TABLE OF CONTENTS ●Introduction �� 4 SYSTEM MENU �� 53 ●Support and Service �� 4 Display ��54 ●Application, Export, and Modification �� 4 Sound volume ��55 ●Compliance Information Statement �� 5 System timer��55 ●Definitions of Symbols �� 5 H/W setting��56 ●Safety Precautions (do not operate without reading) ��...
Page 3 Throttle mixing ��166 Telemetry:Current sensor [Current] ��109 Pitch → Needle ��167 Telemetry:Airspeed sensor [Airspeed] ��110 Tele. setting (Telemetry setting)�� 111 Pitch → Rudder (Revolution mixing) ��168 Trainer ��113 Gyro (Helicopter)��169 Warning setting ��116 Governor ��171 User menu setting ��117 Gyro setting CGY755 CGY760R ��173 Data reset ��118 Wired connection:Advanced setting ��...
Page 4: Introduction
Outside North America Please contact your Futaba importer in your region of the world to assist you with any questions, problems or service needs. Please recognize that all information in this manual, and all support availability, is based upon the systems sold in North America only.
Page 5: Compliance Information Statement
Cet émetteur ne doit pas être co-situé ou fonctionner conjointement avec une autre antenne ou émetteur. Declaration of Conformity (for EU) Hereby, Futaba Corporation declares that the radio equipment type is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address:...
Page 6: Safety Precautions (Do Not Operate Without Reading)
■ No part of this manual may be reproduced in any form without prior permission. ■ The contents of this manual are subject to change without prior notice. ■ The contents of this manual should be complete, but if there are any unclear or missing parts please contact a Futaba Service Center.
Page 7 Flying Precautions WARNING Never grasp the transmitter antenna while flying. For safety, fly so that the aircraft is visible at all times. 　　　 ■ The transmitter output may drop drastically. ■ Flying behind buildings or other large structures will not only Always make sure that all transmitter stick move- cause you to lose sight of the aircraft, but also degrade the RF ments operate all servos properly in the model prior to...
Page 8 Battery and Charger Handling Precautions DANGER Do not recharge a battery that is damaged, deterio- Always use the charger with the specified power rated, leaking electrolyte, or wet.　 supply voltage. Do not allow the charger or battery to become wet. If the battery liquid should get in your eyes, do not rub your eyes, but immediately wash them with tap wa- ■...
Page 9 ESC, etc. ■ If left in such an environment, the plastic may be damaged. ■ Futaba is not responsible for damage sustained by combination with parts other than Futaba Genuine Parts. Use the parts ■ Since the metal parts of the case may corrode, always keep specified in the instruction manual and catalog.
Page 10: Contents And Technical Specifications
Note: This set does not include a charger. Use a commercially available USB charger AC adapter (USB-A type 5 V-2 A) or the Futaba optional USB AC adapter. Note: The battery in the T16IZ transmitter does not arrive already attached to the battery...
Page 11: Transmitter Controls �� 11 Information
Transmitter Controls ● micro SD Slot ● Antenna ● PC Port T h e t r a n s m i t t e r c a n b e u s e d a s a game controller by c o n n e c t i n g i t t o a computer with a USB cable.
Page 12 ● Stick tension adjustment port Back ● Right Slider ● Left Slider ● Earpone Jack ● S.I/F Port 　（S.BUS setting） ● Trainer port ● Battery cover ● Kickstand ● Charging Port The angle when the transmitter is placed can be changed by rotating the swing handle and tightening the screw.
Page 13: Transmitter's Antenna
Transmitter's Antenna As with all radio frequency transmissions, the strongest area of signal transmission is from the sides of the transmitter's antenna. As such, the antenna should not be pointed directly at the model. If your flying style creates this situation, easily move the antenna to correct this situation. Rotating antenna The antenna can be rotated 90 degrees and angles 90 degrees.
Page 14: Transmitter Lipo Battery Lt2F2000B
Transmitter LiPo Battery LT2F2000B Installing/removing the LT2F2000B Connect the battery connector Press the tab to open the battery cover. Remove the battery cover Close the battery cover completely Battery cover First insert two tabs Be careful not to pinch the wiring Install the battery into the transmitter Click ! Click !
Page 15 This set is not equipped with an AC adapter for charging. Must be purchased separately. ● AC adapter USB-A type 5 V - 2 A ● Futaba option AC adapter USB type Access the charge port by flipping the rubber cover on the bottom of the transmitter.
Page 16: How To Turn Transmitter Power On/Off
How to turn transmitter power ON/OFF When turning on the power, the T16IZ transmitter will begin emitting RF automatically after it confirms the surrounding RF conditions. The status of the transmitter is displayed by LED at the upper part of the front of a T16IZ.
Page 17: Touch Display
Touch Display Tapping the settings buttons for Tap the panel with your finger to navigate. each value on the settings screen will cause value input buttons to *Plastic film is attached to the Touch Display. Please be careful so that you don't scratch the Touch appear at the top of the panel.
Page 18: Lock Display
Lock Display Temporarily activating this function makes it impossible to change data by accidental input during flight. How to lock 1. With the home screen displayed. 2. Press the HOME/EXIT button for about 1 second. "Key Icon" is displayed and the keys will be disabled.
Page 19: Switch (Sa-Sh)
Switch (SA-SH) SF : 2 positions; Alternate; SH : 2 positions; Momentary; Long lever Long lever SE : 3 positions; Alternate; SG : 3 positions; Alternate; Short lever Short lever SA : 3 positions; Alternate; SD : 3 positions; Alternate; Short lever Short lever SB : 3 positions;...
Page 20: Volume
Volume The volume LD and RD knobs allow analog input. *The T16IZ transmitter beeps when the volume knob reaches the center position. *You can use each setting screen of the mixing functions to select volumes and define the direction of movement. Slider LS (Left), RS (Right): The Linear Slider LS and RS offer analog input.
Page 21: Digital Trims (T1-T4)
Digital Trims T1-T4 This transmitter is equipped with 4 digital trims. Each time you press a trim button, the trim position moves one step. If you continue pressing it, the trim position starts to move faster. In addition, when the trim position returns to the center, the tone will change.
Page 22: Monitor Led Display
Monitor LED Display The status of the transmitter is displayed by LED indicators on the upper porton of the T16IZ. Red LED Blue LED ◆ ON At startup ◆ ON Radio waves are being transmitted. ◆ Blinking Power switch is turned on with ◆...
Page 23: Stick Control: Airplane Example
Stick control : Airplane Example *Example Stick Mode2 A general model example. (There is also a diﬀerent operational model.) Roll Axis Control Pitch Axis Control Right roll Nose Up The right aileron is up. Elevator stick The left aileron Aileron stick is down.
Page 24: Stick Control: Helicopter Example
Stick control : Helicopter Example *Example Stick Mode2 A general model example. (There is also a diﬀerent operational model.) Roll Axis Control Pitch Axis Control Right roll Nose Up Elevator stick Aileron stick To the right (moved to the bottom) Level ﬂight Level ﬂight Neutral...
Page 25: Stick Control: Multicopter Example
Stick control : Multicopter Example *Example Stick Mode2 A general model example. (There is also a diﬀerent operational model.) Roll Axis Control Pitch Axis Control Right roll Nose Up Right slide Elevator stick Aileron stick Back slide To the right (moved to the bottom) Hovering Level ﬂight...
Page 26: Stick Adjustment
Stick Adjustment Adjustment of the stick lever length Adjustment of stick lever tension You can adjust the length of stick levers as you like. It is recommended to adjust the length of the You can adjust how quickly the sticks in line with your hand size. stick returns to neutral.
Page 27: Stick Mode
Stick Mode MODE1 MODE2 MODE3 MODE4 Default J2 stick J3 stick Spring → Hard Spring → Hard Spring → Soft Spring → Soft J2 stick J3 stick Spring → Free Spring → Free Spring → ACT Spring → ACT J3 stick J2 stick Ratchet →...
Page 28: Micro Sd Card �� 28 Stick Alarm
Saving model data and update files (released from When you have a problem of saving or reading data Futaba) into the micro SD card, you can use those after a long period of use, please get a new micro files on your T16IZ transmitter. Equipment for SD card.
Page 29: Connector/Plug �� 29 Timer
-When an micro SD card is installed in CAUTION the T16IZ transmitter, a folder called "Fu- taba" is created. Folders called "LOG" and B e s u r e t o t u r n o f f t h e p o w e r t o "MODEL"...
Page 30: Receiver Nomenclature �� 30 Function Name
"S.BUS2": outputs of S.BUS2 port. [Telemetry Sensor ] *When using nine or more channels, use an S.BUS ＋ function or use a second R7108SB and link both － to your transmitter. Extra Voltage Connector Use this connector when using a voltage telemetry device to send the battery voltage information (DC 0 ~ 70 V) from the receiver to the transmitter.
Page 31 Connection of a receiver battery WARNING Please make sure that you use a battery that can deliver enough capacity for the number and kind of servos used. Dry batteries cannot be used. DANGER Battery Switch 3.7 ～ 7.4 V Receiver A battery is connectable also with which port.
Page 32 R7108SB CH Mode table Channel Modes Channel The R7108SB is capable of changing its channel allocations as Output Mode A Mode B Mode C Mode D connector described in the table below. This is especially important when 1 ～ 8CH 1 ～...
Page 33: Receiver's Antenna Installation
Receiver's Antenna Installation The R7108SB has two antennas. In order to maximize signal reception and promote safe modeling Futaba has adopted a diversity antenna system. This allows the receiver to obtain RF signals on both antennas and fly problem-free. *Must be kept as straight as possible.
Page 34 Mounting the Servo Safety precautions when you *Servo is not included in this set. install receiver and servos. WARNING Wood screw 2.3-2.6mm nut washer Connecting connectors Rubber Rubber grommet grommet Be sure to insert the connector until it Brass eyelet Brass eyelet stops at the deepest point.
Page 35: S.bus/S.bus2 Installation
●The S.BUS/S.BUS2 servos memorize the number of channels themselves. (settable with the T16IZ) ●The S.BUS/S.BUS2 system and conventional system (receiver conventional CH used) can be mixed. S.BUS　Glider usage example Receiver: R7108SB Servo: S3174SV×9 ( Optional ) HUB×4 ( Optional )
Page 36: S.bus2 System �� 36 Telemetry:receiver [Battery]
S.BUS2 System When using the S.BUS2 port, an impressive array of telemetry sensors may be utilized. S.BUS2 TABLE S.BUS2 S.BUS Servo Servo Receiver port Telemetry sensor S.BUS2 S.BUS Gyro Gyro S.BUS ○ ○ × S.BUS2 ×　（※） ○ ○ （※）Don't connect S.BUS Servo, S.BUS Gyro to S.BUS2 connector.
Page 37: S.bus2 Sdevice Setting �� 37 Telemetry:receiver [Ext-Batt]
S.BUS/S.BUS2 device setting S.BUS/S.BUS2 servos or a telemetry sensor can be connected directly to the T16IZ. Channel setting and other data can be entered for the S.BUS/S.BUS2 servos or sensors. 1. Connect the S.BUS device as shown in the figure. 2.
Page 38: Home Screen �� 38 Telemetry:temperature
Home Screen This is the Home screen and descriptions of its menus. Use your finger to operate the touch screen. Battery voltage for receivers Condition name Battery Indicator • In FASSTest/T-FHSS mode, this • The condition name • When battery is low, the alarm data displayed.
Page 39: Link Procedure �� 39 Telemetry:rpm Sensor
ID code of the transmitter to which it is being paired. Once the link is made, the ID code is stored in the receiver and no further linking is necessary unless the receiver is to be used with another transmitter. When you purchase additional R7108SB receivers, this procedure is necessary; otherwise the receiver will not work.
Page 40: After Setting �� 40 Telemetry:altitude
*When you use two receivers, please be sure to 9. ACT will be chosen if telemetry is used. setup a "Rx1" and "Rx2" in the "dual" mode. It is INH when not using it. *Telemetry function cannot be used for the 2nd receiver.
Page 41: Model Id
Model ID FASSTest, T-FHSS For the sake of safety, this function does not operate the receiver if the model data of the model program settings that does not match the aircraft is used by mistake. Conventional system Model ID Rx 1 Rx 1 Operation Not Operation...
Page 42: Range Testing Your R/C System
Range Testing Your R/C System It is extremely important to range check your models prior to each flying session. This enables you to ensure that everything is functioning as it should and to obtain maximum enjoyment from your time flying. The T16IZ transmitter incorporates a system that reduces its power output and allows you to perform such a range check.
Page 43: Model Basic Setting Procedure
MODEL BASIC SETTING PROCEDURE Airplane basic setting procedure 1. Model addition and call Initial setting assigns 1 model to the T16IZ transmitter. The Model Select function is used to add models and to select models which are already set. ● If the direction of the servo is incorrect, adjust the direction with the Reverse function of the Linkage menu.
Page 44 7. Airbrake This function is used when an air brake is necessary when taking off or diving, etc. The preset elevators and flaps (camber flap, brake flap) offset amount can be activated by a switch. The offset amount of the aileron, elevator, and flap servos can be adjusted as needed.
Page 45 Helicopter basic setting procedure This section outlines examples of use of the helicopter functions of the T16IZ. Adjust the actual values, etc. to match the fuselage used. 1. Model addition and call 3. Flight condition addition The transmitter can install up to eight flight Default setting assigns 1 model to the T16IZ.
Page 46 4. Fuselage linkage Connect the throttle rudder, aileron, elevator, pitch, and other servos in accordance with the kit instruction manual. For a description of the connection method, see "Servos connection by model type". Note: The channel assignment of the T16IZ is different from that of our existing systems.
Page 47 ●Pitch curve (Idle up 2) 8. Throttle hold setting The high side pitch setting is less than idle up 1. *If throttle hold is necessary, please refer to the Throttle hold The standard is +8º. function. ●Pitch curve (Hold) 9. Throttle cut setting At auto rotation, use the maximum pitch at both the high and low sides.
Page 48: Servo Connection By Model Type
Servo Connection by Model Type The T16IZ transmitter channels are automatically assigned for optimal combination according to the type selected with the Model type function of the Linkage menu. The channel assignment (initial setting) for each model type is shown below. Connect the receiver and servos to match the type used. *The set channels can be checked at the Function screen of the Linkage menu.
Page 49 Airplane/glider ●Ailevator 1AIL 2AIL 2AIL+1FLAP 2AIL+2FLAP 2AIL+4FLAP 4AIL+2FLAP 4AIL+4FLAP Airplane Glider Airplane Glider Airplane Glider Airplane Glider Airplane Glider Airplane Glider Airplane Glider Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator Throttle Motor Throttle...
Page 50 Airplane/glider ●Tailless wing 2AIL 2AIL+1FLAP 2AIL+2FLAP 2AIL+4FLAP 4AIL+2FLAP 4AIL+4FLAP Airplane Glider Airplane Glider Airplane Glider Airplane Glider Airplane Glider Airplane Glider Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron AUX4 AUX4 AUX4 AUX4 AUX4 AUX4 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2 Throttle Motor Throttle...
Page 51 Airplane/glider ●Tailless wing Winglet 2 Rudder 2AIL 2AIL+1FLAP 2AIL+2FLAP 2AIL+4FLAP 4AIL+2FLAP 4AIL+4FLAP Airplane Glider Airplane Glider Airplane Glider Airplane Glider Airplane Glider Airplane Glider Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Rudder2 Rudder2 Rudder2 Rudder2 Rudder2 Rudder2 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2 Throttle Motor Throttle...
Page 52: Helicopter
Helicopter ●FASSTest 18CH / FASST MULTI / ●FASSTest 12CH FASST 7CH / S-FHSS H-4/H-4X Swash All other H-4/H-4X Swash All other Aileron Aileron Aileron Aileron Elevator Elevator Elevator Elevator Throttle Throttle Throttle Throttle Rudder Rudder Elevator2 Rudder Gyro Gyro Pitch Pitch Pitch Pitch...
Page 53: System Menu
SYSTEM MENU The System menu sets up functions of the ● When the System menu button is tapped, the menu shown below is called up. Tap the transmitter. This does not set up any model data. function button that you want to enter. System menu functions table Display Display adjustment.
Page 54: Display
Display The following LCD screen adjustments: ● Backlighting brightness adjustment ● Backlighting decrease time adjustment ● Touch screen calibration ● Tap the [Display] button in the System menu to call the setup screen shown below. ●Return to System menu Backlight max. brightness adjustment Touch calibration 1.
Page 55: Sound Volume
Sound volume Sound volume setting This function can set the volume of "Other sound," "Warning," and "Voice," respectively. ● Tap the [Sound volume] button in the System menu to call the setup screen shown below. ●Return to System menu The respective volume control Sound volume Setting method 2.
Page 56 To change the mode the stick ratchet must be changed. Request that this ● Tap the [Calibration] button in the System menu to call the setup screen shown below. be done by Futaba Service. (Charged modification) ●Return to System menu...
Page 57: Battery
Battery Low battery alarm voltage set Select the battery alarm voltage according to the battery to be used. It isn't indicated in case of manual setting. ●Return to System menu Battery type change : Lipo(2cells) → Manual setting When choosing manual setting, the numerical value can be input.
Page 58: S.bus Servo
S.Bus servo S.BUS servo setting An S.BUS(2) servo can memorize the channel and various settings you input. Servo setting can be performed on the T16IZ screen by wiring the servo as shown in the figure. * With some S.BUS(2) servos, there are some functions which cannot be used.
Page 59 S.BUS Servo Description of each parameter's function *There are functions that can and cannot be performed according to the servo type. • ID Displays the ID of the servo whose parameters are to be read. It cannot be changed. • Channel Channel of the S.BUS system assigned to the servo.
Page 60 • Boost ON/OFF OFF : It is the boost ON at the time of low-speed operation.(In the case of usual) ON : It is always the boost ON.(When quick operation is hope) • Damper The characteristic when the servo is stopped can be set. When smaller than the standard value, the characteristic becomes an overshoot characteristic.
Page 61 Information The program version and SD card size are displayed. The User name, language and Unit system used by the system can also be changed. This function registers the T16IZ user name and the The Information screen displays the T16IZ system language displayed at proportional can be changed.
Page 62: Linkage Menu
LINKAGE MENU The Linkage menu is made up of functions which perform model addition, model type selection, end point setting, and other model basic settings. Linkage menu functions table Servo monitor Displays the servo test and operation position Model select Model addition, call, deletion, copy, model name setting Model type Model type, wing type, tail type, swash type, selection...
Page 63: Servo Monitor
Servo monitor Servo Test & Graph Display / Displays servo positions. This is used for testing servo movement. “Moving In order to prevent any potential difficulties, Test” (repetition mode) and “Neutral Test” (fixed the servo test function will be inoperable, or position mode) are available.
Page 64: Model Select
Model select The Model selection function performs model addition, call, deletion, copy, and model name setting. This function is used to load the settings of the characters, and the model name always appears in desired model into the T16IZ’s memory. the display screen.
Page 65 Model call Model deletion 1. Tap the Internal or SD card. Select the 1. Tap the select model name or the model you location to which the desired model is to be want to delete in the model list. saved. (The model currently selected cannot be deleted.) 2.
Page 66 Model name change Model copy 1. The model data chosen at current model 1. The model data chosen at current model can be changed. The current model name, can be copied. The current model name, tap. tap. 2. When [Rename] is tapped, a keyboard appears on the screen.
Page 67: Model Type
Model type This function selects the model type from among airplane, glider, helicopter, and multicopter. Seven types of main wings (six types of flying functions, and mixing functions for the chosen wing) and three types of tail wings are available model type.
Page 68 Set the type you choose by tapping. Airplane/Glider : Choose the Helicopter : Choose the wing type and tail. swash type.
Page 69: Servo Reverse
Servo Reverse Use to reverse the servo throw direction. Servo Reverse changes the direction of an as an additional precaution to confirm proper model individual servo’s response to a control stick memory, hook ups, and radio function. movement. WARNING For CCPM helicopters, be sure to read the section on Swash AFR before reversing any servos.
Page 70: End Point
End point Sets the travel, limit point. The End point function adjusts the left and right servo throws, generates differential throws, and will correct improper linkage settings. 30 ～ 30 ～ 140% 140% The travel rate (normal full stick movement at high rates) can be varied from 30% to 140% in each direction on channels 1 to 16.
Page 71: Servo Speed
Servo speed Sets the speed of each servo. The Servo speed setting is used to set the servo speed setting can be varied from 0 to 27 in each delay for each channel, from channel l to channel channel. 16. The system uses the programmed speed (delay) to slow down servo position changes.
Page 72: Function
Function Channel assignment for each function can be changed to suit your needs. DG1, DG2 (switch channels) When you select model and wing (swash) types, These two channels can be used as switch (On/ you will find that the optimized combinations of Off) channels.
Page 73 Trim change 1. Tap the trim button to call the trim setup screen. H/W reverse This function reverses the operation signal of the 2. The following items can be set at the trim sticks, switches, trim levers, and knobs. setup screen. Note: This setting reverses the actual operation ●...
Page 74: Fail Safe
Fail safe Sets the servos' operating position when transmitter signals can no longer be received or when the receiver battery voltage drops. The Fail safe function is used to set up positions position you did not command, land at once and that the servos will move to in the case of radio check your receiver battery.
Page 75: System Type
*After any change, remember to test the model and fully check servo direction and motion. However, telemetry cannot be used for the 2nd *Analog servos cannot be used with the R7108SB in the receiver. FASSTest12CH mode. ● Select [System type] in the Linkage menu and access the setup screen shown below.
Page 76 12 channels (linear10+ON/OFF2) can be used. Telemetry Sensor cannot be used, but the response speed is faster than that of the 18CH mode. Analog servos cannot be used with the R7108SB in the FASSTest 12CH mode. • ■ FASST MULTI FASST-MULTI system receiver mode.
Page 77: Trim Setting
Trim setting Digital trim settings This function adjusts the digital trim's control step When the flight conditions are set, the trim amount and operation mode (T1-T4). operation can be coupled with any of the conditions selected through combination mode. ● Select [Trim setting] at the linkage menu and call the setup screen shown below.
Page 78: Throttle Cut
Throttle cut Stops the engine safely and easily. Throttle cut provides an easy way to stop the engine, by flipping a switch with the throttle stick at idle. The action is not functional at high throttle to avoid accidental dead sticks. The switch’s location and direction must be chosen, as it defaults to "...
Page 79: Idle Down
Idle down Lowers the engine idling speed. The Idle down function lowers the engine's idle by flipping a switch with the throttle stick at idle. The action is not functional at high throttle to avoid accidental dead sticks. The switch’s location and Tapping this will change direction must be chosen, as it defaults to "...
Page 80: Swash Ring (Heli Only)
Swash ring Limits the swash travel within a fixed range to prevent linkage damage (Helicopter only) This function limits the travel of the swash plate to prevent linkage damage as the aileron and elevator operation is used. It is useful for 3D heli setting. ●Tap the [Swash ring] button in the Linkage menu to call the setup screen shown below.
Page 81: Swash (Heli Only, Except
Swash Swash operation linkage correction function (helicopter only, except swash type H-1). Neutral Point Mixing Rate At your linkages, if the servo horn deviates from This compensation mixing is used to correct the a perpendicular position at neutral, the linkage tendency of the swash-plate for each control.
Page 82 Linkage correction setting procedure Neutral point setting procedure *Becomes the compensation reference point. *Set the linkage compensation after setting the mixing rate. *Adjusting the servo horn so that the neutral point position is near the 50% position makes the mixing amount small. *This function compensates for elevator interference by aileron operation or aileron interference by 1.
Page 83 Stick alarm　 An alarm (single beep) can be sounded at the specified throttle stick position. ●Alarm function ON/OFF can be set by switch. Tapping this will change INH to ON and activated. If the throttle stick ●Return to Linkage menu reaches the yellow l i n e , a n a l a r m w i l l sound.
Page 84 Timer Timer setting The Timer function may be set for Each timer may be set for count-down or count up operation any desired time, i.e. engine run time, with a target time. specified times for competitions, etc. If a target time is set and the timer reaches the set time, a Two independent timers are provided buzzer sound for each count is generated.
Page 85 Integration Timer INT (integration) Timer is the function which changes progress of a timer according to the location of the throttle stick. When the throttle stick is raised for faster speed, the speed of the timer usually increases. With the throttle stick at mid-range speed, the timer speed decreases (to 50%). When the throttle is positioned at low end, the timer's progress stops.
Page 86 Function name Function name can be changed The name of the spare functions (Auxiliary 1-8) can be changed for the full name (10 characters) or for the abbreviated name (4 characters). ● Tap the [Function name] button in the Linkage menu to call the setup screen shown below.
Page 87: Telemetry System
Telemetry system This screen displays and sets the various information from the receiver. An alarm and vibration can be generated depending on the information. For example, a drop in the voltage of the receiver battery housed in the aircraft can be reported by an alarm. ●...
Page 88 Home display 16 of telemetry data is displayed HOME/EXIT is pushed *Be aware that pressing and holding this activates the key lock Y o u c a n c h o o s e which type of sensor t o d i s p l a y f o r f o u r displays.
Page 89: Sensor
Sensor Various telemetry sensors setting [What is a slot?] This screen registers the telemetry sensors used Servos are classified by CH, but sensors are with the transmitter. When only one of a certain classified in units called “slot”. There are slots from type of sensor is used, this setting is unnecessary No.
Page 90 Sensor：Reload This page is set when using multiple telemetry sensors of the same type. When using multiple sensors of the same type the sensors must be registered in the transmitter. Connect all the sensors to be used to the T16IZ as shown in the figure at the right and register them by the following procedure.
Page 91 Sensor : Change slot This page is set when using multiple telemetry sensors of the same type. This procedure changes the slot number of one registered sensor. ● Call page 3/3 from the [Sensor] menu. ●Return to Linkage menu ● Tap the [Change slot] button in the Sensor screen to call the setup screen shown below.
Page 92: Telemetry
Telemetry Displaying data from the receiver This screen displays your choice of data from the receiver. Also warnings can be activated regarding the data. For example, if the receiver voltage drops, the user can be warned by an alarm (and vibration). T a p p a g e b u t t o n t o advance to next page.
Page 93 Telemetry: Receiver [Battery] Displaying data from the receiver battery voltage In this screen, the battery voltage of a receiver is *It cannot be used in FASST mode and S-FHSS mode. displayed. *Only receiver voltage and EXT voltage can be used in FASSTest12CH mode.
Page 94 The EXT-VOLT screen will display the data from You will be alerted by an alarm or vibration if the the EXT-battery output from the R7108SB receiver. voltage set by you is exceeded. In order to use this function, it is necessary to connect external voltage connector of the R7108SB *It cannot be used in FASST mode and S-FHSS mode.
Page 95 Telemetry : Temperature Displaying data from the temperature *A temperature sensor must be installed in the aircraft. Temperature is a screen which displays/sets up *It cannot be used in FASST mode and S-FHSS mode. the temperature information from an optional *Only receiver voltage and EXT voltage can be used in FASSTest12CH mode.
Page 96 Telemetry : RPM Sensor Displaying data from the rpm *An rpm sensor must be installed in the aircraft. The RPM Sensor screen is used to set up an optional rpm sensor and display the rotation *It cannot be used in FASST mode and S-FHSS mode. information it transmits.
Page 97 Telemetry : Altitude Displaying data from the altitude *An altitude sensor or GPS sensor must be installed in the aircraft. Altitude is a screen which displays / sets up the altitude altitude from atmospheric pressure. Atmospheric pressure information from an optional altitude sensor or GPS sensor. will get lower as you go up in altitude.
Page 98: Telemetry:altitude [Variometer]
Telemetry : Altitude [Variometer] Displaying data from the variometer *An altitude sensor or GPS sensor must be installed in the aircraft. VARIO is a screen which displays / sets up the status, the T16IZ incorporates a different melody variometer information from an optional altitude for ascent and descent.
Page 99 Vario Melody Setting Tap the [Set] button Current variometer *These settings can be made for each sensor. Next page Range Deadband When the variometer is greater When the variometer is less than When the variometer is less W h e n t h e v a r i o m e t e r i s than this value, Vario melody is this value, Vario melody is not than this value, Vario melody...
Page 100 Delay The output vario melody does not change during the delay time. In other words, this is a minimum time of Vario melody output. Setting range：0.0 s，0.5 s，1.0 s，1.5 s Initial value：0.0 s *This parameter is effective to all variometers. [Vario Melody Delay] Actually Variometer 0.0m/s...
Page 101: Telemetry:voltage [Battery]
●Battery voltage measurement for receivers [R7108SB use] 3. Tap to the Limit [4.0 V] item . ●The drive battery 1 is measured in an EXT port [R7108SB use] ●The drive battery 2 is measured in an EXT line [SBS-01V use] 4.
Page 102: Telemetry:voltage [Ext-Batt]
*It cannot be used in FASST mode and S-FHSS mode. necessary to connect External voltage connector of *Only receiver voltage and EXT voltage can be used in R7108SB ⇔ SBS-01V ⇔ Battery FASSTest12CH mode. *The FASSTest18CH /T-FHSS mode can use all the telemetry SBS-01V measures two batteries.
Page 103: Telemetry:gps [Distance]
Telemetry : GPS [Distance] Displaying data from the Distance Screen *A GPS sensor must be installed in the aircraft. The Distance screen displays and sets altitude data *The GPS sensor is necessary, and is sold separately. Mount from an SBS-01/02G GPS Sensor (sold separately), and connect the sensor in accordance with the sensor and allows the distance to the airborne aircraft to instruction manual.
Page 104 First, the set of a reference is required. Setting a "too close" alarm distance 1. The model and transmitter to which the GPS 1. Tap Alarm and choose from Buzzer, Voice, sensor was connected are turned on. and Inhibit. 2. Tap to the [Preset] of "Reference" item. 2.
Page 105: Telemetry:gps [Speed]
Telemetry : GPS [Speed] Displaying data from the speed *A GPS sensor must be installed in the aircraft. The speed screen displays and sets the speed data from an SBS-01/02G (GPS sensor) sold separately. *The GPS sensor is necessary, and is sold separately. Mount The speed of the aircraft during flight can be displayed.
Page 106: Telemetry:gps [Altitude, Variometer, Position]
Telemetry : GPS [Altitude, Variometer, Position] *A GPS sensor must be installed in the aircraft. The Altitude, Variometer, Position screen displays *It cannot be used in FASST mode and S-FHSS mode. and sets the data from an SBS-01/02G (GPS *Only receiver voltage and EXT voltage can be used in FASSTest12CH mode.
Page 107: Telemetry:servo Sensor [Current]
Telemetry : Servo sensor [Current] *Servo sensor must be installed in the aircraft. The SBS-01S can monitor and display the in-flight current, operating angle, and internal temperature of up to two S.BUS2 servos. If you forget to connect the servo wiring during fuselage assembly, or the servo was disconnected, an alarm can be activated at the transmitter.
Page 108: Telemetry:servo Sensor [Temperature, Angle]
Telemetry : Servo sensor [Temperature] [Angle] *Servo sensor must be installed in the aircraft. ● Select [Servo sensor] in the Telemetry screen and access the setup screen shown below. ●Return to Linkage menu ● Temperature ↑ An upward arrow indicates the alarm will sound when the temperature reaches above your set value.
Page 109: Telemetry:current Sensor [Current]
Telemetry : Current sensor [Current] *Current sensor must be installed in the The SBS-01C has the capability of measuring aircraft. current, voltage and capacity (consumption) from drive battery all at the same time. Drive Battery Motor to Receiver SBS-01C ● Select [Current] in the Telemetry screen and access the setup screen shown below.
Page 110: Telemetry:airspeed Sensor [Airspeed]
Telemetry : Airspeed sensor [Airspeed] Displaying data from the airspeed *A Airspeed sensor must be installed in the aircraft. The speed screen displays and sets the speed *The Airspeed sensor is necessary, and is sold separately. data from an SBS-01TAS (Airspeed sensor) sold Mount and connect the sensor in accordance with the sensor instruction manual.
Page 111: Tele. Setting (Telemetry Setting)
■ Extension FLD: Log data file *When copying or moving a log file, always select both the .FLI file and .FLD file. Log files can be converted to CSV format by using the telemetry log converter available at the Futaba website. ■ Notes ◇...
Page 112 Telemetry Alarm Duration and Repeat time The repeat time and duration time for the telemetry alarm (buzzer, vibration and speech) can be set. ● Tap the [Telemetry Setting] button in the Linkage menu to call the setup screen shown below. Duration is not displayed when Repeat is INH.
Page 113: Trainer
Trainer Trainer system starting and setting T16IZ trainer system makes it possible for the Note: This trainer system can be used in the following instructor to choose which channels and operation manner: modes can be used in the student's transmitter. 1.
Page 114 ● Tap the [Trainer] button in the Linkage menu to call the setup screen shown below. ●Return to Linkage menu When using at the student side When using at the teacher side 1. Select the mode. 1. Select the mode. *When changing the mode, tap to the item you want to *When changing the mode, tap to the item you want to change and change the mode using the "▼▼"...
Page 115 "--" : Always ON. "SA"~"SH": The switch which enables student Futaba is not responsible for damage side operation can be selected. (See "Switch sustained by combination with parts other selection method" at the end of this manual than Futaba Genuine equipment.
Page 116: Warning Setting
Warning setting Mixing warning normal reset The warning display at power ON can be turned ON/OFF for each function. Use by setting functions which may be dangerous if operated at power ON to ON. Initial setting is all ON (Buzzer). ●...
Page 117: User Menu Setting
User menu setting Original menu screen making *Any change made to data entered from the User menu or T16IZ has a menu for each of the following: from the normal method of use are the same. Changes made System, Linkage, and Model. Also, you can in either way are saved into the transmitter memory.
Page 118: Data Reset
Data reset Model memory setting data reset. (by item) This function is designed to allow you to reset *The trim step amount and trim rate are not reset. selected portions or all of the settings saved in Model menu setting: the active model memory.
Page 119 MODEL MENU (Airplane/Glider functions) The dedicated mixes, etc. usable when airplane Condition select function to add flight conditions. or glider model type is selected are displayed (Up to 8 conditions can be used) in this Model menu functions section. First use Note: The T16IZ is designed so that the airplane and glider model types can handle aircraft of the same the Model type function of the Linkage menu to...
Page 120: Condition Select
Condition select Flight condition's addition, deletion, copy, condition renaming, and condition delay can be set. [All model types] The functions in the Model menu can be used by positions and when there are variations in the operating time between channels during switching the settings of up to 8 flight conditions condition switching can be suppressed.
Page 121 Currently selected condition name The ON/OFF switch of Conditions List condition is chosen. Condition Copy Condition Remove 1. Tap the [Copy] button. The Copy screen 1 . S e l e c t t h e c o n d i t i o n b y appears.
Page 122: Afr
The angle and curve of each operation function can be set. [All model types] AFR function is used to adjust the throw and This is normally used after End Point has defined operation curve of the stick, lever, and switch the maximum throw.
Page 123: Dual Rate
Dual rate 100% D/R curves which can be switched by switch, etc. can be added. The curve can be adjusted by the AFR function. ● Up to 6 rates can be added for each condition. ● D/R is set for each condition and is not reflected at other conditions.
Page 124: Prog, Mixes (Program Mixing)
Program. mixes Program mixing which can be freely customized. Up to 10 mixings can be used for each condition. [All model types] Programmable mixing may be used to correct Offset-type mixing applies a fixed offset or preset to the programmed channel servo operation and undesired tendencies of the aircraft, and it may also be used for unusual control configurations.
Page 125 Setting methods 1. To turn the trim mode ON/OFF, tap the Trim button on the screen. ●Group/single mode selection *When mixing includes master side trim, set the Trim button Activating functions for only the selected to [ON]. When mixing does not include master side trim, set conditions: the Trim button to [OFF].
Page 126: Aileron Differential ��126 Flight Tune (Aileron/Elevator Basic Settings)
Aileron differential [Airplane/glider, 2 ailerons or more] The left and right aileron differential can be adjusted independently. The differential rate can also be adjusted according to the flying state by setting a fine tuning VR. AIL1 AIL 2 (Main Aileron) (Main Aileron) AIL 3 AIL 4...
Page 127: Flap Setting ��127 Rudder Basic
Flap setting [Corresponding model type]: Airplane/ glider, 2 flaps or more] The up/down travel of each flap (camber flaps: FLP1/2, brake flaps: FLP3/4) can be adjusted independently at each servo according to the wing type. FLP 4 ● The operation reference point of each flap can be FLP 3 (Brake Flap) (Brake Flap)
Page 128: Ail → Camber Flap
AIL → Camber flap [Corresponding model type]: Airplane/ glider, 2 ailerons + 2 flaps or more This mix operates the camber flaps (FLP1/2) in the aileron mode. When the aileron stick is manipulated, the ailerons and camber flaps perform aileron operation simultaneously and the operation characteristic of the roll axis is FLP 1 FLP 2...
Page 129: Ail → Brake Flap
AIL → Brake flap [Corresponding model type]: Airplane/ glider, 4 flaps or more This mix operates the brake flaps (FLP3/4) in the aileron mode. When the aileron stick is manipulated, the aileron and brake flaps perform the aileron operation simultaneously FLP 4 FLP 3 (Brake Flap)
Page 130: Aileron → Rudder
Aileron → Rudder [Corresponding model type]: Airplane/glider, general Use this mix when you want to mix the rudders with aileron operation. ● A mixing curve can be set. AIL1 AIL 2 (Main Aileron) (Main Aileron) ● Mixing during flight can be turned ON/OFF by AIL 3 AIL 3 (Chip Aileron)
Page 131: Elevator → Camber
Elevator → Camber [Corresponding model type]: Airplane/glider, 2 ailerons or more Note: Tailless wing elevator can be operated This function is used when you want to mix the when this mix is activated. camber flaps with elevator operation. When used, the flaps are lowered by up elevator, and lift can ●...
Page 132: Camber Mixing
Camber mixing [Corresponding model type]: Airplane/glider, 2 ailerons or more ● The up/down side rates of the aileron, flap, and elevator servos can be adjusted by curve. When This function adjusts the rate of camber the mixing direction is reversed by the linkage, operation which operates the wing camber adjustments can be made by changing the (ailerons, camber flaps, brake flaps) in the...
Page 133 Setting method (Curve/rate setup screen) ● Tap [INH]. ● The curve and rate are adjusted by calling (ON is displayed.) the aileron, flap, and elevator curve/rate ● When setting a switch, tap to the [--] item screens. of the switch and tap the screen to call the The rate and curve of each servo can be set selection screen, and then select the switch by calling each screen.
Page 134: Airbrake → Ele
Airbrake → ELE [Corresponding model type]: Airplane/glider, general AIR BRAKE This mix is used when you want to mix the elevators with airbrake (spoiler) operation. It raises the elevators to correct for dropping of the nose during airbrake operation. AILVATOR V-TAIL *This function does not operate when airbrake is not assigned at the Function menu in the Linkage menu.
Page 135: Camber Flap → Ele ��135 Govenor Expert
Camber flap → ELE [Corresponding model type]: Airplane/ glider, 2 ailerons + 1 flap or more This mixing is used to correct changes (elevator direction) generated when the camber flaps (speed flaps) are used. FLP 1 FLP 2 (Camber Flap) (Camber Flap) ●...
Page 136: Rudder → Aileron
Rudder → Aileron [Corresponding model type]: Airplane/glider, general This function is used when you want to mix the ailerons with rudder operation. It is used when rudder is applied during roll maneuvers, knife AIL1 AIL 2 (Main Aileron) (Main Aileron) edge, etc.
Page 137: Rudder → Elevator
Rudder → Elevator [Corresponding model type]: Airplane, general This function is used when you want to mix ● Link can be set: Links this mixing to other mixings. ● The mixing rate can be fine-tuned by setting a VR. elevator operation with rudder operation. It is used (Fine tuning) to correct undesirable tendencies when rudder is applied in roll maneuvers, knife edge, etc.
Page 138: Butterfly
Butterfly [Corresponding model type]: Glider, 2 ailerons or more This function allows powerful brake operation ● Mixing during flight can be turned ON/OFF by setting a switch. (Always ON at [--] setting) by simultaneously raising the left and right ● The butterfly operation reference point can be ailerons and lowering the flaps (camber flap, offset.
Page 139 ●Return to Model menu Select the Mixing Rate AIL and FLP box. Adjust the mixing rates. Elevator rate adjustment (To elevator curve setup screen) Fine tuning *In case of tailless setting wing not display. (Elevator correction rate setup screen) The offset position is indicated by a red dotted line by an elevator curve.
Page 140 Throttle stick full stroke MODE ● Mode A ● Mode B (Normal) (Throttle stick full stroke MODE) ● The butterfly operation direction is reversed ● It does not reverse at the neutral position, at the neutral position (50) of the throttle so you can set the butterfly operation start stick.
Page 141: Trim Mix 1/2 ��141 Condition Select
Trim mix 1/2 [Corresponding model type]: Glider, general These functions call the ailerons, elevators, and Example flaps (camber flaps, brake flaps) trim offset rates 1. Move to the [INH] item Set the trim mix function to preset according to the flight state. [ON].
Page 142: Snap Roll (Airplane Only)
Snap roll [Corresponding model type]: Airplane, general (Example) Setting example for F3A This function selects the switch and rate adjustment ● Mode: [Master] of each rudder, (ailerons, elevators, or flaps) when ● Safety SW: [SW-G] (Safety measure) a snap roll is performed. ●...
Page 143: Air Brake (Airplane Only)
Air brake [Corresponding model type]: Airplane, general This function is used when an air brake is necessary when landing or diving, etc. Elevator The preset elevators and flaps (camber flap, Aileron 2 brake flap) offset amount can be activated by a switch.
Page 144: Gyro
Tap to the [Rate] item. Adjust the rate. ● When using this function, Tap [INH]. ● When a Futaba GYA gyro is used, when [GY] type is selected, the sensitivity set value is directly read in both the AVCS and Normal modes.
Page 145 (Example) Setting three axis using a GYA450 and GYA451 (2) ● Wing type: Aileron 2 servos mounted fuselage selected ● Set 5CH → Gyro (GYA451AIL), 7CH → Gyro2 (GYA451ELE), 8CH → Gyro3 (GYA450RUD), Control and Trim → "--" : at the Function menu of the Linkage menu.
Page 146: Ailevator
Ailevator [Corresponding model type]: Airplane/glider, Tail type Ailevator (Effective only when 2 servos used at the elevators) This function improves the operating performance of the roll axis by operating the elevators as ailerons. Ailevator is where each elevator in a standard (conventional) or v-tail moves independently, like ailerons on a wing.
Page 147: Acceleration
Acceleration [Corresponding model type]: Airplane/glider general Acceleration setting can be performed at Elevator, Elevator → Camber and Aileron → Rudder. (Glider only) ● This setting is divided into elevator setting and camber setting. The setting method is the same. ● Camber setting sets the acceleration function for Ele to camber mixing.
Page 148: Motor
Motor [Corresponding model type]: Airplane/glider, general This function lets you set the operation speed when ● The set operation speed operation can be activated at initial operation only. (1 time the motor of an F5B or other EP glider is started by operation) However, operation can be repeated switch.
Page 149: V-Tail��149 Screen
V-Tail [Corresponding model type]: Airplane/glider, Tail type V-tail This function lets you adjust for left and right rudder angle changes at elevator and rudder operation of a V-tail airplane. V-tail is when 2 servos are used together to control rudder movement as elevators. In addition to each ELEVATOR RUDDER rudder side moving up and down together, each side...
Page 150: Winglet
Winglet [Corresponding model type]: Airplane/glider, winglet(2RUD) This function adjusts the left and right rudder angles of airplanes with winglets. It can be used for special airplanes with two rudders. The amount of movement of the two mounted rudder servos can be adjusted separately. RUDDER 1 Two servos are operated with one rudder stick.
Page 151 MODEL MENU (Helicopter functions) This section contains information on the commands Also, add flight conditions at the Condition Select that apply to helicopters only. For instructions screen if necessary before setting the model data at on airplane, glider and multicopter, refer to the each function.
Page 152: Condition Select ��152 ●Operations Related To Servo Speed
Condition select Flight condition's addition, deletion, copy, condition renaming, and condition delay can be set. [All model types] The functions in the Model menu can be used by positions and when there are variations in the operating time between channels during switching the settings of up to 8 flight conditions condition switching can be suppressed.
Page 153 Currently selected condition name The ON/OFF switch of Conditions List condition is chosen. Condition Copy Condition Remove 1. Tap the [Copy] button. The Copy screen 1 . S e l e c t t h e c o n d i t i o n b y appears.
Page 154: Afr ��154 ●Curve Setting Operation
The angle and curve of each operation function can be set. [All model types] AFR function is used to adjust the throw and This is normally used after End Point has defined operation curve of the stick, lever, and switch the maximum throw.
Page 155: Dual Rate
Dual rate D/R curves which can be switched by switch, etc. can be added. The curve can be adjusted by the AFR function. ● Up to 6 rates can be added for each condition. ● D/R is set for each condition and is not reflected at other conditions.
Page 156: Prog, Mixes (Program Mixing) ��156 ●Pc Port
Program. mixes Program mixing which can be freely customized. Up to 10 mixings can be used for each condition. [All model types] Offset-type mixing applies a fixed offset or preset Programmable mixing may be used to correct to the programmed channel servo operation and undesired tendencies of the aircraft, and it may also may control up to four circuits simultaneously.
Page 157 Setting methods 1. To turn the trim mode ON/OFF, tap the Trim button on the screen. ●Group/single mode selection *When mixing includes master side trim, set the Trim button Activating functions for only the selected to [ON]. When mixing does not include master side trim, set conditions: the Trim button to [OFF].
Page 158: Pitch Curve
Pitch curve / Pitch trim Pitch curve This function adjusts the pitch operation curve for *Up to 17 points can be set for the point curve types. However, when using the 3 points or 5 points specified to each flight condition for the optimal flight state create a curve, a simple curve can be created by reducing relative to movement of the throttle stick.
Page 159 Setting method ● Group/Single item: When you also want to input the same setting contents at other conditions, perform setting in the group mode. In this case, the same contents are input to the other conditions set in the group mode.
Page 160 Pitch trim (Hovering pitch, high pitch, low pitch) The hovering pitch, low pitch, and high pitch trim setup screen can be called from the Pitch curve setup screen. ●Return to Model menu Hovering pitch trim Low/high pitch trim setting setting Hovering pitch trim High Pitch/Low Pitch Trim The Hovering Pitch trim function trims the pitch...
Page 161: Throttle Curve ��161 ●Updating
Throttle curve / Throttle Hover trim Throttle curve This function adjusts the throttle operation curve point data is used, a simple curve can be easily for each condition for optimum engine speed to created by reducing the number of input points of throttle stick movement.
Page 162 Curve setting examples created by reducing the number of points on the The curves shown below are created by using the line to 5. When actually creating a curve, enter point curve type and inputting the data of the 5 the data specified per the aircraft (or the reference points 0% (low side), 25%, 50% (center), 75%, value).
Page 163: Acceleration
Acceleration This function is used to adjust the pitch and the throttle rise characteristic at acceleration/ deceleration operation. An acceleration function which temporarily increases the pitch and throttle operations at throttle stick acceleration/deceleration operation can be set. Example of acceleration function use ●When used at pitch, the acceleration function is effective when you want to quicken the response of the fuselage at 3D...
Page 164: Throttle Hold
Throttle hold Example of use ● Since throttle hold has 2 modes (Cut) and (Idle), using it in the Idling mode during This function sets the throttle cut position for t r a i n i n g a n d i n t h e C u t m o d e w h e n autorotation.
Page 165: Swash Mixing
Swash mixing Example of use ● As an example, use swash mixing to correct undesirable tendencies in the roll direction. The swash mix function is used to correct the swash ● For a condition which uses Aileron to plate in the aileron (roll) direction and elevator Elevator, set this function to ON.
Page 166: Throttle Mixing
Throttle mixing When correction is necessary, tap to the mixing item corresponding to the mixing that needs This function corrects slowing of engine speed correction and tap the screen to call the curve setup caused by swash plate operation during aileron screen, and then correct the slowing.
Page 167: Pitch → Needle
Pitch → Needle This mixing is used when the engine is equipped increases needle operation at throttle stick with needle control or other fuel-air mixture acceleration/deceleration operation can be set. adjustment. A needle curve can be set. The rise characteristic of the needle servo at acceleration and deceleration operation can be An acceleration function which temporarily adjusted.
Page 168: Pitch → Rudder (Revolution Mixing)
Pitch → Rudder (Revolution mixing) Use this mix when you want to suppress the However, when a GY Series or other heading hold reaction torque generated by main rotor pitch and gyro is used, since correction is performed by the speed changes during pitch operation.
Page 169: Gyro (Helicopter)
Gyro　[Helicopter] This function is used to adjust gyro sensitivity. The Note: [Gyro] [Gyro2] [Gyro3] Default function sensitivity and operation mode (Normal mode/ [Gyro]: CH6(FASSTest12CH) CH5(Other system type) AVCS mode) can be set for each condition. [Gyro2] : CH9 The gyro sensitivity can be switched with each [Gyro3] : CH10 condition or the switch.
Page 170 Usage example #1: Using gyro for only the rudder and adjusting sensitivity for each condition ＊ Gyro gain channel Gyro : CH5 For the FASSTest12CH, Gyro/RUD is 6ch. The gyro sensitivity adjustment connector connects to 6ch. ● Select [Gyro] at the This is all that is needed model menu and call for use in this case.
Page 171: Governor
Governor When using a Futaba governor, this function is *When using the Fuel Mixture function, the mixture servo is controlled from the governor. When transmitting the used to switch the RPM of the helicopter's head. mixture curve data from the transmitter to the governor, the Up to 3 rates can be set for each condition.
Page 172 ●Diplay mode selection ●Fine tuning VR settings *When [rpm] mode is selected above setting, the display Tap to the [--] item and tap the screen to mode can be selected. access the selection screen. Select the * There is no change in the transmitter output even when the control.
Page 173: Gyro Setting Cgy755 Cgy760R
Gyro setting The T16IZ has the same functions as the GPB-1. The CGY755 / CGY760R can be set up from the T16IZ screen by connecting to the T16IZ. Some functions can be set wirelessly. *CGY760R needs to be Ver3.0 ~. Update CGY760R. A. Wired connection: Advanced settings (all functions same as GPB-1) T16IZ Notes...
Page 174: Wired Connection:advanced Setting
SETTING A. Wired connection: Advanced settings CAUTION Be sure to connect and disconnect the CGY760R/CGY755 and T16IZ connection cable with the power off. *If "CRSF" is ON in the system type of the linkage 1. Select "Gyro setting" on the last page of menu, "Gyro setting" cannot be selected. Helicopter Model Menu * At this time, if Gyro is not connected to T16IZ by wire, the EQ ID screen appears.
Page 175: Wireless Tunings
SETTING B. Wireless tunings Before making Wireless tunings, it is necessary to download the setting data from the gyro to the T16IZ via a wired connection. First, wired connection T16IZ ● Connect the receiver battery (3.5 to 8.4 V) to CGY755/CGY760R one of the "AIL" to "S.B2" connectors other than "RPM"...
Page 176 Home Screen Home Screen Home Screen Display Condition number On the home screen, basic information such as swash type, With switch operation from the transmitter, several parameters can be switched by gyro operation mode, sensitivity and governor ON / OFF, setting up to 5 types of data. If you set the condition switch to the channel having the AFR function of the transmitter and set the point for each flight condition with the engine operating time etc, are displayed.
Page 177 Home Screen Home Screen Home Screen Basic menu screen ◆ Flight Tune（Aileron, Elevator） ◆ Swash Basic（Swash） ◆ Rud Basic（Rudder） ◆ Gov Basic（Governor） ◆ S.BUS Basic Expert menu screen ◆ Swash Detail（Swash） ◆ Flight Tune Expert（Aileron） ◆ Rudder Expert（Rudder） ◆ Governor Expert（Governor） Receiver screen ◆ Internal Rx ◆ RF type...
Page 178: Basic Menu
Basic Menu Basic Menu As the name suggests, this menu allows changes to the basic settings of CGY. Make sure to set each "BASIC MENU". Basic menu screen ◆ Flight Tune（Aileron, Elevator） ◆ Swash Basic（Swash） ◆ Rud Basic（Rudder） ◆ Gov Basic（Governor） ◆ S.BUS Basic...
Page 179: S.bus Basic Menu
This selects the ELE2 servo types. There are three types of the servo driving frequency selection, AN:70 Hz, DG285 Hz, and 760 μS. All Futaba digital servos can be operated with fastest DG:285 Hz mode but some of other brands of servos do not support DG:285 Hz mode.
Page 180: Swash Basic
This selects the swash servo types. There are four types or modes of the servo driving frequency selection, AN:70 Hz, DG:95 Hz, DG:140 Hz, DG285 Hz, and 760 μS. All Futaba digital servos can be operated with fastest DG:285 Hz mode but some of other brands of servos do not support DG:285 Hz mode.
Page 181 Swash Basic Swash Basic (4) SWASH Type: Swash change to plate type Select the swash plate type. When you change the setting, other data is initialized. Setting: H-1 / H3-120 / H3-140 / H3-90 / H4-00 / H4-45　　　Initial setting: H3-120 WARNING All of the swash plate parameters are reset when the swash plate type is changed. Doing so eliminates any possible errors or mal- functions within the system.
Page 182 Swash Basic Swash Basic (6)AIL, ELE, PIT. Ntr: Servo neutral adjustment Adjust the neutral position of the swash servo (aileron, elevator, pitch, second elevator). The second elevator (ELE2) is displayed only when the swash type is H4-xx. Setting ranges: +240 ~ -240 Initial value: 0 (7) SWS. Dir: Swash direction setting This selects the aileron, elevator and collective pitch direction.
Page 183 Swash Basic Swash Basic (14) Pit. High: Pitch high memorizing This parameter saves the full positive collective pitch point into the CGY. [Setting method] Touch the "Pit. High" rate button to enter the setting mode. Operate the throttle stick fully to the high. Touch the “Pit. High” rate button again.
Page 184 Flight Tune（Aileron / Elevator Basic settings） Flight Tune（Aileron / Elevator Basic settings） Flight tune sets control of helicopter roll (aileron) and pitch (elevator) axis. "FLT. TUNE" screen from the "BASIC MENU" screen. Cond (1) Base. Gain: Gyro base gain setting This sets the Cyclic Gyro Base Gain. If the Rotor Head Gain (Rot HD Gn) Channels are set to "INH"...
Page 185 Flight Tune（Aileron / Elevator Basic settings） Flight Tune（Aileron / Elevator Basic settings） Cond (3) Cnt. AuthAIL: Control Authority Aileron Aileron Control Authority changes the rate at which the gyro will try to achieve the set "CYC. Rt". A higher value will create a quicker accelerated reaction to a stick input to reach and stabilize to the "CYC. Rt" value; a lower value will reach the desired "CYC.
Page 186 Flight Tune（Aileron / Elevator Basic settings） Flight Tune（Aileron / Elevator Basic settings） Note: To effectively operate the next "ELE Comp" (elevator correction), make sure to set "Pit High", "Pit Zero", "Pit Low" on the "SWASH BASIC" menu. Cond (7) ELE. Comp: Elevator pre compensation A helicopter that has a head that rotates clockwise, will exhibit a tendency whereby the nose will be pulled towards the disk with positive blade pitch.
Page 187 Rudder Basic Rudder Basic In the "Rudder Basic" menu, you make the basic setting of the rudder gyro. WARNING "Rudder Basic" screen from the "BASIC MENU" screen. The servo type parameter within the CGY must match the type of servo you are using. Incorrect settings may damage the CGY or the servo.
Page 188: Govenor Basic
Governor Basic Governor Basic This menu sets the governor’s fundamental functions. The menu Servo limit point set- Note: When using the governor function, be sure ting must be set first. to make each setting of "Governor Basic". Note: After completing the linkage of the throttle, "Governor Basic"...
Page 189 Governor Basic Governor Basic (6) Stick sw.: Stick switch The governor can be activated by throttle stick position. [Setting method] Touch the "Stick SW" button to enter the setting mode. Operate the throttle stick to the position where you want to turn Governor ON.
Page 190 Governor Basic Governor Basic (11) SenseTyp: Sensor type Select the type of governor sensor. Nitro (BPS-1 backplate; Magnet Type) 1:1 Magnet "1:1 Magn" (Magnet type applied to helicopter part that turns at the same RPM as the main rotor) HPoleEP: For Electric motors 8 poles and above LPoleEP: For electric motors 6 poles.
Page 191: Expert Menu
Expert Menu Expert Menu This menu enables the user to further refine the gyro and governor settings. Expert Menu ◆ Swash Detail（Swash） ◆ Flight Tune Expert（Aileron・Elevator） ◆ Rudder Expert（Rudder） ◆ Governor Expert（Governor）...
Page 192: Rudder Expert
Rudder Expert Rudder Expert The rudder Expert menu allows for further refinement of the tail rotor gyro performance. "Rudder Expert" screen from the "EXPERT MENU 3D" screen. (1) RUD Ntr: Rudder servo neutral setting This parameter is used to set the neutral position of the rudder servo. Po- sition the rudder servo arm as perpendicular as possible to the tail rotor pushrod prior to making adjustments with this parameter.
Page 193 Rudder Expert Rudder Expert (3) CNT. DlIn: Control delay in This parameter sets the delay as you move the stick from neutral toward left or right. Larger values result in a softer tail rotor feel off center. This parameter must be adjusted individually for LEFT and RIGHT tail rotor commands.
Page 194 Rudder Expert Rudder Expert (6) F/F.Rate U / F/F.Rate D: F/F mixing rate Feed Forward mix is used to counteract sudden increases in torque from the motor during fast collective pitch changes. If you notice a tail kick, using (right rudder on Clockwise rotor disk, left rudder on CCW) F/F mixing can be tuned to reduce the tail kick.
Page 195: Flight Tune Expert (Aileron/Elevator Expert Settings)
Flight Tune Expert（Aileron/Elevator Gyro Expert Setting） Flight Tune Expert（Aileron/Elevator Gyro Expert Setting） The "Flight Tune Expert" menus allow further refinement of cyclic gyro performance. "Flight Tune Expert" screen from the "EXPERT MENU 3D" screen. Cond (1) HeadHld A / HeadHld E: Head hold aileron / elevator This features is used to adjust the heading hold aspect of the gyro control. If the helicopter is not holding angle or cyclic control rates, increasing the heading hold gain will improve holding the helicopter at a certain angle and improve the cyclic rate consistency.
Page 196: Swash Detail
Swash Detail Swash Detail The swash detail setting is used to keep the swash plate level at high and low collective pitch to cyclic interactions and cyclic pitch to collective pitch interactions. "Swash Detail" screen from the "EXPERT MENU 3D" screen. (1) PIT AIL: collective pitch aileron mixing rate Going from MID to HIGH and MID to LOW collective pitch check that the...
Page 197 Swash Detail Swash Detail (7) ELE PIT: elevator collective pitch mixing rate During back and forward elevator inputs at middle collective, check if the swash plate is raising or lowering during the input. [Setting method] Operate the transmitter stick in the direction you want to set.
Page 198 Swash Detail Swash Detail (12) ELE High / ELE Low: Linkage compensation elevator At both the HIGH pitch and LOW pitch check to make sure that the swash plate is staying level on the aileron and collective axis when using elevator inputs. If the swash plate is rising or falling: [Setting method] Operate the transmitter stick in the direction you want to set.
Page 199 Governor Expert Governor Expert This menu sets the Governor Expert parameters, allowing the user to further refine the governor settings. "Governor Expert" screen from the "EXPERT MENU 3D" screen. (1) Work Mode: Governor working mode Sets the governing type mode. - GOVERNOR (Governor Mode) – RPM is entirely controlled by the GOV once it has engaged.
Page 200 Governor Expert Governor Expert (6) Revo. Up Dly: Revolution change up delay How quickly the RPM changes when increasing RPM between two different RPM conditions and flight modes. A higher number slows the RPM change rate; a lower value speeds up the RPM change rate. Setting ranges: 2 ~ 40 Frm Initial value: 8 Frm (7) Revo.
Page 201 MODEL MENU (Multicopter functions) The dedicated mixes, etc. usable when These dedicated mixes can be set for each multicopter model type is selected are displayed flight condition, as required. When you want to in this Model menu functions section. use the system by switching the settings for each condition by switch or stick position, use the Condition select function to add flight conditions.
Page 202 Condition select Flight condition's addition, deletion, copy, condition renaming, and condition delay can be set. [All model types] The functions in the Model menu can be used by positions and when there are variations in the operating time between channels during switching the settings of up to 8 flight conditions condition switching can be suppressed.
Page 203 Currently selected condition name The ON/OFF switch of Conditions List condition is chosen. Condition Copy Condition Remove 1. Tap the [Copy] button. The Copy screen 1 . S e l e c t t h e c o n d i t i o n b y appears.
Page 204: Afr
The angle and curve of each operation function can be set. [All model types] AFR function is used to adjust the throw and This is normally used after End Point has defined operation curve of the stick, lever, and switch the maximum throw.
Page 205: Dual Rate
Dual rate D/R curves which can be switched by switch, etc. can be added. The curve can be adjusted by the AFR function. ● Up to 6 rates can be added for each condition. ● D/R is set for each condition and is not reflected at other conditions.
Page 206: Prog, Mixes (Program Mixing)
Program. mixes Program mixing which can be freely customized. Up to 10 mixings can be used for each condition. [All model types] Offset-type mixing applies a fixed offset or preset Programmable mixing may be used to correct to the programmed channel servo operation and undesired tendencies of the aircraft, and it may also may control up to four circuits simultaneously.
Page 207 Setting methods 1. To turn the trim mode ON/OFF, tap the Trim button on the screen. ●Group/single mode selection *When mixing includes master side trim, set the Trim button Activating functions for only the selected to [ON]. When mixing does not include master side trim, set conditions: the Trim button to [OFF].
Page 208: Operations Value Setting
Common operations used in function setup screen This section describes the functions often used at the function setup screen. Refer to it when setting each function. Operations value setting Tapping the value setting buttons on each screen will cause value input buttons to appear at the top of the panel.
Page 209: Operations Related To Fine Tuning
Operations related to fine tuning VR Operation mode selection *The operation modes which can be selected depend on the function. VR selection Rate adjustment (Fine tuning VR operation position) [Setting method] [Fine tuning VR operation mode] 1. Control selection [LIN.] M i x i n g r a t e 0 % a t c e n t e r o f V R . When the VR is turned clockwise and Tap the [Control] "--"...
Page 210 Operations related to servo speed Linear （First） 0 ～ 27 （ Slowly）（First） 0 ～ 27 （ Slowly） In case of Linear Speed In speed Servo speed setting The servo speed at each function operation (including flight condition switching) can be adjusted. The servos Out speed Speed operate smoothly at a fixed speed...
Page 211 Curve setting operation This section describes the setting procedure of curves which are used with the AFR function and each mixing function. Curve type selection Four types of curves (EXP1, EXP2, Point and Spline) can be selected. Curve type selection 1.
Page 212 Setting by curve type When the curve type is selected as described above, adjustment items corresponding to the curve type appear on the screen. Adjust each curve as described below. EXP1/EXP2 curve adjustment 1. Tap to the [Offset] setting item. (EXP1 curve) 2.
Page 213 Point curves or spline curves of up to 11/17 points can be used. (Initial value: 7/9 points) The set points can be freely increased, decreased, and offset. Point addition method 5. Press "Rate" and use the up/down arrows to adjust the rate points up or down. 1.Open the screen of a mixing curve with the curve function.
Page 214 Curve setting operation Spline curve Up to 11 or 17 points curve can be used. (differs with function) A smoother curve is made. Initial point number: 9 points (17 points Setting method is same at spline and point. curve), 7 points (11 points curve) Point Spline *The set points can be freely increased, decreased, and...
Page 215: Switch Selection Method
Switch selection method The various functions used in the T16IZ can be selected by switch. The switch (including when stick, trim lever, or VR are used as a switch) setting method is common to all functions. Switch selection When a switch is selected at a mixing function, etc., the selection screen shown below is called. (Switch selection screen example) Tap the chosen switch.
Page 216 Hysteresis-type and box-type can be selected in a hardware select screen. When a stick, trim lever, or VR is used as a switch, the following 4 modes can be selected. ◆ Linear・Hysteresis mode ◆ Symmetry・Hysteresis mode This setting method selects function ON/OFF based The operation is the same as the linear hysteresis on the set point.
Page 217 When shifting the ON/OFF point ◆ Area Green：ON The ON/OFF and hysteresis (dead band) boundary point (there ◆ Area Red：OFF are 2 points: top and bottom) position can be shifted. ON/OFF is ◆ Area Yellow：Hysteresis (Dead band) possible at a free position. [ Setting method ] Reverse of ON/ 1.
Page 218 Logic switch (Condition select and DG1, DG2) The logic switch function lets you turn operation on and off by combining two switches. For instance, the condition is activated when 2 switches are turned on. Logic mode AND: When both switches are ON, the condition is ON.
Page 219: Realflight Connection Method
3 . S e t " D e a d b a n d P e r c e n t a g e ( % ) " o f "Controller" to 0. 4. Click the [OK] button to close the "Settings" dialog. 5. Select "Select Controller ..." from the "Simulation" menu to open the "Select Controller" dialog. 6. Set "Profile" to "Futaba" and click the [Edit] button.
Page 220 7. If necessary, assign channels and make reverse settings. After setting, click the [Save As ...] button to save the profile. 8. Click the [Close] button to return to the "Select Controller" dialog. 9. Click the [Calibrate] button to calibrate. Set the stick, switch, dial, and lever to be used in the neutral position, and press the [Next] button.
Page 221 Updating Your Futaba T16IZ transmitter programming can be updated easily online. When functions are added or improved, the update file can be downloaded from our website. Copy the update files to the SD card and then use the following procedure to update the program.
Page 222 7. When the software update is completed, Don't absolutely remove the battery "Completed" message is shown on the LCD and the SD card from the transmitter display of your T16IZ. (Show below picture.) during the update. There is a possibility that the transmitter will be damaged.
Page 223: T14Sg/Fx-22/T12K ⇒ T16Iz Conversion
T14SG/FX-22/T12K → T16IZ MODEL DATA CONVERSION The model data (only latest version) of T14SG/FX-22/T12K can be copied to T16IZ. * SD card is required. * The model data of T16IZ cannot be copied to T14SG/FX-22/T12K. 5. The converter can accept model data [Model data conversion method] made by T14SG/FX-22/T12K with the latest 1.
Page 224 CONSEQUENTIAL DAMAGES, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF THE USE OR INABILITY TO USE THE FONT SOFTWARE OR FROM OTHER DEALINGS IN THE FONT SOFTWARE. FUTABA CORPORATION Hobby Radio Control Business Center Sales & Marketing Department...

This manual is also suitable for:

T16iz series 01000141

FUTABA R7108SB Full Manual

Quick Links

Related Manuals for FUTABA R7108SB

Summary of Contents for FUTABA R7108SB

This manual is also suitable for:

Table of Contents
