Clamping screw for
quick-release axle in
telescopic fork
14 lb/ft (19 Nm)
Tighten right-hand axle clamp-
ing screw 1 with appropriate
torque.
Clamping screw for
quick-release axle in
telescopic fork
14 lb/ft (19 Nm)
Remove front-wheel stand.
Slide the brake calipers on the
left-hand and right-had side
onto the brake rotors.
Install mounting bolts 4 on
left and right with appropriate
torque.
Radial brake calipers on
telescopic forks
28 lb/ft (38 Nm)
Remove adhesive tape from
wheel rim.
WARNING
Brake pads do not contact
the brake disc
Risk of accident due to delayed
braking effect.
Before driving off, check that
the braking effect kicks in with-
out any delay.
Engage the brakes repeatedly,
continuing until the brake pads
seat against the rotors.
Insert the wheel speed sensor
cable into the holding clips 1
and 2.
Insert the wheel speed sen-
sor into the bore and install
screw 3.
Wheel speed sensor on
fork
Joint compound: Micro-
encapsulated or medium-
strength screw lock
9
177
