System Indicators and Status

The CX5500 unified conference station's indicator lights let you know whether the unified conference station
is sending, receiving, or holding audio or video calls. The three microphone indicator lights are located on the
three ends of the unified conference station's base, and the active video indicator light is located on the
underside of the camera head. See the figure
of the microphone and active video indicators. The following tables describe the microphone and active video
indicator lights used on the CX5500 unified conference station.
Microphone Indicators and System Status
Microphone
Indicator
Off
Green
Flashing green
Slowly flashing green
Red
Flashing red
Flashing green and
red
Active Video Indicator and System Status
Active Video
Indicator
Off
Green
Flashing green
Polycom, Inc.
Speaker
Mute buttons and status indicators
USB 3.0 Type B port
USB 2.0 port
Touchscreen
CX5500 unified conference station hardware
System Status
Not in a call
In a call
Incoming call
System is starting up
In a call with microphones muted
Incoming call with microphones muted; call on hold
Software update in progress
System Status
Not in a call; no video in the call
In a call with active video
Privacy cap is closed
for the location
