Administrator's Guide for ViewStation EX, ViewStation FX, and VS4000

Power Supply

2-8
The ViewStation EX and ViewStation FX set-top systems have an external power
supply.
To connect the power supply
Connect the power supply to the power connector on the back of the system.
1.
2. Connect the power cord to the power supply.
ViewStation EX
2
3.3V 7A
12V 3A
XVGA
4
2
Power
Leave the power cord unplugged until you have connected all standard and optional
equipment to the system.
Be sure to remove the packaging collar from around the ViewStation EX or ViewStation FX
system's camera before powering on the system.
Do not use any power supply other than the one supplied with your ViewStation EX or
ViewStation FX system. Using the wrong power supply will void the warranty and may
damage your system.
0101
1
ViewStation FX
4
3
#
$%$& ('
"#& $'
1
XVGA
4
2
Power
