H o w t o a d d a n e w
H o w t o a d d a n e w
1. Click Add.
2. The settings are listed as below:
Available parameters are listed as follows:
Item
Profile
WAN Profile
LAN
VLAN/Member
Apply
Cancel
3. Enter all of the settings and click Apply. The new profile will be shown as below.
b r i d g e V L A N p r o f
b r i d g e V L A N p r o f
Description
Type the name of the profile.
Use the drop down list to choose the WAN interface.
Choose a VLAN profile from the drop down list.
You have to open LAN>>Switch page and click 802.1Q
VLAN for creating VLAN ID number bound with LAN port
(802.1Q VLAN profile) first. Otherwise, no profiles will be
displayed here for you to specify.
Click it to save and exit the dialog.
Click it to exit the dialog without saving anything.
80
i l e
i l e
