Lens Options for Models 'M/C1930'

• The following figure shows the lens image circles relative to Genie Nano models using the
OnSemi Python2000 sensor.
• A typical 2/3" lens will fully illuminate these sensors.
Lens Options for Models 'M/C1280' & 'M/C1240'
The following figure shows the lens image circles relative to Genie Nano models using the
•
OnSemi Python1300 sensor.
A typical ½" lens will fully illuminate these sensors.
•
•
240 Additional Reference Information
1" Lens (~16mm)
Image Circle
2/3" Lens (~11mm)
Image Circle
1" Lens (~16mm)
Image Circle
1/2" Lens (~8mm)
Image Circle
2/3" Lens (~11mm)
Image Circle
