The following bytes contain the print quality selection, as shown:
Byte Value
Bit 0-1 F800
Bit 2 01 - 2A
2B - 55
56 - AA
AB - FE
FF
Note: S828 only with Host Fast Draft enabled.
For printing multiple-density selections of graphics and bar codes, the following values are valid if bar
code/graphics density is set to computer selected:
Byte Value
Bit 0-1 F800
Bit 2 01 - 55
56 - FE
FF
Notes:
1. A PQC command can result in a font change in order to provide the desired quality level.
2. The printer changes fonts to satisfy quality selections for all supported code pages except OCR (340),
OCR-A (892), or OCR-B (893). It will not change the selected code page to provide a requested quality.

Text Function Set Commands

The text function set contains the commands and data controls for presenting text information on a logical
page, page segment, or overlay area on the physical medium. The following commands are the text
function set:
The following pages describe the text function set commands.
Load Equivalence (LE)
Length D61D
This command permits Begin and End suppression controls imbedded in data stored within the printer to
reference different external values. For example, internal suppression values of 06, 07, and 09 (from a
Begin Suppression control) can map to an external value of 02 from a Load Copy Control command, if the
printer previously has received an appropriate Load Equivalence command. Thus, the printer can use a
single Load Copy Control suppression pair for more than one suppression value (see "Begin Suppression
(BSU)").
Chapter 5 IPDS Programming Information
Description
PQC Order Code
Fast Draft Quality
DP
DP Text
NLQ
Depends on Operator Panel setting
Description
PQC Order Code
Low-Density Graphics/Bar Codes
High-Density Graphics/High-Contrast Bar Codes
Depends on Operator Panel setting
Flag Correlation ID (Optional) Data
