Reloading Paper

Follow this procedure when "LOAD PAPER" displays. (This message occurs
when the last sheet of paper passes through the paper slot.) This procedure
reloads paper without removing the last sheet of the old paper supply. This action
retains the current top of form setting.
1. Raise the printer cover. Raise the forms thickness lever as far as it will go.
Press CLEAR to turn off the alarm. Do not open the tractor doors or remove
the existing paper.
2. Open the cabinet front door. Align the paper supply with the label on the
floor. Ensure that the paper pulls freely from the box.
3–8
Thin Paper
Medium Paper
Thick Paper
Figure 3–1. Forms Thickness Lever
Operating the Printer
