Printronix ProLine 5 Series Manual page 129

Proprinter XL
Define CR Code
This option controls the action of the printer when it receives a Carriage Return
code (0D hex) from the host computer. If this feature is enabled, each time the
printer receives a Carriage Return, it inserts an additional Line Feed code (0A
hex) into the data stream. Do not use this feature if the host computer sends Line
Feeds to the printer.
CR = CR does not insert an extra Line Feed after each Carriage Return.
CR = CR + LF inserts an extra Line Feed after each Carriage Return.
Auto LF
This option defines the printer actions when print data is received past the forms
width setting.
Enable performs an automatic carriage return and line feed when data
is received past the forms width.
Disable discards any data past the forms width.
Define LF Code
This option determines whether an automatic carriage return should occur
whenever a line feed command is received.
LF = LF does not perform an automatic carriage return. The next print
position will be the current print position of the next line.
LF = CR + LF forces an automatic carriage return with each line feed
command. The next print position is position 1 of the next line.
FF Valid at TOF
The FF Valid at TOF option determines whether the printer will perform a Form Feed
when the host sends a Form Feed command, if the printer is at the Top of Form.
Disable will not perform a form feed when the host sends a Form Feed
command and the printer is at the Top of Form.
Enable performs a form feed when the host sends a Form Feed
command and the printer is at the top of form.
4–76 Configuration Menus
