Draytek Vigor2960 Series User Manual page 127

H H o o w w t t o o
1. Open LAN>>LAN DNS.
2. Click the Add button.
3. The following dialog will appear.
Available parameters are listed as follows:
Item
Profile
Status
Domain Name
CNAME (Alias
Domain Name)
IP Address
IPv6 Address
4. Enter all of the settings and click Apply. The new profile will be added on the screen.
Vigor2960 Series User's Guide
a a d d d d a a n n e e w w L L A A N N D D N N
Description
Type a name for such profile.
Check the box to enable such profile.
Type the domain name for such profile.
Type several domain names in this field. LAN DNS will
redirect both Domain name and CNAME to an assigned IP.
For example, Domain Name is set with "www.draytek.com",
and the CNAME is set as "www.dray.com". If the IP address
is set with "192.168.1.123", then both "www.draytek.com"
and "www.dray.com" will be directed to "192.168.1.123".
The IP address will be used for mapping with the domain
name specified above.
The IPv6 address will be used for mapping with the domain
name specified above.
S S p p r r o o f f i i l l e e
119
