9
186
Pull mounting plate on posi-
tion 1 outwards and remove it
upwards.
Lift battery slightly out of
z
holder sufficiently for positive
terminal to be accessible.
Remove positive battery ca-
ble 1 and pull out battery.
Install battery
NOTICE
If the 12-V battery is inserted
incorrectly or the terminals re-
versed (e.g. when jump starting),
it can blow the fuse for the alter-
nator regulator.
Fasten positive battery cable 1.
Slide battery into holder.
First, insert mounting plate into
supports 1. Next, press it un-
der the battery at position 2.
