6. Load the paper onto the sprockets and close the tractor door. Make sure the
leading edge of the first sheet of paper is parallel to the tractor splined shaft.
If the paper is misaligned, reload it onto the tractor sprockets until its edge is
parallel to the splined shaft.
7. Slide the right tractor to remove paper slack or to adjust for various paper
widths. Lock the tractor.
Horizontal
Adjustment
Knob
8. After both tractors are secured, you may use the horizontal adjustment knob
to make fine horizontal paper adjustments .
Setting Up the Printer
Splined Shaft
Paper Edge
Paper Scale
