Printronix ProLine 5 Series Manual page 155

Dataproducts (Standard & Longlines) Submenu
Dataproducts
(From 4–97)
Data Bit 8 PI Ignored
Enable * Enable *
Disable Disable
Prime Signal
Data Bit 8
The Data Bit 8 parameter allows access to the extended ASCII character set.
Normally, this parameter is enabled. When this parameter is disabled, the printer
interprets bit 8 of each incoming data character as a zero, regardless of its actual
setting.
PI Ignored
The PI (Paper Instruction) signal is used to control vertical paper motion.
Enable causes the printer to interpret the eight data lines as DVFU
commands when the PI signal is true.
Disable ignores the PI signal and treats the data as characters or
control codes.
Data Polarity
The Data Polarity parameter must be set to match the data polarity of your host
computer.
Standard does not expect the host computer to invert the data.
Inverted expects the data received on the data lines from the host
computer to be inverted. Ones become zeros, and vice-versa.
4–102
Data Polarity
Standard *
Inverted
TOF Action
Disable* Reset*
Enable Do nothing
* = Factory default
Response Latch Data On
Polarity
Standard * Middle*
Inverted Trailing
Leading
Buffer Size
in k
1*
1–16
Configuration Menus
