4 4 . . 1 1 2 2 . . 1 1 . . 2 2 V V P P N N G G e e n n e e
This page allows you to configure the basic settings for the VPN tunnel of Vigor2960.
Available parameters are listed as follows:
Item
WAN Profile
Local IP/Subnet
IPsec Security Method
IKE Phase1 Mode
Apply
Cancel
r r a a l l S S e e t t u u p p
Description
Choose a WAN interface profile to be used.
Type the IP address and subnet mask of local host.
Choose one of the following methods for the security of data
transmission. For example, choose AH to specify the IPsec
protocol for the Authentication Header protocol. The data
will be authenticated but not be encrypted.
Choose Aggressive or Main as the IKE Phase1 Mode.
Click it to save the configuration.
Click it to discard the settings configured in this page.
344
Vigor2960 Series User's Guide
