X'03D101' Invalid Order in Graphic Image
Explanation: A Begin Image order has been
executed in a segment, and an order other than a
Comment, Image Data, or End Image order is
executed.
Alternate Exception Action: None.
X'03D103' Image Width Greater Than Maximum
Supported
Explanation: The Width value specified in the
Begin
Image order exceeds the maximum image width
supported by the product.
Alternate Exception Action: The image width is
truncated at the maximum width supported.
X'03E100' Relative Line Outside Coordinate
Space
Explanation: The relative line starts inside the
drawing order coordinate space but goes outside.
Alternate Exception Action: None.

Specification Check-General - X'02'

The following exception codes are the valid codes for a general specification check condition:
X'020001' Embedded Text Control Code Error
Explanation: Undefined text control code.
Alternate Exception Action: Ignore the control
sequence.
X'020202' Invalid IPDS Command Length
Explanation: The length for a command is not
within the allowed range.
The length of a Request Resource List entry is not a
valid or supported value.
The length specified for a Request Resource List
entry does not match the number of bytes received.
Alternate Exception Action: None.
X'020302' IPDS Command Header Length too
Small
Explanation: The length value of a command is
less than 5 (or less than 7 if a correlation ID is
included).
Alternate Exception Action: None.
X'020401' End Page Encountered During Active
Suppression
The
Explanation:
encountered before a text suppression ended.
Alternate Exception Action: Process the object as
if the corresponding End Suppression control
sequence appeared at the end of the object. That is,
all of the data following the Begin Suppression
control sequence in the object is processed and
suppressed.
Chapter 6 IPDS Exception Reporting Codes
End Page control
X'03D102'
Supported
Explanation: The value specified for the
graphic image
supported.
Alternate Exception Action: None.
X'03D104'
Maximum Supported
Explanation: The Height value specified in the
Begin Image order exceeds the maximum
image height supported by the product.
Alternate Exception Action: The image height
is truncated at the maximum height supported.
X'020201' End Suppression Text Control
Error
Explanation: The active Begin Suppression ID
within the current page, overlay, or page
segment is not the same as that specified in the
ES control.
There is no active suppression ID.
X'020205' Invalid
Length
Explanation: A data structured field has been
received in a WGC or WBCC command that is
less than the minimum allowable length.
Alternate Exception Action: None.
X'020305' Area Position Orientation is Not
Supported
Explanation: The orientation specified in the
Area Position structured field of the WGC or
WBCC command is not a valid or supported
value.
Alternate Exception Action: None.
X'020402' Acknowledge Reply Response
Continuation Request is Invalid
was Explanation: The printer received a command
whose response continuation bit is on but there
is no response to continue.
Alternate Exception Action: None.
