Draytek Vigor2960 Series User Manual page 253

Use mOTP
SSL Proxy
SSL Application
(VNC)
SSL Application
(RDP)
PPPoE Server
Allow PPPoE
Server Login
Quota Reset
Frequency
Time Quota (min)
Current Time Used
(min)
Traffic Quota(MB)
Current Traffic
Used (MB)
Vigor2960 Series User's Guide
Click Enable to make the authentication with mOTP
function.
mOTP PIN Code - Type the code for authentication (e.g,
1234).
mOTP Secret - Use the 32 digit-secret number generated by
mOTP in the mobile phone (e.g., e759bb6f0e94c7ab4fe6).
It is available when System User is set with false. The web
proxy over SSL will be applied for VPN.
To clear the selected one, click
selections.
It is available when System User is set with false. Choose
one of the SSL Application profiles (VNC) for applying into
this profile.
To clear the selected one, click
selections.
It is available when System User is set with false. Choose
one of the SSL Application profiles (RDP) for applying into
this profile.
To clear the selected one, click
selections.
Click Enable to activate related PPPoE configuration.
It is used to configure the cycle time for PPPoE quota. Note
that each time when the quota is reset, the value of Current
Time Used/Current Traffic Quota will be reset to initial
situation (0).
Everyday – The quota for PPPoE will be reset every day.
Everymonth – The quota for PPPoE will be reset every
month.
Type a time quota for PPPoE connection.
Note: The range of Time Quota is 1~14400 minutes.
Display the cumulative amount of time that the user used.
Reset - Click it to reset the setting to default value (0).
It is used to set the maximum traffic (MB) for such user
profile.
Display the cumulative amount of data traffic that the user
used.
Reset - Click it to reset the setting to default value (0).
245
to remove current object
to remove current object
to remove current object
