- Page 1 Intel® Server System R1000SPO Product Family Technical Product Specification A document providing an overview of product features, functions, architecture, and support specifications Revision 1.0 March 2016 ® Intel Server Boards and Systems...
- Page 2 Intel® Server System R1000SPO Product Family TPS Revision History Date Revision Number Modifications January 2016 0.7 First preliminary version First External Public Release Changes: Updated Illustrations Appendix E - Added High Temperature Ambient Information Section 3.3.4 - Added Holdup time for Fixed Power Supply March 2016 1.0...
- Page 3 This document contains information on products, services and/or processes in development. All information provided here is subject to change without notice. Contact your Intel representative to obtain the latest TPS. The products and services described may contain defects or errors known as errata which may cause deviations from published specifications.
-
Page 4: Table Of Contents
Intel® Server System R1000SPO Product Family TPS Table of Contents 1. Introduction ............................1 Chapter Outline ............................ 1 Server Board Use Disclaimer ......................2 Product Errata ............................2 2. Product Family Overview ........................ 3 Operating System Support....................... 5 OS Validation Levels .......................... 5 2.1.1... - Page 5 Intel® Server System R1000SPO Product Family TPS Power Recovery ..........................25 3.3.11 Voltage Interruptions ........................25 3.3.12 Protection Circuits ..........................25 3.3.13 Power Supply Status LED ......................27 3.3.14 Server Board Power Connectors....................27 4. Thermal Management ........................29 Thermal Operation and Configuration Requirements ............30 Thermal Management Overview ....................
- Page 6 Intel® Server System R1000SPO Product Family TPS Appendix B: POST Code Diagnostic LED Decoder ..............62 Appendix C: POST Code Errors ......................72 Appendix D: System Cable Routing Diagrams ................76 Appendix E: High Temperature Ambient Info ................77 Glossary ..............................79...
- Page 7 Figure 36. 8 x 2.5” Drive SAS/SATA Backplane – front view ..............42 Figure 37. 8 x 2.5” Drive SAS/SATA Backplane – rear view ............... 42 Figure 38. Installing M.2 Device ..........................43 Figure 39. Intel® Raid Upgrade Key ........................46 Figure 40. Intel ®...
- Page 8 Figure 42. Front Panel LEDs and Buttons ......................48 Figure 43. Add-in Card Support ..........................51 Figure 44. Riser Card Assembly..........................51 Figure 45. Intel® I/O Module Placement ......................52 Figure 46. Intel ® RMM4 Lite Activation Key Installation ................55 Figure 47.
- Page 9 Table 4. Operating System Validation Levels ....................5 Table 5. System Environmental Limits Summary ..................17 Table 6. Intel Product Weight Information ....................... 18 Table 7. 350 Watt AC Power Supply Efficiency (Gold) ................20 Table 8. 450 Watt AC Power Supply Efficiency (Gold) ................20 Table 9.
- Page 10 Intel® Server System R1000SPO Product Family TPS Table 39. POST Progress Codes ........................... 63 Table 40. MRC Progress Codes ..........................69 Table 41. POST Progress LED Codes ........................70 Table 42. POST Error Codes and Messages..................... 72 Table 43. POST Error Beep Codes ........................74...
-
Page 12: Introduction
Note that some system features are provided as configurable options and may not be included standard in every system configuration offered. Please reference the Intel ®... -
Page 13: Server Board Use Disclaimer
Intel® Server System R1000SPO Product Family TPS Server Board Use Disclaimer Intel Corporation server boards support add-in peripherals and contain a number of high-density VLSI and power delivery components that need adequate airflow to cool. Intel ensures through its own chassis development and testing that when Intel®... -
Page 14: Product Family Overview
One 2x10 pin connector providing front panel support for two USB 2.0 / 3.0 ports The server board includes a proprietary on-board connector allowing for the installation of a variety of available Intel® I/O modules. An installed I/O module can be supported in addition to standard on-board features and add-in PCIe* cards. - Page 15 Support for Intel® Server Management Software Server Management On-board RJ45 management port Advanced Server Management via an Intel® Remote Management Module 4 Lite (Accessory Option) The server system supports two options for Power Supply: Power Supply Options...
-
Page 16: Operating System Support
Intel® Server System R1000SPO Product Family TPS Operating System Support As of this writing, the Intel® Server System R1000SPO product family provides support for the following operating systems. This list will be updated as new operating systems are validated by Intel. -
Page 17: System Features Overview
T2: Intel will provide and test operating system drivers for each of the server board’s integrated controllers, provided that the controller vendor has a driver available upon request. Vendors will not be required by Intel to develop drivers for operating systems that they do not already support. Intel will NOT provide support for issues related to the use of any add-in adapters or peripherals installed in the server system when an operating system that received only basic installation testing is in use. -
Page 18: Figure 2. Top Cover Features
Intel® Server System R1000SPO Product Family TPS Figure 2. Top Cover Features... -
Page 19: Server Board Features Overview
Intel® Server System R1000SPO Product Family TPS Server Board Features Overview The following illustration provides a general overview of the server board, identifying key feature and component locations. Please refer to Intel ® Server Board S1200SP Technical Product Specification for more information. -
Page 20: Figure 4. On-Board Diagnostic Leds
Intel® Server System R1000SPO Product Family TPS The server board includes several LEDs to identify system status. The following illustrations define supported LEDs and identify their location. Figure 4. On-board Diagnostic LEDs... -
Page 21: Back Panel Features
Intel® Server System R1000SPO Product Family TPS Figure 5. System Reset and Configuration Jumpers Back Panel Features Figure 6. Back Panel Features... -
Page 22: Front Control Panel
Intel® Server System R1000SPO Product Family TPS Front Control Panel Label Description System ID Button w/Integrated LED NMI Button (recessed, tool required for use) NIC 1 & 2 Activity LEDs System Cold Reset Button (recessed, tool required for use) System Status LED... -
Page 23: Locking Front Bezel
Intel® Server System R1000SPO Product Family TPS Locking Front Bezel The optional front bezel is made of Black molded plastic and uses a snap-on design. When installed, its design allows for maximum airflow to maintain system cooling requirements. The front bezel includes a keyed locking mechanism which can be used to prevent unauthorized access to installed storage devices and front I/O ports. -
Page 24: Figure 12. Front Bezel Accessory With Optionally Installed Wave And Id Badge (1)
Intel® Server System R1000SPO Product Family TPS Figure 12. Front Bezel Accessory with Optionally Installed Wave and ID Badge (1) Figure 13. Front Bezel Accessory with Optionally Installed Wave and ID Badge (2) Figure 14. Front Bezel Accessory ID Badge Mechanical Drawings... -
Page 25: System Dimensions
Intel® Server System R1000SPO Product Family TPS System Dimensions 2.8.1 Chassis Dimensions 1.7” 43.2mm Figure 15. Chassis Dimensions... -
Page 26: Label Emboss Dimensions
Intel® Server System R1000SPO Product Family TPS Label Emboss Dimensions 2.8.2 Figure 16. Label Emboss Dimensions... -
Page 27: Available Rack Mounting Kit Options
Advisory Note – Available rack and cabinet mounting kits are not designed to support shipment of the server system while installed in a rack. If you chose to do so, Intel advises you verify your shipping configuration with appropriate shock and vibration testing, before shipment. Intel does not perform shipping tests which cover the complex combination of unique rack offerings and custom packaging options. -
Page 28: 2.10 System Level Environmental Limits
Intel® Server System R1000SPO Product Family TPS 2.10 System Level Environmental Limits The following table defines the system level operating and non-operating environmental limits. Table 5. System Environmental Limits Summary Parameter Limits ASHRAE Class A2 – Continuous Operation. 10º C to 35º C (50º F to 95º F) with the maximum rate of change not to exceed 10°C per hour... -
Page 29: 2.11 System Packaging
Intel® Server System R1000SPO Product Family TPS 2.11 System Packaging The original Intel packaging, in which the server system is delivered, is designed to provide protection to a fully configured system and was tested to meet ISTA (International Safe Transit Association) Test Procedure 3A (2008). -
Page 30: System Power
Intel® Server System R1000SPO Product Family TPS System Power This chapter provides a high level overview of the features and functions related to system power. Power Supply Configurations Systems within this product family are offered with options to support a single fixed mount 350 watt power supply or dual 450 watt power supply modules. -
Page 31: Power Supply Module Options
Intel® Server System R1000SPO Product Family TPS Power Supply Module Options There are two power supply options available for this server product family: 350W AC (fixed mount) and 450W AC (Module). 3.2.1 Power Supply Module Efficiency The following tables provide the required minimum efficiency level at various loading conditions. These are provided at three different load levels: 100%, 50%, and 20%. -
Page 32: Power Distribution Board
Backplane and Optical Disk Drive, come from the Power Distribution Board. For connector pinout and power supply monitoring details, please refer to the Intel® Server Board S1200SP Product Family Technical Product Specification. The PDB is designed to plug directly to the output connector of the power supply and it contains two DC/DC power converters to produce other required voltages. -
Page 33: Ac Power Supply Input Specifications
Intel® Server System R1000SPO Product Family TPS 3.2.4 Power Cord Specification Requirements The AC power cord used must meet the specification requirements listed in the following table. Table 9. AC Power Cord Specifications Cable Type Wire Size 16 AWG Temperature Rating 105ºC... -
Page 34: Ac Input Voltage Specification
Intel® Server System R1000SPO Product Family TPS 3.3.2 AC Input Voltage Specification The power supply must operate within all specified limits over the following input voltage range. Harmonic distortion of up to 10% of the rated line voltage must not cause the power supply to go out of specified limits. -
Page 35: Ac Line Fuse
Intel® Server System R1000SPO Product Family TPS Table 13. AC Line Holdup Time – 450W Power Supply Loading Holdup time 12msec 100% 10msec 3.3.5 AC Line Fuse The power supply shall have one line fused in the single line fuse on the line (Hot) wire of the AC input. The line fusing shall be acceptable for all safety agency requirements. -
Page 36: Susceptibility Requirements
The power supply shall meet the following electrical immunity requirements when connected to a cage with an external EMI filter which meets the criteria defined in the SSI document EPS Power Supply Specification. For further information on Intel standards please request a copy of the Intel Environmental Standards Handbook. -
Page 37: Table 19. Over Current Protection - 350W Power Supply
Intel® Server System R1000SPO Product Family TPS 3.3.13.1 Over-current Protection (OCP) The power supply shall have current limit to prevent the outputs from exceeding the values shown in table below. If the current limits are exceeded the power supply shall shutdown and latch off. The latch will be cleared by toggling the PSON signal or by an AC power interruption. -
Page 38: Power Supply Status Led
Intel® Server System R1000SPO Product Family TPS Table 22. Over Voltage Protection (OVP) Limits – 750W Power Supply OUTPUT VOLTAGE PROTECTION POINT [ V] +12 V 13.6V ~ 15.0V 5VSB 5.6V ~ 6.5V 3.3.13.3 Over-temperature Protection (OTP) The power supply will be protected against over temperature conditions caused by loss of fan cooling or excessive ambient temperature. -
Page 39: Table 24. Main Power Connector Pin-Out
Intel® Server System R1000SPO Product Family TPS The following tables define the pin-out for the connectors: Table 24. Main Power Connector Pin-out Signal Name Pin Signal Name +3.3V +3.3V +3.3V -12V (NA for most designs) PS_ON# PWR_GD SB5V +12V +12V +3.3V... -
Page 40: Thermal Management
Intel® Server System R1000SPO Product Family TPS Thermal Management The fully integrated system is designed to operate at external ambient temperatures of between 10°C and 35°C. Working with integrated platform management, several features within the system are designed to move air in a front to back direction, through the system and over critical components to prevent them from overheating and allow the system to operate with best performance. -
Page 41: Thermal Operation And Configuration Requirements
Intel® Server System R1000SPO Product Family TPS The Intel ® Server System R1000SPO product family is thermally designed and developed in compliance with ASHRAE Class A2 environment guidance; however, there is extra thermal margin for all components in the system, so ASHRAE Class A3 environment conditions can be thermally supported. -
Page 42: Programmable Fan Pwm Offset
This enables easier usage of the fan speed control to support Intel as well as third party chassis and better support of ambient temperatures higher than 35°C. -
Page 43: Nominal Fan Speed
Intel® Server System R1000SPO Product Family TPS 4.2.4 Nominal Fan Speed A fan domain’s nominal fan speed can be configured as static (fixed value) or controlled by the state of one or more associated temperature sensors. OEM SDR records are used to configure which temperature sensors are associated with which fan control domains and the algorithmic relationship between the temperature and fan speed. -
Page 44: Figure 25. Fan Control Model
Intel® Server System R1000SPO Product Family TPS Hot Swap Backplane Temperature Sensors I/O Module Temperature Sensor (With option installed) Intel ® SAS Module (With option installed) Notes: For fan speed control in Intel chassis Temperature margin from throttling threshold... -
Page 45: System Fans
Intel® Server System R1000SPO Product Family TPS System Fans Three single rotor 40 x 56mm system fans, and dedicated fans for the installed power supply modules provide the primary airflow for the system. The system includes three system fans (see Figure 26). The fans are held in place by fitting them over mounting pins coming up from the chassis base. -
Page 46: Figure 27. System Fan Connector Locations On Server Board
Intel® Server System R1000SPO Product Family TPS Figure 27. System Fan Connector Locations on Server Board Table 28. System Fan Connector Pin-out Signal Name Type Description Ground Ground is the power supply ground Power Power supply 12 V Fan Tach Fan... -
Page 47: System Storage And Peripheral Drive Bay Overview
Intel publishes a list of supported hard drives on its Tested Hardware and OS List (THOL). In general, unless identified in the NOTES column in the THOL, all listed hard drives have been tested to meet Intel performance targets when the systems fans are operating above 80% PWM and/or the system is operating at or below the platform ambient thermal limit of 35°C (95°F). -
Page 48: Hot Swap Drive Carriers
Intel® Server System R1000SPO Product Family TPS Intel recommends the following general support guidelines for server systems configured with hard drive storage technology: Avoid sustained server operation in extreme operating environments. Doing so will cause the system fans to operate at their upper speed limits and produce higher levels of RVI which could affect hard drive performance. -
Page 49: Figure 31. 2.5" Ssd Mounted To 3.5" Drive Tray
Intel® Server System R1000SPO Product Family TPS Figure 31. 2.5" SSD mounted to 3.5" Drive Tray NOTE: Due to degraded performance and reliability concerns, the use of the 3.5” drive blank as a 2.5” device bracket is intended to support SSD type storage devices only. Installing a 2.5” hard disk drive into the 3.5”... -
Page 50: Storage Backplane Options
Intel® Server System R1000SPO Product Family TPS Table 29. Drive Status LED States No access and no fault Amber Solid On Hard Drive Fault has occurred Blink RAID rebuild in progress (1 Hz), Identify (2 Hz) Table 30. Drive Activity LED States... -
Page 51: I2C Functionality
Intel® Server System R1000SPO Product Family TPS Figure 33. Backplane Installation NOTE: For details on the istallation/removal of the Backplane, please refer to the Intel® Server System R1000SPO Product Family System Integration and Service Guide. All available SAS/SATA compatible backplanes include the following common features: 12 Gb SAS and 6Gb SAS/SATA ... -
Page 52: Figure 34. 4 X 3.5" Drive Hot-Swap Backplane - Front View
Intel® Server System R1000SPO Product Family TPS The front side of the backplane includes 4 x 29-pin drive interface connectors, each capable of supporting 12 Gb SAS or 6 Gb SAS/SATA. The connectors are numbered 0 thru 3. Signals for all four drive connectors are routed to a single multi-port mini-SAS HD connector on the back side of the backplane. -
Page 53: X 2.5" Drive Sas Backplane
Intel® Server System R1000SPO Product Family TPS 5.4.3 8 x 2.5” Drive SAS Backplane Intel Spare Product Code: F1U8X25S3HSBP The 2.5” drive system SKU will ship with a 8x drive backplane capable of supporting 12 Gb/sec SAS and 6 Gb/sec SAS / SATA drives. Both hard disks and Solid State Devices (SSDs) can be supported within a common backplane. -
Page 54: M.2 Ssd Support
Intel® Server System R1000SPO Product Family TPS A – Power Connector – The backplane includes a 2x2 connector supplying power to the backplane. Power is routed to the backplane via a power cable harness from the Power Supply Modules. SIGNAL... -
Page 55: Sata Dom Support
Intel® Server System R1000SPO Product Family TPS SATA DOM Support The SATA-4 connector on the server board is designed to be compatible with SATADOM devices. Table 31. SATA/SATADOM capable Connector Pin-out Signal Name SATA_TX_P SATA_TX_N SATA_RX_N SATA_RX_P P5V (For Apacer* SATADOM) -
Page 56: Storage Controller Options Overview
DMA operation on up to eight ports and supports data transfer rates of up to 6.0 Gb/s (600 MB/s). The SATA controller contains two modes of operation – a legacy mode using I/O space, and an AHCI mode using memory space. Software that uses legacy mode will not have AHCI capabilities. The Intel ®... -
Page 57: Figure 39. Intel® Raid Upgrade Key
® C230 series chipset. 6.1.1.2 Intel ® Embedded Server RAID Technology 2 (ESRT2) Features of the embedded software RAID option Intel ® Embedded Server RAID Technology 2 (ESRT2) include the following: Based on LSI* MegaRAID* Software Stack Software RAID with system providing memory and CPU utilization ... -
Page 58: Intel Integrated Raid Module Support
RAID Maintenance Free Backup Units (AXXRMFBU5) NOTE: RAID configurations cannot span across the embedded and add-in AHCI SATA controllers. For supported SAS modules, refer to the document Intel® Server Boards S1200SP Configuration Guide and Spares/Accessories List 6.2.1 Intel ®... -
Page 59: Front Control Panel And I/O Panel Overview
Intel® Server System R1000SPO Product Family TPS Front Control Panel and I/O Panel Overview All system configurations include a Control Panel and I/O Panel on the front of the system. I/O Panel Features USB 2.0/3.0** Ports Figure 41. Front I/O Panel Features USB 2.0/3.0 Ports –The front I/O panel includes two USB 2.0/3.0 ports. -
Page 60: Table 33. System Status Led Indicator States
Intel® Server System R1000SPO Product Family TPS 7.2.1 System Status LED NOTE: The Status LED is controlled by the BMC but the BIOS informs the BMC of the state to which the Status LED should be set. The System Status LED has specific states that are described in the following table but the actual state of the Status LED is indicative of one or more of the conditions listed. -
Page 61: Table 34. Front Panel Led Indication Of Bmc State
Intel® Server System R1000SPO Product Family TPS When AC power is first applied to the system, the status LED turns solid amber and then immediately changes to green blinking to indicate that the BMC is booting. Upon completing the BMC boot, the status LED will be solid green if there are no errors/abnormal conditions in the system. -
Page 62: Pcie* Riser Card Support
Intel® Server System R1000SPO Product Family TPS PCIe* Riser Card Support The system includes a riser card slot on the server board. This section will provide an overview and description of the server board features and architecture supporting it. NOTE: The riser card slot is specifically designed to support riser cards only. Attempting to install a PCIe* add-in card directly into a riser card slot on the server board may damage the server board, the add-in card, or both. -
Page 63: Intel® I/O Module Support
To broaden the standard on-board feature set, the server board provides support for one of several available Intel® I/O Module options. The I/O module attaches to a high density 80-pin connector on the server board (labeled “IO_Module”) and is supported by x8 PCIe Gen3 signals from the IIO module of the CPU 1 processor. -
Page 64: 10. Basic And Advanced Server Management Features
Intel ® Remote Management Module 4 Lite RMM4 Lite Activation Key Enables KVM & media redirection When the BMC FW initializes, it attempts to access the Intel ® RMM4 lite. If the attempt to access Intel ® RMM4 lite is successful, then the BMC activates the Advanced features. -
Page 65: 10.1 Ipmi 2.0 Features
Intel® Server System R1000SPO Product Family TPS 10.1 IPMI 2.0 Features Baseboard management controller (BMC) IPMI Watchdog timer Messaging support, including command bridging and user/session support Chassis device functionality, including power/reset control and BIOS boot flags support ... -
Page 66: Dedicated Management Port
Intel® Server System R1000SPO Product Family TPS Front panel management: The BMC controls the system status LED and chassis ID LED. It supports secure lockout of certain front panel functionality and monitors button presses. The chassis ID LED is turned on using a front panel button or a command. - Page 67 Intel® Server System R1000SPO Product Family TPS have management connectivity to the BMC as well as an optional dedicated add-in management NIC. At least two concurrent web sessions from up to two different users is supported. The embedded web user interface shall support the following client web browsers: Microsoft Internet Explorer 9.0*...
-
Page 68: Advanced Management Feature Support (Rmm4 Lite)
Keyboard, Video, Mouse (KVM) Redirection The BMC firmware supports keyboard, video, and mouse redirection (KVM) over LAN. This feature is available remotely from the embedded web server as a Java applet. This feature is only enabled when the Intel ®... - Page 69 Intel® Server System R1000SPO Product Family TPS lite is present. The client system must have a Java Runtime Environment (JRE) version 6.0 or later to run the KVM or media redirection applets. The BMC supports an embedded KVM application (Remote Console) that can be launched from the embedded web server from a remote console.
- Page 70 Intel® Server System R1000SPO Product Family TPS connections to be made, that is, the firewall and, in case of a private internal network, the NAT (Network Address Translation) settings have to be configured accordingly. 10.2.3.3 Performance The remote display accurately represents the local display. The feature adapts to changes to the video resolution of the local display and continues to work smoothly when the system transitions from graphics to text or vice-versa.
- Page 71 Intel® Server System R1000SPO Product Family TPS The following capabilities are supported: The operation of remotely mounted devices is independent of the local devices on the server. Both remote and local devices are useable in parallel. Either IDE (CD-ROM, floppy) or USB devices can be mounted as a remote device to the server.
-
Page 72: Appendix A: Integration And Usage Tips
Intel® Server System R1000SPO Product Family TPS Appendix A: Integration and Usage Tips This section provides a list of useful information that is unique to the Intel ® Server System R1000SPO Product Family and should be kept in mind while configuring your server system. -
Page 73: Appendix B: Post Code Diagnostic Led Decoder
Intel® Server System R1000SPO Product Family TPS Appendix B: POST Code Diagnostic LED Decoder As an aid to assist in trouble shooting a system hang that occurs during a system’s Power-On Self-est (POST) process, the server board includes a bank of eight (2 rows of 4) POST Code Diagnostic LEDs on the back edge of the server board. -
Page 74: Table 38. Post Progress Code Led Example
Intel® Server System R1000SPO Product Family TPS Table 38. POST Progress Code LED Example LED #3 LED #2 LED #1 LED #0 8h (MSB) 1h (LSB) Upper Nibble: Ah Status Lower Nibble: Ch 8h (MSB) 1h (LSB) POST CODE: ACh... - Page 75 Intel® Server System R1000SPO Product Family TPS Diagnostic LED Decoder LED 3 LED 2 LED 1 LED 0 LED # Upper Nibble 8h (MSB) 1h (LSB) Description Checkpoint Lower Nibble 8h (MSB) 1h (LSB) Upper Nibble End Of Sec Phase.
- Page 76 Intel® Server System R1000SPO Product Family TPS Diagnostic LED Decoder LED 3 LED 2 LED 1 LED 0 LED # Upper Nibble 8h (MSB) 1h (LSB) Description Checkpoint Lower Nibble 8h (MSB) 1h (LSB) Upper Nibble DXE CPU Init Lower Nibble...
- Page 77 Intel® Server System R1000SPO Product Family TPS Diagnostic LED Decoder LED 3 LED 2 LED 1 LED 0 LED # Upper Nibble 8h (MSB) 1h (LSB) Description Checkpoint Lower Nibble 8h (MSB) 1h (LSB) Upper Nibble DXE PCI Bus resource requested...
- Page 78 Intel® Server System R1000SPO Product Family TPS Diagnostic LED Decoder LED 3 LED 2 LED 1 LED 0 LED # Upper Nibble 8h (MSB) 1h (LSB) Description Checkpoint Lower Nibble 8h (MSB) 1h (LSB) Upper Nibble DXE SCSI enable Lower Nibble...
- Page 79 Intel® Server System R1000SPO Product Family TPS Diagnostic LED Decoder LED 3 LED 2 LED 1 LED 0 LED # Upper Nibble 8h (MSB) 1h (LSB) Description Checkpoint Lower Nibble 8h (MSB) 1h (LSB) S3 Resume Upper Nibble S3 Resume PEIM (S3 started)
-
Page 80: Table 40. Mrc Progress Codes
Intel® Server System R1000SPO Product Family TPS Table 40. MRC Progress Codes Diagnostic LED Decoder LED # LED 3 LED 2 LED 1 LED 0 Upper Nibble 8h (MSB) 1h (LSB) Description Checkpoint Lower Nibble 8h (MSB) 1h (LSB) MRC Progress Codes... -
Page 81: Table 41. Post Progress Led Codes
Lower disabled due to hardware mem-test error. Nibble 3h = No memory installed. All channels are disabled. Upper Nibble Memory is locked by Intel® Trusted Execution Technology and is inaccessible Lower Nibble DDR4 channel training error Upper 01h = Error on read DQ/DQS (Data/Data Strobe) init... - Page 82 Intel® Server System R1000SPO Product Family TPS Diagnostic LED Decoder LED # LED 3 LED 2 LED 1 LED 0 Upper Description Nibble (MSB) (LSB) Checkp oint Lower Nibble (MSB) (LSB) DIMM configuration population error Upper 01h = Different DIMM types (UDIMM, RDIMM, LRDIMM) are Nibble detected installed in the system.
-
Page 83: Appendix C: Post Code Errors
The user needs to replace the faulty part and restart the system. NOTE: The POST error codes in the following table are common to all current generation Intel server platforms. Features present on a given server board/system will determine which of the listed error codes are supported Table 42. - Page 84 Intel® Server System R1000SPO Product Family TPS Error Code Error Message Response 0195 Processor Intel(R) QPI link frequencies unable to synchronize Fatal 0196 Processor model mismatch detected Fatal 0197 Processor frequencies unable to synchronize Fatal 5220 BIOS Settings reset to default settings...
-
Page 85: Table 43. Post Error Beep Codes
Intel® Server System R1000SPO Product Family TPS Error Code Error Message Response 92A3 Serial port component was not detected Major 92A9 Serial port component encountered a resource conflict error Major A000 TPM device not detected. Minor A001 TPM device missing or not responding. -
Page 86: Table 44. Integrated Bmc Beep Codes
Codes that are common across all Intel server boards and systems that use same generation chipset are listed in the following table. Each digit in the code is represented by a sequence of beeps whose count is equal to the digit. -
Page 87: Appendix D: System Cable Routing Diagrams
Intel® Server System R1000SPO Product Family TPS Appendix D: System Cable Routing Diagrams Figure 48. Internal Cable Routing... -
Page 88: Appendix E: High Temperature Ambient Info
55°C local ambient temperature and 300LFM. 8. The Intel® RAID Maintenance Free Backup Unit (AXXRMFBUx) can support a case temperature of up to 45°C with the system operating in normal mode and up to 55°C with the system operating in a fan fail mode. - Page 89 Intel® Server System R1000SPO Product Family TPS Thermal Configuration Table "●" = Full Support without limitation "4.5" (Cell with number) = Conditional support with limitation " " (Blank) = Not supported ASHRAE Classifications 27°C (See Note 1) Maximum Ambient Temperature 27°C(1)
-
Page 90: Glossary
Intel® Server System R1000SPO Product Family TPS Glossary Acronym Definition Technical Product Specification Non-Disclosure Agreement Input/Output VLSI Very Large Scale Integration Thermal Design Power Platform Hub Controller Direct Media Interface PCIe* Peripheral Component Interconnect Express* SFP+ Enhanced Small Form-Factor Pluggable... - Page 91 Intel® Server System R1000SPO Product Family TPS Acronym Definition PMBUS Power Management Bus SATADOM SATA Disk On a Module Rotational Vibration Interference THOL Tested Hardware and operating list HSBP Hot-Swap Backplane AHCI Advanced Host Controller Interface ESRT2 Embedded Server RAID Technology 2...
- Page 92 Intel® Server System R1000SPO Product Family TPS...
- Page 93 Intel® Server System R1000SPO Product Family TPS NOTES __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________...
