Instruction Codes for Protocol 2000

Instruction
# Description
0 RESET VIDEO
1 SWITCH VIDEO
3 STORE VIDEO
STATUS
4 RECALL VIDEO
STATUS
5 REQUEST STATUS
OF A VIDEO OUTPUT
15 REQUEST WHETHER
SETUP IS DEFINED /
VALID INPUT IS
DETECTED
30 LOCK FRONT PANEL
31 REQUEST WHETHER
PANEL IS LOCKED
56 CHANGE TO ASCII
61 IDENTIFY MACHINE
62 DEFINE MACHINE
NOTES on the above table:
NOTE 1 - When the master switcher is reset, (e.g. when it is turned on), the reset code is sent to the PC. If this code is
sent to the switchers, it resets according to the present power-down settings.
NOTE 2 - These are bi-directional definitions. That is, if the switcher receives the code, it performs the instruction; and if
the instruction is performed (due to a keystroke operation on the front panel), then these codes are sent. For example, if
the HEX code
01
was sent from the PC, then the switcher (machine 3) switches input 5 to output 8. If the user switched input 1 to output 7
via the front panel keypad, then the switcher sends HEX codes:
41
to the PC.
When the PC sends one of the commands in this group to the switcher, then, if the instruction is valid, the switcher
replies by sending to the PC the same four bytes that it was sent (except for the first byte, where the DESTINATION bit
is set high).
NOTE 3 - SETUP # 0 is the present setting. SETUP # 1 and higher are the settings saved in the switcher's memory, (i.e.
those used for Store and Recall).
NOTE 4 - The reply to a "REQUEST" instruction is as follows: the same instruction and INPUT codes as were sent are
returned, and the OUTPUT is assigned the value of the requested parameter. The replies to instructions 10 and 11 are
as per the definitions in instructions 7 and 8 respectively. For example, if the present status of machine number 5 is
breakaway setting, then the reply to the HEX code
0B
would be HEX codes
4B
NOTE 8 - The reply is as in TYPE 3 above, except that here the OUTPUT is assigned with the value 0 if the setup is not
defined / no valid input is detected; or 1 if it is defined / valid input is detected.
VS-88HN - Kramer Protocol 2000
Definition for Specific Instruction
Input
0
Set equal to video input which is
to be switched
(0 = disconnect)
Set as SETUP #
Set as SETUP #
Set as SETUP #
SETUP #
or
Input #
0 - Panel unlocked
1 - Panel locked
0
0
1 - video machine name
2 - audio machine name
3 - video software version
4 - audio software version
5 - RS422 controller name
6 - RS422 controller version
7 - remote control name
8 - remote software version
9 - Protocol 2000 revision
1 - number of inputs
2 - number of outputs
3 - number of setups
85 88
81 87
80 80
80 81
Output
0
Set equal to video output which is
to be switched
(0 = to all the outputs)
0 - to store
1 - to delete
0
Equal to output number whose
status is required
0 - for checking if setup is defined
1 - for checking if input is valid
0
0
Kramer protocol 3000
0 - Request first 4 digits
1 - Request first suffix
2 - Request second suffix
3 - Request third suffix
10 - Request first prefix
11 - Request second prefix
12 - Request third prefix
1 - for video
2 - for audio
3 - for SDI
4 - for remote panel
5 - for RS-422 controller
83
83
85
85
Notes
1
2, 15
2, 3, 15
2, 3, 15
4, 3
8
2
16
19
13
14
25
