H o w t o c r e a t e a P
H o w t o c r e a t e a P
Below will guide you to create a PPTP dial-in profile for VPN connection:
1. Open VPN and Remote Access >> VPN Profiles.
2. Simply click the Add button.
3. The following dialog will appear.
Available parameters are listed as follows:
Item
Profile
Enable
Type
PPTP User Name
Local IP/Subnet
Mask
Remote IP / Subnet
Mask
Netbios Naming
Packet
P T P D i a l - I n V P N p
P T P D i a l - I n V P N p
Description
Display the name of the profile.
Check this box to enable this profile.
There are three types offered here for you to choose. Please
choose PPTP Dial-In for this case.
Choose a PPTP user profile for authentication in PPTP
connection.
Such profile shall be created in User Management>>User
Profile previously. You can click Set PPTP Dial-In For
User Profile in this page to configure a new one for
choosing.
Type the IP address and subnet mask of local host.
Type the LAN IP address and LAN subnet mask for the
remote host.
Enable – Click it to have an inquiry for data transmission
between the hosts located on both sides of VPN Tunnel
while connecting.
Disable –When there is conflict occurred between the hosts
on both sides of VPN Tunnel in connecting, such function
316
r o f i l e
r o f i l e
