Table 5–5. RS–232 Serial Interface Connector Pin Assignments
Input Signals
Signal
Receive Data (RD)
Clear To Send (CTS)
Data Set Ready (DSR)
Data Carrier Detect (DCD)
Received Data (RD) — Serial data stream to the printer.
Transmitted Data (TD) — Serial data stream from the printer for transmitting
status and control information to the host. Subject to protocol selection.
Request To Send (RTS) — Control signal from the printer. Subject to
configuration.
Clear To Send (CTS) — Status signal to the printer indicating the host is ready to
receive data/status signals from the printer.
Data Set Ready (DSR) — Status signal to the printer indicating the host is in a
ready condition.
Data Carrier Detect (DCD) — Status signal to the printer. The ON condition is
required for the printer to receive data.
Data Terminal Ready (DTR) — Control signal from the printer. Subject to
configuration.
5–16
Output Signals
Pin Signal
3 Transmit Data (TD)
5 Request To Send (RTS)
6 Data Terminal Ready (DTR)
8
Miscellaneous
Pin Signal
2 Chassis Ground
4 Signal Ground
20
Pin
1
7
Interfaces
