Click Diagnostics and click ARP Cache Table to view the content of the ARP (Address
Resolution Protocol) cache held in the router. The table shows a mapping between an
Ethernet hardware address (MAC Address) and an IP address.
4
.
1
6
.
2
.
1
A
R
4
.
1
6
.
2
.
1
A
R
Each item will be explained as follows:
Item
Refresh
Clear All
Search
IP Address
HW type
MAC Address
Flags
T
a
b
l
e
T
a
b
l
e
P
C
a
c
h
e
T
a
b
l
e
P
C
a
c
h
e
T
a
b
l
e
Description
Renew the web page.
Remove all of the information from this page.
Move the mouse cursor onto the box of Search. Click the
mouse button and type the keyword inside the box. The
system will display the records relating to the keyword.
Display the IP address for different ARP cache.
Display the hardware type of the address from RFC 826.
Display the MAC address for different ARP cache.
C means complete entry.
M means permanent entries.
396
Vigor2960 Series User's Guide
