POWER SYSTEMS
POWER SUPPLY SYSTEM
POWER SYSTEM LOCATION INDEX
Main fuse block
(See MAIN FUSE REMOVAL/INSTALLATION )
1
(See RELAY LOCATION )
(See RELAY INSPECTION )
Key reminder switch
2
(See KEY REMINDER SWITCH REMOVAL/INSTALLATION )
(See KEY REMINDER SWITCH INSPECTION )
Ignition switch
3
(See IGNITION SWITCH REMOVAL/INSTALLATION )
(See IGNITION SWITCH INSPECTION )
(w)
RX-8 Body
Page 383
