trunks are programmed as immediate start/supervision = Yes, with the exception of trunks with an asterisk (*) next to them. Trunks marked with an asterisk (*) are set for Wink start/supervision = Yes.
Page 426 Page 426 of 562 Preprogrammed data Table 92 Trunk model information (Part 2 of 5) Mode Pack Model Signaling DIP or DTN BIMP and TIMP 3COM/600 3COM/600 3COM/600 3COM/600 3COM/900 3COM/900 3COM/900 3COM/900 —/600 — —/ 600 — 553-3011-210 Standard 1.00 October 2003...
Page 427 Preprogrammed data Page 427 of 562 Table 92 Trunk model information (Part 3 of 5) Mode Pack Model Signaling DIP or DTN BIMP and TIMP 3COM/600 (Wink Start Supv = Yes) 3COM/600 (Wink Start Supv = Yes) 3COM/900 (Wink Start Supv = Yes) 3COM/900 (Wink Start Supv = Yes) 3COM/600...
Page 428 Page 428 of 562 Preprogrammed data Table 92 Trunk model information (Part 4 of 5) Mode Pack Model Signaling DIP or DTN BIMP and TIMP 600/1200 600/1200 3COM/600 3COM/600 3COM/600 3COM/600 3COM/900 3COM/900 3COM/900 3COM/900 —/600 — —/600 — 553-3011-210 Standard 1.00 October 2003...
Page 429 Preprogrammed data Page 429 of 562 Table 92 Trunk model information (Part 5 of 5) Mode Pack Model Signaling DIP or DTN BIMP and TIMP 3COM/600 3COM/600 3COM/600 3COM/600 3COM/900 3COM/900 3COM/900 3COM/900 * These trunks are set for Wink start. Small System Installation and Configuration...
Page 430: Model Telephones
Page 430 of 562 Preprogrammed data Model telephones This section provides model numbers for each telephone type and tables showing the numbering and placement of the keys, and the feature assigned to each key. Note: OPS telephones do not have their own telephone models. You can, however, create OPS models in by entering DD in response to the CDEN prompt in LD 10.
Page 431 Preprogrammed data Page 431 of 562 • M2216 — two models • M3000 — two models Hotel and Motel telephones • 500- and 2500-type telephones — one model • M2006 — two models • M2008 — two models • M2616 — one model Health Care telephones •...
Page 432 Page 432 of 562 Preprogrammed data Table 94 Class of Service options — digital telephones Prompt Meaning Toll Denied Automatic Answerback Denied Automatic Digit Display Hunting Allowed Last Number Redial Allowed Call Forward No Answer Allowed Pickup Allowed Ring Again Allowed Message Waiting Allowed Table 95 Class of Service Options —...
Page 433: Administration Telephone Models
Preprogrammed data Page 433 of 562 Administration telephone models M2008 model 99 Intended use: Administration (maintenance) telephone Assigned Class of Service options: MTA/ADD/LNA/FNA/GPUA/MWA/FBD Table 96 M2008 model 99 Key number position Feature Blank Message Transfer Speed Call (personnel: 99) Forward Conference Small System Installation and Configuration...
Page 434 Page 434 of 562 Preprogrammed data M2616 model 99 Intended use: Administration (maintenance) telephone Assigned Class of Service options: MTA/LNA/FNA/GPUA/MWA/ADD//HFA/FBD Table 97 M2616 model 99 number number Feature position position Feature — — Auto Dial Message Auto Dial Transfer Auto Dial Ring Again Auto Dial Forward...
Page 435: Central Answering Position (Cap) Telephone Models
Preprogrammed data Page 435 of 562 Central Answering Position (CAP) telephone models M2616 and 2216 CAP telephone model 60 Intended use: Central Answering Position telephone Assigned Class of Service options: LNA/FND/GPUA/MWA/ADD/HFD/AGN/FBD/SPV Table 98 M2616 and 2216 CAP telephone model 60 number number Feature...
Page 436: General Business Telephone Models
Page 436 of 562 Preprogrammed data General business telephone models M2000 series telephones The M2000 series telephones — M2112, M2018, M2317, M2009, and M3000 — are limited to a combined total of 128 model telephones. (In other words, there can be no more than a combined total of 128 different models for all the M2000 series telephones.) It is up to you to make sure that the model associated with the telephone you are activating is predefined.
Page 437 Preprogrammed data Page 437 of 562 Table 100 Default features available using M2317 model 20 softkeys Key number position Feature Language Privacy Release Ring Again Transfer Charge Account Calling Party Number Conference Call Park M2317 model 25 Intended use: Two-line general business telephone with message indication and display Assigned Class of Service options: FNA/GPUA/LND/MWA/ADD/FBD Table 101...
Page 438 Page 438 of 562 Preprogrammed data Table 102 Default features available using M2317 model 25 softkeys Key number position Feature Language Privacy Release Ring Again Transfer Charge Account Calling Party Number Conference Message Call Park M2009 model 21 Intended use: Two-line general business telephone Assigned Class of Service options: FND/GPUA/LNA/MWA/NDD/FBD Table 103 M2009 model 21 (Part 1 of 2)
Page 439 Preprogrammed data Page 439 of 562 Table 103 M2009 model 21 (Part 2 of 2) Key number position Feature Conference M2009 model 26 Intended use: Two-line general business telephones with message indication Assigned Class of Service options: FNA/GPUA/LNA/MWA/NDD/FBD Table 104 M2009 model 26 Key number position Feature...
Page 440 Page 440 of 562 Preprogrammed data M2112 model 22 Intended use: Two-line general business telephone Assigned Class of Service options: FND/GPUA/LNA/MWA/NDD/FBD Table 105 M2112 model 22 Key number Key number Feature position position Feature — — Ring Again Auto Dial Pick-Up Auto Dial Call Forward...
Page 441 Preprogrammed data Page 441 of 562 M2018 model 24 Intended use: Two-line general business telephone Assigned Class of Service options: FND/GPUA/LNA/MWA/NDD/FBD Table 107 M2018 model 24 Key number Key number Feature position position Feature Auto Dial Auto Dial Auto Dial Auto Dial Auto Dial Transfer...
Page 442: Analog (500/2500-Type) Telephone Models
Page 442 of 562 Preprogrammed data Table 108 M2018 model 29 (Part 2 of 2) Key number Key number Feature position position Feature Auto Dial Ring Again Auto Dial Pick-Up Auto Dial Call Forward Auto Dial Conference Auto Dial Auto Dial Analog (500/2500-type) telephone models Note: When you are activating an analog (500-type) telephone, you must use an analog (2500-type) telephone to define the features.
Page 443 Preprogrammed data Page 443 of 562 Analog (500/2500-type) support personnel telephone models Table 109 Analog (500/2500-type) telephone models Model Type of telephone Assigned Class of Service options Support personnel telephone with TLD, C6A, CFXD, DTN, FND, GPUA, LNA, XFA, toll denied XRA, FBD Support personnel telephone UNR, C6A, CFXD, DTN, FND, GPUA, LNA,...
Page 444 Page 444 of 562 Preprogrammed data Health care telephone models Note: When you are activating a 500-type telephone, you must use a 2500-type telephone to define the features. Once you have done this, unplug the 2500-type telephone and replace it with the 500-type telephone that you are activating.
Page 445 Preprogrammed data Page 445 of 562 M2006 General business telephone models Table 112 M2006 General business telephone models (Part 1 of 2) Assigned Class of Key number position with Model Intended use Service options assigned feature General business FND, GPUA, LNA, 5 - Transfer telephone MWA, FBD, UNR...
Page 446 Page 446 of 562 Preprogrammed data Table 112 M2006 General business telephone models (Part 2 of 2) Assigned Class of Key number position with Model Intended use Service options assigned feature General business FNA, GPUA, LNA, 5 - Message telephone with message MWA, FBD, TLD 4 - Transfer indicator...
Page 447 Preprogrammed data Page 447 of 562 M2006 model 41 Intended use: Hotel guest room telephone with message indication Assigned Class of Service options: CCSA/MWA/FBD/FNA/CNDD/TLD Table 114 M2006 model 41 Key number position Feature Message Hot * Hot * Hot * Hot * * These keys are Hotlines to various Hotel and Motel services, such as Room service, and the front desk.
Page 448 Page 448 of 562 Preprogrammed data M2008 General business telephone models Table 116 M2008 General business telephone models (Part 1 of 2) Assigned Class of Key number position with Model Intended use Service options assigned feature General business FND, GPUA, LNA, 7 - Auto Dial telephone MWA, NDD, FBD...
Page 449 Preprogrammed data Page 449 of 562 Table 116 M2008 General business telephone models (Part 2 of 2) Assigned Class of Key number position with Model Intended use Service options assigned feature General business FND, GPUA, LNA, telephone with display MWA, ADD, FBD 6 - Auto Dial 5 - Transfer 4 - Ring Again...
Page 450 Page 450 of 562 Preprogrammed data M2008 Two-line general business telephone models Table 117 M2008 Two-line general business telephone models (Part 1 of 2) Assigned Class of Key number position with Model Intended use Service options assigned feature Two-line general FND, GPUA, LNA, 7 - Auto Dial business telephone...
Page 451 Preprogrammed data Page 451 of 562 Table 117 M2008 Two-line general business telephone models (Part 2 of 2) Assigned Class of Key number position with Model Intended use Service options assigned feature Two-line general FNA, GPUA, LNA, business telephone with MWA, ADD, FBD 6 - Message message indication and...
Page 452 Page 452 of 562 Preprogrammed data M2008 manager telephone models Table 118 M2008 Manager telephone models (Part 1 of 2) Assigned Class of Key number position with Model Intended use Service options assigned feature Manager telephone FND, GPUA, LNA, 7 - Transfer MWA, NDD, FBD 6 - Voice Call 5 - Speed Call (personnel: 20)
Page 453 Preprogrammed data Page 453 of 562 Table 118 M2008 Manager telephone models (Part 2 of 2) Assigned Class of Key number position with Model Intended use Service options assigned feature Manager telephone with FND, GPUA, LNA, display MWA, ADD, FBD 6 - Voice Call 5 - Speed Call (personnel: 20) 4 - Ring Again...
Page 454 Page 454 of 562 Preprogrammed data Table 119 M2008 model 40 (Part 2 of 2) Key number position Feature Hot * * These keys are Hotlines to various Hotel and Motel services, such as Room service, and the front desk. You define them when you activate the telephone. M2008 model 41 Intended use: Two-line guest room telephone with message indication Assigned Class of Service options: CCSA/MWA/FBD/FNA/CNDD/TLD...
Page 455 Preprogrammed data Page 455 of 562 M2008 model 50 Intended use: Nurses’ station telephone with speed call Assigned Class of Service options: FND/LNA/GPUA/MWA/NDD/FBD Table 121 M2008 model 50 Key number position Feature Auto Dial Transfer Speed Call Ring Again Pick-Up Forward Conference M2008 model 51...
Page 456 Page 456 of 562 Preprogrammed data Table 122 M2008 model 51 (Part 2 of 2) Key number position Feature Forward Conference M2008 model 52 Intended use: Nurses’ station telephone with speed call and display Assigned Class of Service options: FND/LNA/GPUA/MWA/ADD/FBD Table 123 M2008 model 52 Key number position...
Page 457 Preprogrammed data Page 457 of 562 M2008 model 53 Intended use: Nurses’ station set with message, speed call and display Assigned Class of Service options: FNA/LNA/GPUA/MWA/ADD/FBD Table 124 M2008 model 53 Key number position Feature – Message Speed Call Ring Again Pick-Up Forward Conference...
Page 458 Page 458 of 562 Preprogrammed data M2008 Message center telephone models Table 125 M2008 Message center telephone models Assigned Class of Key number position with Model Intended use Service options assigned feature Message center FND, GPUA, LNA, 7- Message Cancellation telephone MWA, NDD, FBD 6 - Message Indication...
Page 459 Preprogrammed data Page 459 of 562 M2216 ACD telephone models Table 126 M2216 ACD telephone models Assigned Class of Service Model Intended use options Key number position with assigned feature ACD agent with LNA, FND, 15 - Auto Dial display GPUA, MWA, 14 - Auto Dial 6 - Transfer...
Page 460: Digital Telephone Models
Page 460 of 562 Preprogrammed data Digital telephone models M2616 Secretary telephone models Table 127 M2616 Secretary telephone models Assigned Class of Service Model Intended use options Key number position with assigned feature Secretary LNA, FND, 15 - Auto Dial telephone with GPUA, MWA, 14 - Auto Dial...
Page 461 Preprogrammed data Page 461 of 562 M2616 Advanced business telephone Table 128 M2616 Advanced telephone models (Part 1 of 2) Assigned Class of Service Model Intended use options Key number position with assigned feature Advanced LNA, FND, 15 - 7 - Transfer business GPUA, MWA, 14 - Auto Dial...
Page 462 Page 462 of 562 Preprogrammed data Table 128 M2616 Advanced telephone models (Part 2 of 2) Assigned Class of Service Model Intended use options Key number position with assigned feature Advanced LNA, FND, 15 - business GPUA, MWA, 14 - Auto Dial 6 - Speed Call telephone with ADD, HFA, FBD...
Page 463 Preprogrammed data Page 463 of 562 M2616 Manager telephone models Table 129 M2616 Manager telephone models (Part 1 of 2) Assigned Class of Service Model Intended use options Key number position with assigned feature Manager LNA, FND, 15 - 7 - Transfer telephone GPUA, MWA, 14 - Auto Dial...
Page 464 Page 464 of 562 Preprogrammed data Table 129 M2616 Manager telephone models (Part 2 of 2) Assigned Class of Service Model Intended use options Key number position with assigned feature Manager LNA, FND, 15 - telephone with GPUA, MWA, 14 - Auto Dial 6 - Speed Call display ADD, HFA, FBD...
Page 465 Preprogrammed data Page 465 of 562 M2616 model 40 Intended use: Front desk console with display Assigned Class of Service options: LNA/FND/GPUA/MWA/ADD/CNDA/HFA/FBD Table 130 M2616 model 40 Key number Key number Feature position position Feature – – Hot * Speed Call (personnel: 20) Control Class of Service Ring Again Message Registration...
Page 466 Page 466 of 562 Preprogrammed data M2616 model 50 Intended use: Nurses’ station telephone Assigned Class of Service options: LNA/FND/GPUA/MWA/NDD/HFA/FBD Table 131 M2616 model 50 Key number Key number Feature position position Feature – Transfer Auto Dial Speed Call (personnel: 20) Auto Dial Ring Again Auto Dial...
Page 467 Preprogrammed data Page 467 of 562 M2616 model 51 Intended use: Nurses’ station telephone with display Assigned Class of Service options: LNA/FND/GPUA/MWA/ADD/HFA/FBD Table 132 M2616 model 51 Key number Key number Feature position position Feature – Speed Call (personnel: 20) Auto Dial –...
Page 468 Page 468 of 562 Preprogrammed data M2616 Message center telephone models Table 133 M2616 Message center telephone models Assigned Class of Service Model Intended use options Key number position with assigned feature Message center LNA, FND, 15 - 7 - Transfer telephone GPUA, MWA, 14 - Auto Dial...
Page 469 Page 469 of 562 Changing preprogrammed data Contents This section contains information on the following topics: Introduction ..........Changing the default numbering plan .
Page 470: Introduction
Page 470 of 562 Changing preprogrammed data Printing model information........Analog telephones .
Page 471: Changing The Default Numbering Plan
Changing preprogrammed data Page 471 of 562 Changing the default numbering plan You may need to change the default numbering plan in order to improve performance or to remove numbering plan conflicts. Refer to Tables 81 through 87 on pages 411 to 419 for a full listing of the default DN assignments for Cabinet and Chassis systems.
Page 472: Determining New Extension Numbers
Page 472 of 562 Changing preprogrammed data The character display reads: 1 DEFAULT SETS 2 NUMBERING PLAN Select “2 NUMBERING PLAN” by entering the number “2”. The character display reads: FIRST NUMBER (XXXX)? To create a new first number, enter the digits you want and press the pound key.
Page 473 Changing preprogrammed data Page 473 of 562 Example: Assume the new numbering plan starts at extension number 4500. You wish to know the extension number of the telephone connected to card 8, unit 12: Subtract 1 from the card slot number (8 - 1):=7 Multiply by 16:x Add the first extension number:+ 4500...
Page 474: Using The Meridian Mail Auto-Configure Feature
Page 474 of 562 Changing preprogrammed data Using the Meridian Mail Auto-configure feature The Meridian Mail Auto-configure feature automatically matches Meridian Mail mailboxes with telephone extensions. If you have the Meridian Mail card option and you want to use the Meridian Mail Auto-configure feature, make sure: •...
Page 475: Removing Numbering Plan Conflicts
Changing preprogrammed data Page 475 of 562 Example: The first number in the numbering plan is 2200. If you want the first number in the numbering plan to be 2300, and the first line card is located in slot 6, perform the following calculation: Locate the first line card.
Page 476: Conflicts With Acd Queues
Page 476 of 562 Changing preprogrammed data on the TTY and respond to the system prompts as shown below. Repeat the procedure once for each of the six units that you want to remove. LD 11 TYPE 2008 10 XX where “XX”...
Page 477: Conflicts With Call Park Extension Numbers
Changing preprogrammed data Page 477 of 562 Conflicts with Call Park extension numbers System call park extension numbers are preprogrammed for the Central Answering Position. (For some countries, the default call park extensions are listed in Table 74 on page 404.) To remove this data from the system, load LD 50 and respond to the prompts as follows: LD 50 TYPE...
Page 478: Conflicts With The Spre Code
Page 478 of 562 Changing preprogrammed data Conflicts with the SPRE code If the preprogrammed SPRE code interferes with the programming required for the Small System, use LD 15 to remove it. (For some countries, the default SPRE access code is listed in Table 73 on page 402.) For customer 0 enter the following in response to the SPRE prompt: LD 15 SPRE...
Page 479: Conflicts With Flexible Feature Codes
Changing preprogrammed data Page 479 of 562 X aaaa where “aaaa” = the current night number (the night number now removed) Conflicts with Flexible Feature Codes If the preprogrammed Flexible Feature Codes interfere with the programming required for the Small System, use LD 57 to remove the data from the system. (For some countries, default FFCs are listed in Table 88 on page 420.)
Page 480 Page 480 of 562 Changing preprogrammed data To remove one access code, enter the following commands: Action request TYPE FFC = Flexible feature codes CUST 0-31 Customer Number FFCT YES (NO) FFC Confirmation tone Remove specific access code CODE aaaa Enter access code prompt (aaaa) AAAA Enter the new access code prompt...
Page 481: Creating, Changing, And Removing Model Telephones
Changing preprogrammed data Page 481 of 562 Creating, changing, and removing model telephones If you need a model telephone different from the default models provided in Small System software, use overlays to design your own models using the information in Table 134 on page 481.
Page 482: Modifying Analog Model Telephones
Page 482 of 562 Changing preprogrammed data Modifying analog model telephones If you want to modify an analog telephone, use LD 10 and type in the following commands on the TTY. LD 10 TYPE 500 M MODL where “YYY” = the model number of the telephone that you are modifying For more information about LD 10 and its associated prompts and commands, refer to the system software NTPs that are shipped with the...
Page 483: Modifying Digital Model Telephones
Changing preprogrammed data Page 483 of 562 You must enter the following information in LD 11 in order to create a digital telephone model. LD 11 TYPE 2XXX M or 3000 M where “XXX” = allowed telephone types MODL where “YYY” = the model number of the telephone that you are creating (between 1–127) Enter the responses to the remaining prompts in order to complete the new...
Page 484: Printing Model Information
Page 484 of 562 Changing preprogrammed data Printing model information To print information about model telephones, use LD 20. Analog telephones LD 20 TYPE 500 M MODL where “YYY” = the telephone model number. If you want to print all of the models for this telephone type, leave this value blank.
Page 485: Removing Model Telephones
Changing preprogrammed data Page 485 of 562 Removing model telephones Use LD 10 to remove analog telephone models and LD 11 to remove digital telephone models. Respond as follows to the prompts in either overlay: LD 10 or LD 11 TYPE XXXX M where “XXXX”...
Page 486: Creating Model Trunks
Page 486 of 562 Changing preprogrammed data Creating model trunks To create a new model trunk, load LD 14 and enter the following commands on the TTY: LD 14 TYPE aaa M where “aaa” = the type of trunk that you are creating (TIE, COT, WATS, and so on) MODL where “YYY”...
Page 487: Modifying Model Trunks
Changing preprogrammed data Page 487 of 562 Modifying model trunks If you want to modify a trunk, load LD 14 and enter the following commands on the TTY: LD 14 TYPE aaa M where “aaa” = the type of trunk that you are modifying MODL where “YYY”...
Page 488: Printing Model Information
Page 488 of 562 Changing preprogrammed data Printing model information To print information about model trunks, load LD 20 and enter the following commands on the TTY: LD 20 TYPE TTTT where “TTTT” = the trunk type MODL where “YYY” = the model number. If you want to print all of the models for this trunk type, leave this value blank.
Page 489 Changing preprogrammed data Page 489 of 562 The prompt “NEW ACCESS CODE?” asks you for a new access code for the route. Enter the new access code and press the pound key. The display shows “CODE CHANGED”. After a delay of approximately 4 seconds you hear special dial tone and the sequence is repeated when the prompt “ROUTE ACCESS?”...
Page 490 Page 490 of 562 Changing preprogrammed data 553-3011-210 Standard 1.00 October 2003...
Page 491 Page 491 of 562 Survivability Contents This section contains information on the following topics: Introduction ..........Operating modes.
Page 492: Introduction
Page 492 of 562 Survivability Introduction This chapter provides a brief overview of the Small System’s Survivability feature. It also describes the procedures to configure Survivability on a new system, or add the capability to an existing Small System. Operating modes The following are the two modes of operation: •...
Page 493: Description
Survivability Page 493 of 562 Description Figure 131 Small System Survivability IP Expansion PBX - survival mode Point-to-point Main PBX - survival mode PBX - survival mode High Performance Data Network PBX - survival mode PBX - normal 553-A065 Incremental Software Management The number of survivable cabinets or chassis in a system is defined by an Incremental Software Management (ISM) parameter labeled SURVIVABILITY.
Page 494: Switchover To Survival Mode
Page 494 of 562 Survivability Switchover to survival mode A survivable IP expansion cabinet or chassis is able to restart after it loses communication with the main cabinet or chassis, due to an outage of the main cabinet or chassis or due to a failure of the link between the cabinets or chassis.
Page 495 Survivability Page 495 of 562 The following example illustrates the tasks performed by the Small System’s IP expansion cabinet or chassis when communication with the main cabinet or chassis is lost: The IP expansion cabinet or chassis attempts to reestablish the connection to the main cabinet or chassis.
Page 496: Switchback From Survival Mode
Page 496 of 562 Survivability Switchback from survival mode A survivable IP expansion cabinet or chassis can switch back to normal mode after communication with the main cabinet or chassis is restored. The following two scenarios can trigger a cabinet or chassis in survival mode to return to normal mode: •...
Page 497: Survivability Notification
Survivability Page 497 of 562 timer expires. If switchback is set to NO, the cabinet or chassis remains in survival mode until a technician enters the SBFS command. Switchover timer The timer is started on a survivable IP expansion cabinet or chassis as soon as the link with the main cabinet or chassis goes up or down.
Page 498 Page 498 of 562 Survivability Special dial tone The dial tone provided to the telephones in survival mode is different from the dial tone for telephones in normal mode. This Flexible Survivable Dial Tone is provided with the Small System; however, the user can alter the Flexible Survivable Dial Tone in LD 56.
Page 499 Survivability Page 499 of 562 Figure 132 Display telephone Local mode Remote TTY Survivable IP remote TTY The three Serial Data Interface (SDI) ports on the Small System Controller (SSC) card of an IP expansion cabinet or chassis are available for use as additional system remote TTYs.
Page 500: Database Synchronization
Page 500 of 562 Survivability Special text, which is displayed on the TTY of the IP expansion cabinet or chassis, indicates when the IP expansion cabinet or chassis is operating in survival mode. This text informs the technician of the difference between the remote TTY’s access to the main cabinet or chassis in normal mode and the IP expansion cabinet or chassis in survival mode.
Page 501 Survivability Page 501 of 562 software release. If this check fails, the download operation is aborted for that cabinet or chassis. The data files are loaded from the primary (C:) drive of the IP expansion cabinet or chassis to protected memory when a switchover to survival mode occurs.
Page 502 Page 502 of 562 Survivability The data is then written to the primary flash drive. When the database files in the primary flash drive are updated, data and patches are written to the internal backup flash drive (Z:). Note: LD 43 and 143 are not available on an IP expansion cabinet or chassis in survival mode.
Page 503 Survivability Page 503 of 562 Figure 133 SWP command operation SWP command operation 1. Swap .rec and .bak on Main cabinet Main Memory database in use database.rec database.rec database.rec database.bak External Primary Backup PC Card Drive Flash Drive Flash Drive 2.
Page 504 Page 504 of 562 Survivability RES and RIB Command The RES command restores data from the main cabinet or chassis external PC Card drive to the main cabinet or chassis (C:) drive and all survivable IP expansion cabinet or chassis (C:) drives. The RIB command restores data from the main cabinet or chassis internal backup flash drive to the main cabinet or chassis (C:) drive and from the survivable IP expansion cabinet or chassis internal backup flash drive to the (C:) drive.
Page 505 Survivability Page 505 of 562 Figure 134 RES command RES command operation 1. Copy the database as .tmp file 2. Rename the database .rec file to .bak Main Memory 3. Rename the database .tmp file to .rec database in use database.rec database.rec database.tmp...
Page 506 Page 506 of 562 Survivability Figure 135 RIB command RIB command operation 1. Rename the database .rec file to .bak 2. Copy backup database to primary Main Memory database in use database.rec database.rec database.rec database.bak External Primary Backup PC Card Drive Flash Drive Flash Drive The same sequence of steps are...
Page 507 Survivability Page 507 of 562 DAT command Use the DAT command to print the data issue and creation date of the main cabinet or chassis primary and backup databases, as well as those of the survivable IP expansion cabinets or chassis. The software release of the survivable IP expansion cabinets or chassis must match that of the main cabinet or chassis.
Page 508: Tn Mapping During Survival Mode
Page 508 of 562 Survivability issue a SOTS command. This forces the selected IP expansion cabinet or chassis into survival mode prior to restarting the main cabinet or chassis. A LOCK command can be issued from the main cabinet or chassis prior to a restart.
Page 509 Survivability Page 509 of 562 Procedure 71 Configuring for Survivability — new system Ensure that you have the proper hardware installed to support Survivability. You can only configure Survivability on an IP expansion cabinet or chassis. This means an IP expansion cabinet or chassis that is connected to the main cabinet or chassis with a 100BaseT or 100BaseF link.
Page 510: Configuring Trunks For Survivability
Page 510 of 562 Survivability The SWOTO command is configured in LD 117: CHG SWOTO <cab#> <value> Where: cab# = 1–4 value = 2 - (120) - 600 seconds For point-to-point connection (cabinets or chassis that are not connected over a LAN), it is recommended that you set the timer to a low value to minimize service interruption.
Page 511 Survivability Page 511 of 562 Option 1: Dedicated DID/DOD trunks Procedure 72 Configuring dedicated DID/DOD trunks for Survivability Configure each IP expansion cabinet or chassis with incoming and outgoing DID trunks. Configure the main cabinet or chassis with incoming and outgoing CO trunks.
Page 512 Page 512 of 562 Survivability • The outgoing DOD trunks are used in both normal and survival modes. • Users with DID numbers have direct inward access in both normal and survival modes. Disadvantages: • Non-DID users of the expansion cabinets or chassis cannot directly receive incoming calls in survival mode.
Page 513 Survivability Page 513 of 562 Option 3: Multiple, public-exchange Listed Directory Numbers Procedure 74 Configuring multiple, public-exchange Listed Directory Numbers (LDN) for Survivability Configure the main cabinet or chassis with incoming and outgoing CO trunks. Configure the IP expansion cabinets or chassis with incoming and outgoing CO trunks.
Page 514 Page 514 of 562 Survivability appearance DN ring for incoming calls. The calls can be manually redirected by any of the users assigned to those telephones. • However, when IP Expansion Cabinet 1 is in survival mode, incoming calls to IP Expansion Cabinet 1 (by LDN #1) are terminated only on IP Expansion Cabinet 1's telephone with the multiple appearance DN.
Page 515 Survivability Page 515 of 562 The MBNR and MLDN prompts are configured in LD 15. LD 15 – Customer Data Block Prompt Response Description REQ: Change existing data block TYPE: Change Intercept Treatment CUST 0–31 Customer number MBNR MAIL MAIL MAIL MAIL MLDN xxxx Mail DN...
Page 516 The Small System has been provisioned to support the following applications and telephones, and their circuit cards (if applicable). Contact your system supplier or your Nortel Networks representative to verify that the functionality of the following is supported at this time: •...
Page 517: Ip Line In Survivable Small Systems
Survivability Page 517 of 562 Peripheral Software Download Peripheral Software Download (PSDL) is available from the main cabinet or chassis in normal mode only. PSDL is not supported on IP expansion cabinets or chassis when they are in survival mode. IP Line in survivable Small Systems This section describes certain aspects of IP Line card configuration that are specific to survivable IP expansion.
Page 518 Page 518 of 562 Survivability — If IP Line card fails, Internet Telephone sets can register to another IP Line card only if it is contained within that particular IP expansion cabinet or chassis. — Users cannot make Internet Telephone calls from one IP expansion cabinet or chassis to another.
Page 519: Retrieving Call Detail Recording Records
Survivability Page 519 of 562 Procedure 75 Verifying the operation of an IP Line card in an IP expansion cabinet or chassis in survival mode Go into LD 135 and use the SOTS command to force the IP expansion cabinet or chassis into survival mode. The IP expansion cabinet or chassis will reboot and come up in survival mode.
Page 520 Page 520 of 562 Survivability The XCDR command, file retrieval for small systems in LD 143, transfers the CDR file from the survivable IP expansion directly to the PC connected to the main cabinet or chassis. Use the following procedure to retrieve the CDR files stored on the survivable IP expansion cabinets or chassis (one file per cabinet or chassis) using XModem.
Page 521 Page 521 of 562 Central Answering Position Contents This section contains information on the following topics: Introduction ..........About the Central Answering Position .
Page 522: Introduction
Page 522 of 562 Central Answering Position Program ..........Transfer .
Page 523: Cap Functionality Versus M2250 Functionality
Central Answering Position Page 523 of 562 telephone). If you use key expansion modules, you require a local power supply and power board as well as an expanded telephone footstand. A preprogrammed Small System uses an attendant console; if the console is not activated or is unstaffed, it is said to be in Night Service.
Page 524 Page 524 of 562 Central Answering Position Table 136 illustrates the CAP features which duplicate or simulate attendant console features. Table 136 CAP features versus M2250 features Central Answering Position (CAP) M2250 attendant console Override. Busy Verify Not Ready. Position Busy Make Set Busy (Night Service is entered when the Night Service last Central Answering Position logs out of the ACD...
Page 525: Key Layout
Central Answering Position Page 525 of 562 Attendant console features not available with a CAP The following is a list of attendant console features that are not available with a CAP: • The CAP does not have the capability to provision feature keys which function like incoming call indicators.
Page 526 Page 526 of 562 Central Answering Position Figure 136 on page 526 shows the model feature key assignments on the CAP telephone. These are the features you get when you select a CAP model using the administration telephone. Figure 136 Default M2216 or 2616 CAP model Hot Line Program...
Page 527: Key Expansion Modules
Central Answering Position Page 527 of 562 Key expansion modules Up to two optional Meridian Key Expansion Modules (NT2K22XH) can be used with the base CAP telephone. The keys in Figure 137 on page 528 show the key expansion module with example labels for department or individual names.
Page 528 Page 528 of 562 Central Answering Position Figure 137 shows an example of a key expansion module. Figure 137 Optional key expansion module Warehouse S Brown M Clives Payroll Technology S Grant Engineering G Hart Quality D Jones Manufacturing C Plant A Smith Accounting Sales...
Page 529: Installing The Key Expansion Module(S)
Central Answering Position Page 529 of 562 Installing the key expansion module(s) Use this procedure to add one (single) or two (double) key expansion module(s) to the M2616 or M2216 ACD CAP telephone. Note: Before installing the key expansion module(s), make sure that you have the associated footstand, the power supply board, and the additional power source.
Page 530: Removing The Key Expansion Module(S)
Page 530 of 562 Central Answering Position If the telephone is equipped with a Programmable Data Adapter, reconnect the data cable to the base telephone jack. Make sure that the Programmable Data Adapter cable and the interface cable do not get pinched between the base and the stand.
Page 531 Central Answering Position Page 531 of 562 Remove the interface cable from the telephone by pressing down on the locking tab. If you have an interface cable on the first key expansion module (closest to the telephone), remove it now. End of Procedure Figure 138 Key expansion module connections (bottom view)
Page 532: Configuring Your Cap
Page 532 of 562 Central Answering Position Configuring your CAP The CAP can be configured using the CAP telephone model as described in “Preprogrammed data” on page 399. The CAP can also be configured using a TTY. To configure the CAP, use the system’s TTY to access the following overlays in the order listed: •...
Page 533 Central Answering Position Page 533 of 562 To configure RAN trunks, respond as follows for prompts in LD 14: Note: LD 14 is also used to assign incoming trunks with a Priority (via CLS=APY) LD 14 – Defining and modifying trunks Prompt Response Description...
Page 534 Page 534 of 562 Central Answering Position LD 23 – Configuring ACD as the night number Prompt Response Description <CR> Associated set (used with Meridian Link only). DSAC <CR> Server IS/data service access code (used with Meridian Link only). MAXP 1–120 Maximum number of positions.
Page 535 Central Answering Position Page 535 of 562 LD 23 – Configuring ACD as the night number Prompt Response Description 0–2044 Time in seconds before second RAN is connected to ACD calls (appears if SRRT RAN route number is identified above). NRRT 0–127 RAN route number assigned as night announcement for...
Page 536 Page 536 of 562 Central Answering Position LD 15 – Configuring customer options (Part 2 of 2) Prompt Response Description - AOCS <CR> - RCY1 <CR> - RCY2 1 - (6) - 15 Ring Cycles before forwarding to attendant In LD 15, the customer data block, the prompt ATDN, or Attendant Directory Number, defaults to 0.
Page 537: Logging Into And Out Of The Acd Queue
Central Answering Position Page 537 of 562 LD 11 – Configuring your CAP (Part 2 of 2) Prompt Response Description xx DWC yyyy “xx” = key number DWC = ACD Display Waiting Calls “yyyy” = ACD-DN xx TRN “xx” = key number TRN = Transfer xx AO6 “xx”...
Page 538: Small System Configured In Position Id Mode
Page 538 of 562 Central Answering Position Small System configured in Position ID mode Logging into the ACD queue • The CAP is in the Make Set Busy state. — The Make Set Busy lamp may or may not be on. •...
Page 539: Using Common Cap Features
Central Answering Position Page 539 of 562 Logging out of the ACD queue • You are logged into ACD queue. • Press the Make Set Busy key on the CAP or unplug the headset. — You are now logged out of the ACD queue. Using common CAP features This section describes each of the commonly configured features on the CAP and explains how to use them.
Page 540: Direct Station Select (Bfs)
Page 540 of 562 Central Answering Position You can repeat the process to add more people to the call. Press Rls to disconnect yourself from the call. To talk with two people back and forth, press Hold, placing your second caller on hold, and press the ACD queue key to connect with your first caller.
Page 541: Display Queue (Disp Queue)
Central Answering Position Page 541 of 562 Procedure 81 Making an internal call Lift the handset. Press the DN key. Dial the extension of the person that you want to call or press the DSS key. End of Procedure Display Queue (Disp Queue) This key shows the number of calls in the queue, the number of staffed CAPs, and the waiting time of the oldest call in the queue.
Page 542: No Hold Conference (N. H. Conf)
Page 542 of 562 Central Answering Position Procedure 83 Making the CAP appear busy Press Make Busy. For an M2616 CAP, place the handset in the cradle or press the hookswitch. The indicator comes on. To cancel the Make Busy feature, press Make Busy again. The indicator goes off.
Page 543: Override
Central Answering Position Page 543 of 562 Override This key allows the CAP to “break in” to an established call. The priority level of the telephone involved in the call and the level of the CAP determine whether override is permitted. Procedure 85 Overriding a busy signal and connecting to a call You have dialed an internal call and received a busy signal.
Page 544: Privacy Release (Priv Rls)
Page 544 of 562 Central Answering Position Press Park again. Press Rls. End of Procedure Procedure 88 Retrieving a parked call Press the DN key. Dial the extension on which the call is parked if the call is parked on an extension other than the system call park number.
Page 545: Program
Central Answering Position Page 545 of 562 Program This key allows you to change various display features. Data parameters such as transmission speed, parity, and terminal mode can also be changed if the CAP is equipped with an optional data adapter. •...
Page 546 Page 546 of 562 Central Answering Position Press Transfer while you still hear the phone ringing. You are no longer connected to the call. If the call is not answered or forwarded by the call forward feature, it rings back to the CAP telephone (programmable in LD 15). End of Procedure Procedure 91 Transferring a call with consultation...
Page 547: Other Cap Features
Central Answering Position Page 547 of 562 Other CAP features Your CAP also supports other features, which are discussed in detail in this section. Call Forward and Busy Status The Call Forward and Busy Status (BFS) feature was designed for an environment where party A forwards their calls to party B, for screening.
Page 548 Page 548 of 562 Central Answering Position • Party A’s calls were forwarded to party B, then party A’s call forward is canceled. • Party A’s call forward is not activated, then party A’s calls are forwarded to party B and the CFW lamp on party A’s set lights up. If the customer associated with Party A has Forward Key Allowed Class of Service (FKA), then depressing the BFS key by party B will result in one of the following:...
Page 549 Central Answering Position Page 549 of 562 Feature interactions None. Feature programming To activate this feature, use the following task list in LD 11 and LD 15. LD 11 – Configuring a BFS key Prompt Response Description REQ: Modify existing data. TYPE: xxxx xxxx is one of 2006, 2008, 2616, 2216, 2317, 2009,...
Page 550: Forced Camp-On/Priority Override
Page 550 of 562 Central Answering Position LD 15 – Configuring customer for Forward Key Allowed Prompt Response Description REQ: Modify existing data. TYPE: Features and Options. CUST Customer Number as defined in LD 15..... Forward Key Allowed. Forced Camp-on/Priority Override Forced Camp-on allows a station to “camp-on”...
Page 551 Central Answering Position Page 551 of 562 activated using the Enhanced Override Flexible Feature Code or the Enhanced Override key (EOVR), as described in the preceding paragraph. Associated with the Priority Override feature are seven priority levels which can be assigned to analog (500/2500-type) and Meridian Digital Telephones. This level defines the ability of one set to override another as follows: •...
Page 552 Page 552 of 562 Central Answering Position Setting the Automatic Forced Camp-On (AFCO) prompt to “NO”, and adding an OVR and EOVR key/FFC gives the user the option of using only Priority Override (OVR key/FFC) or using manual Forced Camp-on which is invoked by the first depression of the EOVR key/FFC, followed by Priority Override (second depression of the EOVR key/FFC).
Page 553 Central Answering Position Page 553 of 562 • a parked call • a call-waiting call • a held call • an operator callback or toll operator break-in call • Make Set Busy active • Do Not Disturb active External trunks cannot perform priority override. They can be overridden only if they are the undesired party of an established call being broken into.
Page 554 Page 554 of 562 Central Answering Position Feature programming To activate this feature, use the following task list in LD 10, LD 11, LD 14, LD 15, LD 16, and LD 57. LD 10 – Configuring Forward Camp-on/Priority Override on a set Prompt Response Description...
Page 555 Central Answering Position Page 555 of 562 LD 11 – Configuring Forward Camp-on/Priority Override on a set Prompt Response Description REQ: Modify existing data. TYPE: xxxx xxxx is one of 2006, 2008, 2616, 2216, 2317, 2009, M2016, 2018, 2112, 3000 Digital telephone. xxxx M Model set.
Page 556 Page 556 of 562 Central Answering Position LD 14 – Configuring Warning Tone Allowed Prompt Response Description Modify existing data. TYPE Trunk type..Warning Tone allowed. LD 15 – Configuring Multi Party Operations Prompt Response Description REQ: Modify existing data. TYPE: Multi Party Operations data block.
Page 557 Central Answering Position Page 557 of 562 LD 16 – Configuring Priority Level in route data Prompt Response Description Modify existing data. TYPE Route data block. CUST As defined in LD 15. DMODL 1–127 Default model number for this route. ROUT 0–127 Route Number.
Page 558 Page 558 of 562 Central Answering Position 553-3011-210 Standard 1.00 October 2003...
Page 559 Page 559 of 562 Appendix A: Communications protocol specifications Contents This section contains information on the following topics: Introduction ..........XModem protocol specifications .
Page 560 Page 560 of 562 Appendix A: Communications protocol specifications The following definitions apply to XModem protocol: <soh>01H <eot>04H <ack>06H <nak>15H <C>43H This protocol does not restrict the contents of data sent. Control characters are not processed in the 128-byte data messages (they are handled the same as other characters).
Page 561 Appendix A: Communications protocol specifications Page 561 of 562 1023 message polynomial will be to the order of X . The hi order bit of the first 1023 byte of the message block is the coefficient of X in the message polynomial.
Page 562 Page 562 of 562 Appendix A: Communications protocol specifications SENDERRECEIVER <---<C> times out after 3.4 seconds, <---<C> times out after 3.4 seconds, <---<C> times out after 3.4 seconds, <---<C> times out after 3.4 seconds, <---<C> <soh> 01 FE -data- <xxxx>---> <---<ack>...
Page 564 Installation and Configuration Copyright © 2003 Nortel Networks All Rights Reserved Information is subject to change without notice. Nortel Networks reserves the right to make changes in design or components as progress in engineering and manufacturing may warrant. This equipment has been...

Nortel Meridian 1 Succession 1000M Installation And Configuration Manual

Table of Contents

Cabinet System Equipment

Installing Optional Circuit Cards

Installing and Connecting Cross-Connect Terminals

Installing and Connecting Sdi and Ethernet Ports

Installing Software

IP Line Card Configuration

Connecting the Telephones

Connecting the Trunks

Preprogrammed Data

Changing Preprogrammed Data

Survivability

Central Answering Position

Quick Links

Chapters

Related Manuals for Nortel Meridian 1 Succession 1000M

Summary of Contents for Nortel Meridian 1 Succession 1000M
