About this task
The Fibre Channel adapter must go in PCI slot 2.
The following illustration shows the locations of the adapter expansion slots from
the rear of the file module.
Refer to "Installing a PCI adapter in a PCI riser-card assembly" on page 109 for
instructions.
Removing a 10-Gbps Ethernet PCI adapter
These instructions show the slot location for the 10-Gbps Ethernet PCI adapter.
About this task
The 10-Gbps Ethernet adapter is in PCI slot 4.
The following illustration shows the locations of the adapter expansion slots from
the rear of the file module.
Refer to "Removing a PCI adapter from a PCI riser-card assembly" on page 108 for
instructions.
Installing a 10-Gbps Ethernet PCI adapter
These installation instructions show the slot location for the 10-Gbps Ethernet PCI
adapter.
About this task
The 10-Gbps Ethernet adapter must go in PCI slot 4.
The following illustration shows the locations of the adapter expansion slots from
the rear of the file module.
112
Storwize V7000 Unified: Problem Determination Guide Version
