Printronix ProLine 5 Series Manual page 74

Define LF Code (Line Feed)
This parameter forces the printer to insert an automatic Carriage Return code
into the data stream whenever a Line Feed code occurs. This can be used in
most installations, but it is required if the host computer does not send Carriage
Returns to the printer.
LF = LF. Does not perform an automatic carriage return. The next print
position will be the current print position of the next line.
LF = CR + LF. Performs an automatic carriage return. The next print
position will be print position 1 of the next line.
Autowrap
This parameter determines if text will wrap to the next line when the line of text
exceeds the right margin.
Disable. Truncates the text beyond the right margin until a CR or CR +
LF is received.
Enable. Automatically inserts a CR + LF after a full print line.
Select SFCC
You can specify which hex code (1–255) will be used as the Special Function
Control Character (SFCC). The factory default setting is 126. The SFCC denotes
that the following data is a PGL command.
PI Slew Range
You can specify how many lines the paper will feed.
15. A paper slew of 1–15 will move 1–15 lines. A paper slew of 0 will
move 1 line.
16. A paper slew of 0–15 will move 1–16 lines.
Configuration Menus 4–21
