22
23
Not illuminated
*
The letters at the beginning of each DTC are only displayed when using the WDS or equivalent, and
refer to the following: B= Body system, P= Powertrain system, U= Network communication system.
PID/DATA MONITOR INSPECTION
1. Connect the WDS or equivalent to the DLC-2.
2. Display the PID/data monitor items.
Verify a displayed item according to the PID/data monitor table.
•
3. Disconnect the WDS or equivalent.
Communication error between
B2141 P1260 the keyless control module and
the PCM (data transfer error)
ID number data in the PCM and
B2139 P1260 the keyless control module do not
match.
Keyless control module
B1342 -
malfunction
SECURITY LIGHT:
22, DTC B2141/P1260
SECURITY LIGHT:
23, DTC B2139/P1260
DTC B1342
(KEYLESS CONTROL
MODULE)
(w) RX-8 Body
Page 358
