5 Connecting the VS-88HN 8x8 HDMI Matrix
Switcher
To connect the VS-88HN 8x8 HDMI Matrix Switcher as illustrated in the example
in Figure 3:
1. Connect up to eight HDMI sources (for example, DVD players) to the IN
HDMI connectors.
You do not have to connect all the sources.
2. Connect the eight OUT HDMI connectors to up to eight HDMI acceptors (for
example, LCD displays with built-in speakers).
You do not have to connect all the outputs.
3. If required, connect a PC/controller to the RS-232 port (see
and/or the Ethernet port (see
4. Connect the device to the mains electricity (not shown in
5. Power the device.
6. If necessary, acquire the EDID (see
10
Always switch off the power to each device before connecting it to your
VS-88HN. After connecting your VS-88HN, connect its power and then
switch on the power to each device.
VS-88HN - Connecting the VS-88HN 8x8 HDMI Matrix Switcher
Section 6.9).
Section 6.2)
Section 6.8)
Figure 3).
