Rot. Char Size
When the Rotated Character Size option is Adjusted, rotated
(clockwise/counter–clockwise), expanded characters have a different size than
an unrotated character with the same size parameters. If Not Adjusted, rotated,
expanded characters will be the same size as unrotated characters with the
same size parameters.
Ignore Spaces
When disabled, trailing spaces are NOT deleted from alphanumeric elements in a
graphics pass. When enabled, trailing spaces are deleted from alphanumeric
elements in a graphics pass.
Midline ^PY (includes ^PN)
When disabled, the Graphics mode Enabled command, ^PY, must be the first
three characters of a line. When enabled, the ^PY or ^PN can occur anywhere in
a line.
Dark barcode
When enabled, bar codes will be printed in dark mode no matter what the dark
mode is set for. If this option is disabled, dark mode printing will only occur if the
dark mode command is sent before the bar code command.
Expanded Font
Scalable: These expanded characters have rounded edges.
Block: These are block characters compatible with the IGP–X10
printers.
Width Limit
When enabled, the system will limit the length and width for expanded characters
to a limit shown in the following table.
allowed for a specific height in the range of 00 to 40 (0.0 to 4.0 inches).
Configuration Menus
Table 4–1 shows the maximum width
