Profile
Enable
Always On
Dial-Out Through
Failover to
Idle Timeout
Server IP/Host
Name
PPTP User Name
PPTP Password
Local IP/Subnet
Mask
Remote IP/Subnet
Mask
Route/NAT Mode
Netbios Naming
Packet
Vigor2960 Series User's Guide
Display the name of the VPN profile.
Check this box to enable such profile.
Click Enable to make the profile being always on.
Choose a wan profile to be used by such profile. Then, use
the default WAN IP or specify a WAN Alias IP for VPN
tunnel.
Choose a wan profile which will lead the data passing
through other WAN automatically when the selected WAN
interface (in Dial-Out Through) is failover.
When Always On is disabled, you have to type the value for
terminating the network connection.
Type the IP address or host name of PPTP server.
Type a user name for authentication in PPTP connection.
Type a password for authentication in PPTP connection.
Type the IP address and subnet mask of local host.
Type the LAN IP address and LAN subnet mask for the
remote host.
Specify the purpose for such profile.
Enable – Click it to have an inquiry for data transmission
between the hosts located on both sides of VPN Tunnel
while connecting.
Disable –When there is conflict occurred between the hosts
on both sides of VPN Tunnel in connecting, such function
can block data transmission of Netbios Naming Packet inside
the tunnel.
