Intel ® Server System R1000WT Product Family System Integration and Service Guide
Instruction Format
Each procedure described in this chapter will follow an illustration first format. This format will give the reader the
option to follow a quicker path to system integration by first seeing an illustration of the intended procedure. If
necessary, the reader can then follow the step-by-step instructions that will accompany each procedure.
System Integration Advisory Note
It is highly recommended that the system integration process defined in the following sections within this
chapter be performed in the order specified. Following these instructions will result in the proper
installation of critical system components and provide recommended cable routing. Deviating from the
prescribed process may result in improper system assembly, a longer integration process, and a less than
desired system appearance.
2 Rev 2.2
