Draytek Vigor2960 Series User Manual page 403

4 4 . . 1 1 6 6 . . 1 1 . .
Display the information for each route with IPv6 protocol.
Each item will be explained as follows:
Item
Refresh
Destination
Next Hop
Flags
Metric
Iface
Vigor2960 Series User's Guide
2 2 I I P P v v 6 6 R R o o u u t t i i n n g g T T a a
Description
Renew the web page.
Display the destination IP address for various routings.
Display the next hop address for such route.
Display the flag of the routing entry. Possible flags include:
U (route is up)
H (target is a host)
G (use gateway)
R (reinstate route for dynamic routing)
D (dynamically installed by daemon or redirect)
M (modified from routing daemon or redirect)
A (installed by addrconf)
C (cache entry)
! (reject route)
Display the distance to the target (usually counted in hops).
It may be needed by routing daemons.
Display the direction of such route represented with
LAN/WAN profile (starting from LAN/WAN profile to
LAN/WAN profile).
b b l l e e
395
