Type
LDAP profiles
DHCP from
DHCP Relay
DHCP Server Location
DHCP Server IP
Address
Force L2TP with IPsec
policy
Apply
Cancel
Enter all of the settings and click Apply.
Choose a LDAP profile for PPTP Server if LDAP is
selected as user authentication type.
To clear the selected one, click
object selections.
Choose a LAN profile for L2TP Server if RADIUS is
selected as user authentication type.
Enable - Let the router assign IP address to every host in
the LAN.
Disable - Let you manually assign IP address to every host
in the LAN.
It is available when DHCP Relay is enabled.
Choose the WAN/LAN interface for the DHCP server.
It is available when DHCP Relay is enabled. Set the IP
address of the DHCP server you are going to use so the
relay agent can help to forward the DHCP request to the
DHCP server.
If it is checked, the router will use L2TP with IPsec policy
for VPN connection.
Click it to save the configuration.
Click it to discard the settings configured in this page.
306
to remove current
