The parameter bytes contain the specific characteristics for the drawing order. For information about the
parameters, see the specific drawing orders, following this description.
Code Drawing
00 No Operation
01 Comment
04 Reserved (Treated as a No-op)
08 Set Pattern Set
0A Set Color (Graphics)
0C Set Mix
0D Set Background Mix
11 Set Fractional Line Width
18 Set Line Type
19 Set Line Width
21 Set Current Position
22 Set Arc Parameters
26 Set Extended Color
28 Set Pattern Symbol
29 Set Marker Symbol
85 Fillet at Current Position
87 Full Arc at Current Position
91 Image at Current Position
92 Image Data
93 End Image
A1 Relative at Current Position
The following sections describe the drawing orders.

No Operation

00
Description: This order is a no-operation; it has no effect on the graphic medium presentation space or
any attribute or any current parameter.

Comment

01
Description: This order is a no-operation; it has no effect on the graphic medium presentation space or
any attribute or any current parameter. This order can appear anywhere within the segment.
L1 is the length byte. This byte is a value between 1 and 255 and specifies the number of data bytes that
follow. Parameters P1 to Pn are the data bytes. The printer ignores the data within the order. However,
there must be at least one data byte within this order.
Chapter 5 IPDS Programming Information
L1 P1..Pn
Code Drawing
33 Set Character Cell Size
34 Set Character Angle
38 Set Character Set
39 Set Character Precision
3A Set Character Direction
3B Set Marker Precision
3C Set Marker Set
3E End Prologue
43 Reserved (Treated as a No-op)
60 End Area
68 Begin Area
71 End Segment (Treated as a No-op)
81 Line at Current Position
82 Marker at Current Position
83 Character String at Current Position
C1 Line
C2 Marker
C3 Character String
C5 Fillet
C7 Full Arc
D1 Begin Image
E1 Relative Line
