The following page is used to create Active-Standby profiles.
Available parameters are listed as follows:
Item
Add
Edit
Delete
Refresh
Auto Refresh
Profile Number Limit
Profile
HA LAN Profile
Virtual IP for
Gateway
VHID
Role
HA Status
Description
Add a new HA profile.
Modify the selected HA profile.
To edit the profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for you
to modify the corresponding settings for the selected profile.
Remove the selected HA profile.
To delete a profile, simply select the one you want to delete and
click the Delete button.
Renew current web page.
Specify the interval of refresh time to obtain the latest status.
The information will update immediately when the Refresh
button is clicked.
Display the total number (4) of the object profiles to be created.
Display the name of the HA profile.
Display the LAN profile used by such HA.
Display the IP address of the gateway.
Display the virtual host ID number of the profile.
Display the role of this profile in the corresponding HA group.
Display the online status (Master, Backup, LAN_failed and
WAN_Failed) of such HA profile.
