5.15

Machine configuration menu

5.15.1 Selecting, changing and saving parameters

ENTER (Enter the menu)
•
Switch off the machine at the main switch.
•
Press and hold the "welding procedure" push-button and switch the machine on again at
the same time.
NAVIGATION (Navigate the menu)
•
Select parameters by turning the "welding parameter setting" rotary knob.
•
Set or change the parameters by turning the "welding voltage" rotary knob.
EXIT (Exit the menu)
•
Press the "gas test" push-button (switch machine off and on again).
ENTER
0
l
Display

5.15.2 Power-saving mode

The power-saving function can be activated either by pressing the button for a longer time (see chapter
"Machine description – Short overview") or by setting a parameter in the configuration menu (time-based
power-saving mode).
When power-saving mode is activated, both machine displays show the horizontal digit in the
centre of the display only.
Pressing any operating element (e.g. tapping the torch trigger) deactivates power-saving mode and the
machine is ready for welding again.
099-005221-EW501
16.04.2014
+
Setting/selection
Lead resistance 1
Lead resistance for the first welding circuit 0 mΩ–60 mΩ (8 mΩ ex works).
Only qualified service personnel may change the parameters!
Time-based power-saving mode
•
5 min.–60 min. = Time to activation of power-saving mode in case of inactivity.
•
off = inactivated
Design and function
NOTE
EXIT
Figure 5-24
Machine configuration menu
0
l
NAVIGATION
47
